Coleman Octagon 98 Bedienungsanleitung

Coleman Zelt Octagon 98

Lies die bedienungsanleitung für Coleman Octagon 98 (5 Seiten) kostenlos online; sie gehört zur Kategorie Zelt. Dieses Handbuch wurde von 18 Personen als hilfreich bewertet und erhielt im Schnitt 4.5 Sterne aus 9.5 Bewertungen. Hast du eine Frage zu Coleman Octagon 98 oder möchtest du andere Nutzer dieses Produkts befragen? Stelle eine Frage

Download PDF

Seite 1/5

SHEET 1 OF 1

Wichita, Kansas USA 67219

The Coleman Company, Inc.

COMPOSITE- NO

CRITICAL DIMENSION

cm3

REV.

MAT ERIAL:

SEE NOTES

1:1 27-SEP-13

Black

Program: InDesign CS6

Abby K

Instruction for Octagon 98 - Half Rainy

4010024931

SCALE:

NAME:

DATE: DRAWN BY: APPROVED BY: REVISION

FINISH

SPEC.:

DATE NAME ECN NO.MODIFICATIONS

grams

g/cm3

This drawing contains proprietary information and trade secrets of The Coleman Company, Inc.

Unauthorized use or copying is prohibited.

METRIC

[INCH]

CHECKING IS COMPULSORY

VOLUME 01 27-SEP-13 Abby K 20031793NEW

MASS

DENSITY

GENERAL TOLERANCES

EXCEPT AS NOTED

0 TO 6mm = ±0.1

>6 TO 30mm = ±0.2

>30 TO 80mm = ±0.3

>80 TO 180mm = ±0.4

>180mm = ±0.5

ANGULAR = ± 3°

PART

NO.:

DO NOT PRINT THIS PAGE

Printing Notes:

Material: White washable and tear resistant non-woven

fabric, such as Tyvek.

Ink: Black

Resolution: 150 DPI or above

Printing method: Offset Printing

Size: 8.27 x 11.29(A4) in (W x H)

STITCH LINE

Fig. 1

Roof

Pole Leg Pole

TENT SETUP INSTRUCTIONS

(continued on other side)

Connect Poles to Tent

Layout & Positioning

of Tent and Poles

• Layoutandpositionthetentwithbothdoorsfacingdesired

directions.(Fig.1)

• Stakedowntentcornersbydrivingthestakesintotheloops

attachedatthebottomofthetent.(Fig.2)

• Keeptheoortaut.

• Assembleallpolesbyunfoldingandinterlockingtheshock-

cordedpolesections.

• Insertoneendofroofpoletothe8-in-1polehubatthecenter,

andtheotherendwillbeinsertedintotothepoleconnectorat

tentcorneratstep2.(Fig.3)

Tent

Stake

Fig. 2

• Insertroofpolesandlegpolesintopoleconnectors.(the

colormarkingonthelegpolesshouldmatchthemarkon

poleconnectors)

• Insertonepinintotheendofthelegpole.(Fig.5and6)

• Repeatforalllegpoles.

• Thetentwillraiseasthelegpolesareallconnectedwith

thetent.

NOTE: The tent door should between the adjacent leg poles

with awning pole connector.

Attach Tent to Leg Poles

Using Clips

• Attachclipsalongtheedgesoftenttolegpoles.(Fig.7)

• Makeanyadjustmentstothetentstakes,ifneeded.

Fig. 7

Awning Pole

Connector

Roof Pole

Leg Pole

Fig. 4

Pole

Connector

Fig. 5

Pole

Clip

Fig. 3

Pole

Hub

Roof

Pole Fig. 6

Leg

Pole

AwningPole,fiberglass,black,thick

SteelRoofPole,steel,gray

SteelLegPole,steel,gray

5010000569

N/A

5010000568

N/A

Before you begin

• Readallinstructionsbeforesetup.

• Selectalevelsiteclearofrocks,branches,andotherhardor

sharpobjects,toinstallyourtent.

WARNING: Keep clear of overhead power lines.

• Donotsetupyourtentundertreesbecauseofpotentiallightning

strikesorfallingtreelimbsininclementweather.

• Securewith stakesandguylinesprovidedtopreventpropertyall

damageorpersonalinjury.

• Forbestresultsinwindyconditions,positionnarrowendoftent

intothewind.

• Enlistthehelpofatleastoneotherpersontoassistyouwhenit

istimetoassemblethetent.

Pole Descriptions

Description

No. Qty. Pole

Repair Kit

Pole

Replacement Kit

Tent Octagon 98 - Half Rainfly

(The product may look different from yours. It is for illustration purpose only.)

STITCH LINE

4010024774(ECN20031793-01)

TheColemanCompany,Inc.•3600NorthHydraulic•Wichita,Kansas67219U.S.A.

1-800-835-3278intheUnitedStates•www.coleman.com

MADE IN BANGLADESH

©2013TheColemanCompany,Inc.Allrightsreserved.

Coleman®, ,and areregisteredtrademarksofTheColemanCompany,Inc.

WARNING: KEEP ALL FLAME AND HEAT SOURCES AWAY FROM

THIS TENT FABRIC.

ThistentmeetstheammabilityrequirementsofCPAI-84.The

fabricmayburnifleftincontinuouscontactwithanyamesource.

Theapplicationofanyforeignsubstancetothetentfabricmay

rendertheame-resistantpropertiesineffective.

Strap

Fig. 12

Pole

Fig. 11

“S”

Hook

Fig. 9

Fig. 13

1.Allpolesandstakesmustbeplacedinthestoragebagto

preventdamagetothefabricitemsplacedinthecarrycase.

2.Makesuretentiscleananddrybeforeplacingincarrycase.

3.Removerainy,spreadoutonooroftent,thenunzip

door&ventsbeforetakingtentdownforstorage.

4.Neatlyfoldtenttowidthofpolestoragebag,placeontent,roll

tightly,andplaceincarrycase.

5.Storeinaclean,dryarea.

To Store

Attach Rainﬂy

Rainﬂy

Pole Sleeve

Fig. 8

Awning

Pole

Fig. 10

Awning

Pole

Awning

Connector

Things You Should Know:

• Undercertainconditions(coldweather,highhumidity,etc.)

condensationwillformontheinsideofyourtent.Condensation

iscausedbywatervaporfromyourbreath,perspiration,orany

wetclothinginsidethetent.ItisNOTLEAKAGEthroughthetent

fabric.Itcanbeminimizedbyremovingwetclothingfromyour

tentandbyprovidinggoodventilationthroughthetent.

• Treelimbs,treesap,birddroppings,ormoisturesteadilydripping

offtreelimbscancausedamagetothetentfabricanditscoating

resultinginleaksorlossofame-resistantproperties.

• Neverstoretent,evenforashortperiodoftime,withoutdrying

itthoroughlyandbrushingoffcakeddirt.Donotpackstakesor

polesinsideyourtent.Useaseparatestoragebag.

• Stakesshouldberemovedbypullingonthestakeitself.NEVER

PULLONTHETENTTOREMOVESTAKESASTHISCOULDRESULT

INPROPERTYDAMAGEORPERSONALINJURY.

• Tentpolesshouldnotbelefttelescopedtogetherduringstorage.

• Donotleaveyourtentset-upforweeksatatime.Beawarethat

exposuretoultravioletraysfromthesuncanseriouslydamage

materialand/orcauseittobecomediscolored.

• Insertawningpoleintopolesleeveslocatedonundersideof

rainy.(Fig.8)

• Draperainyovertent.(Fig.9)

• Connecttheelasticloopswith“S”hooks,(foundattherainy

corners)totheringsfoundatthetentcorners.(Fig.10)

• Insertthetipsoftheawningpoleintothegrommets.(Fig.11)

• Securerainywithstrapslocatedontheundersideof

rainy.(Fig.12)

• Attachandstakeoutguylines.(Fig.13)

HINT: Duringsetup,keepdoorzippedtokeeppropertension

onfabric.
