Seite 1/1

hue

m70

LED

280

ø120

140

555/655/855

160

600/700/900

Cod. 02017305 EAN 8422248061988

TF 2003 DURALUM

TF-2003 DURALUM 600

TELESCOPICHOODS

Code 02017305

EAN 8422248061988

Model

TF-2003 DURALUM 600

Type Telescopic

Product fiche according to directives EU65/2014 - EN61591, EN60704-2-13, EN50564

AEC (Anual Energy consumption) (kWh/annum) 44,5

EEI class (Energy Eiciency Class) C

FDE (Fluid Dynamic Eiciency) 11,9

FDE class (Fluid Dynamic Eiciency Class) E

LE (Lighting Eiciency) (lux/W) 36

LE class (Lighting Eiciency Class) A

GFE (Grease Filtering Eiciency) 68

GFE Class (Grease Filtering Eiciency class) D

Air flow at minimum speed (m 3/h) 150

Air flow at maximum speed (m 3/h) 390

Air flow at intensive speed (TURBO) (m 3/h) -

Sound Power Level at minimum speed (dB) 45

Sound Power Level at maximum speed (dB) 57

Sound Power Level at intensive speed (TURBO) (dB) -

Po (Power Consumption in o mode) (W) 0

Ps (Power Consumption in standby) (W) 0

Integration directive EU 66/2014

ƒ (Time Increase Factor) 1,6

EEI (Energy Eiciency Index) 78,2

QBEP (Flow Rate at Best Eiciency Point) (m3/h) 198,2

PBEP (Static Pressure Dierence at Best Eiciency Point) (Pa) 148

WBEP (Electric Power Input at Best Eiciency Point) (W) 68,6

WL (Nominal Power Consumption of Lighting system) (W) 7

EMIDDLE (Average Illumination of Lighting system on Cooking surface) (lux) 252

External Dimensions

Width (mm) 600

Depth (mm) 280

Total max height (mm) 180

Total min height (mm) 180

Outlet Diameter (mm) 120

Characteristics

Motor TF 2003

Extraction Levels 2

Motor Maximum Power Consumption 100

Maximum Pressure 194

Intensive Speed (TURBO) Pressure -

Control Type Rocker Switch

Automatic shut-down timer -

Electronic Filter Saturation Indicator -

Filter Type Metallic

Anti-grease Filter Number 2

Inner Shield √

Lighting

Light Type Ecoled

Adjustable Intensity Lighting -

Nº of Lamps 2

Installation

Minimum height distance to a electric worktop hob (mm) 550

Minimum height distance to a gas worktop hob (mm) 650

Instalation with Outlet tube to the exterior / Recirculating BOTH

Easy Instalation System √

Electric Connection

Total Rush Power (W) 107

Rated Voltage (V) 220-240

Network Frequency (Hz) 50

Electrical Insulation Class CLASS I

Plug -

Accessories

Upper Decorative tube Extension -

White Decorative Tube -

Black Decorative Tube -

Island Tube Enhancer -

Check Valve 02849003

MAX PRO Metal Filter -

Metal Filter 02825272*

DUAL Filter (metal + active charcoal) -

Active Charcoal Filter 02825263

Noiseless Flexible Duct -

❒

Mechanical control panel

❒

2 extraction levels

❒

Extraction power (according to UNE/EN 61591): 390m

/h - 150m

❒

Maximum air flow (free outlet): 600m

❒

Sound power (Reg.(EU) nº65/2014): 45.5dB(A), maximum: 57dB(A)

❒

Tangential motor. Extra silent. Maximum energy consumption 100W

❒

High eiciency LED lighting

❒

Easy-to-clean inner panel

❒

Easy-to-install system

❒

Dishwasher-washable filters

❒

Finished in Stainless steel fingerprint free DurAlum

❒

Replaceable handrail

❒

Max. pressure 194 Pa

❒

120mm outlet diameter

❒

Energy Class: C

▶ Accessories

(not included)

Active charcoal filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Cod. 02825263 / EAN 8422248006552 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Check valve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Cod. 02849003 / EAN 8422248044653 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
