Congratulations on your purchase of Camden EC1 and thank you for
selecting Cranborne Audio to be a part of your music creation process.
Cranborne Audio, for us, means so much more than metal boxes with
components in them. These are our labours of love that embody and
demonstrate our demand for excellence. By distilling what matters and
putting our soul into these tools, we hope to help other people make magic
and express themselves, and in some way, become part of our Cranborne
Audio family.
So welcome to our family. We care for our family. And we care about making
your tracks, albums, scores sound as good as they should.
Controls and Connectors
Page 2 ©2020 Cranborne Audio Ltd
[1] Mojo Control: Adjusts the level of
Mojo
analogue saturation. Bypasses Mojo
and clicks off when turned fully
anti-clockwise.
[10] 48v Status Indicator: Bicolour LED
that displays 48v status.
Off = 48v Off, voltage fully discharged
Amber = 48v voltage
charging/discharging
Red = 48v fully charged
[2] Mojo Style Switch: Toggles the
Mojo style between 2 discrete styles:
Thump & Cream.
[11] Preamp Level Control: Adjusts the
level of the Camden Preamp into the
Aux bus.
[3] Signal Indicator: RGB LED that
displays incoming signal level and clip
status.
[12] Aux In/C.A.S.T. Level Control:
Adjusts the level of the rear Aux Inputs
and C.A.S.T. OUT RR into the Aux bus.
[4] HPF Switch: Engages the 80Hz
High Pass (Low Cut) filter. -3dB @
80Hz.
(Switch Down = ON)
[13] EXT In Level Control: Adjusts the
level of the EXT IN jack into the Aux
bus.
[5] Polarity Switch: Inverts the polarity
of the input signal by 180°.
(Switch Down = ON)
[14] Aux Headphone Level: Adjusts the
main level of the Aux bus to the Aux
Headphones output.
[6] Gain Control: 12 position switched
pot. Adjusts the input sensitivity of the
preamp from 8 to 68.5dB in 5.5dB
increments.
[15] EXT IN Line Input: Connects a
mono, analogue playback source
directly into Camden EC1’s monitoring
path. EXT In is also sent to the second
‘T’ path of the C.A.S.T. Output.
[7] Input Type Switch: 3-way switch.
Adjusts the input Impedance and pad
status of the preamp input to match
the desired input type; hi-z, line, or mic.
[16] Aux Headphone Output: Used for
connecting headphones to the Aux
bus.
[8] 48v Switch: Engages 48v phantom
power for the rear XLR input
connector.
(Switch Down = ON)
[17] Power Switch: Safely powers on
and off Camden EC1. Tap to power on,
press and hold to power off.
[9] Hi-Z/Line Input: Used to connect
line or hi-z instruments directly into
the preamp’s front panel. Hi-z/line
input interrupts rear XLR or C.A.S.T.
input connections.
Page 3 ©2020 Cranborne Audio Ltd
