Wall Sconce Installation Instructions

This wall sconce can be used as a surface mounted portable light or it can be converted to a

surface mounted fixture, either of which complies with Underwriter’s Laboratory standards for

safety.

Portable Surface Mounted Light

1. Determine the location of the wall sconce and mark wall with a pencil at the top of the

round base. Nail the top of the picture hook into the wall at the pencil mark.

2. Loosen the green ground screw and remove the bare copper ground wire from the

round mounting plate (on back of base) and tighten ground screw. Discard this copper

wire since it is used only when the wall light is permanently wired as a fixture.

3. Suspend the wall sconce on the picture hook (the semi-circle shaped opening in top of

mounting plate fits over the picture hook).

4. Insert the cord into the cord cover and position it on the wall below the light. Mark its

location on the wall with a pencil.

5. Remove the film from the adhesive strip on the back of the cord cover. Reposition cord

cover on the pencil marks and press it firmly against wall (cord cover will adhere best

to a smooth flat surface)

Convertible Surface Mounted Fixture

1. Disconnect power to the electrical outlet box in the wall, remove cover plate (save the

screws) and unscrew wire connectors from ends of house wiring (save the wire

connectors).

2. Unscrew the 2 round brass ball finials from the front of the wall sconce and remove

round mounting plate from the back of the base. If the 2 headless machine screws

came unscrewed from the round mounting plate, re-install into the holes that are 3 ½

inches on center. Discard the 2 spacers (3/6” x 1” threaded pipe).

3. Gently pull the house wiring (white, black and copper ground wire) out of the electrical

outlet box and push it through the center hole in the round mounting plate. Position

the round mounting plate over the outlet box so the 2 headless machine screws are on

a horizontal line parallel to the floor. Attach the mounting plate to outlet box by

inserting the screws (that you saved in step 1 above) through the curved slots or holes

that align with the threaded holes in the outlet box and tighten.

4. The bare copper ground wire attached to the green ground screw on the round

mounting plate should be connected to the bare copper ground wire in the electrical

box.

5. Convert the wiring of this portable wall sconce to fixture wiring by removing the plug

from the gold insulated supply wire. Cut it off about 1 foot from the round metal base

of the wall sconce and discard cord. (Discard cord cover also).

6. Split the insulation (on the gold double wire) down the center by a length of 3”and

strip ¾” of insulation off the end of each gold wire. If you look very closely you will

notice that the plastic insulation on one of the split wires has a ridge running the

length of the wire on the outside edge. This ribbed wire is the “neutral wire” and the

other is the “hot wire”. Using the wire connectors (that you save in step 1) connect the

ribbed “neutral wire” to white house wire and the other gold wire (without ridge) to

black house wire.

7. Align the two 3/16” diameter holes in the round base over the two headless machine

screws in the round mounting plate and push the wall sconce until it is flush against

the wall.

8. Screw the 2 brass ball finials onto the headless machine screws and tighten with

fingers.

9. Restore power to electrical outlet box.

Caution

Injury to persons and damage to the wall sconce and/or mounting surface may result if the wall

sconce is pulled from the surface. To reduce the likelihood of such injury or damage, mount

only on a surface that is mechanically sound.

www.curreyandcompany.com
