Seite 1/3
Use DataComm Electronics’ Recessed Low Voltage Mid-Size Plate with Duplex Surge Supp to w d your flat panel TV, ressor install lo voltage cables behin
your amplifier or other audio and video devices. This mid ize plate can be in alled uprigh sideways. -s st t,
Features of the 45-0081 Recessed Low Voltage Mid-Size Plate with Duplex Surge Suppressor include:
Compa size fi behind all and large ’s ct ts sm TV
TV re y wa plug cesses completel into the ll
Duplex receptacle for additional devices
IMP INSTRUCTIONSORTANT :
This product is designed for retrofit work only because the electrical outlet x cannot be attached to a stud. bo
This product is designed to alert you if you ever lose surge protection. The Surge Suppressor Receptacle is designed to provide protection against short-
term over-voltage conditions as well as from RFI adio frequency interference). The Surge Suppressor cannot survive, or provide protection in the rare (r
event of a dire lightning strike on the service power line.ct
The Surge Suppressor alerts you to the failure of the surge protection component by means of
an audible signal. alarm sounds, device has “received” power surges in exce of y on as a surge protector. To shut If ss its capacit and is no longer functi ing
off alarm, simply turn the “Alarm Off” screw on the ront of the receptacle clockwise. Note: When alarm sounds and the “Alarm Off” scr is turn off, the f ew
receptacle still nctions as normal duple fu a x receptacle without surge protection.
WARNING:
Before you run your 12/2 or 14/2 w/ground UL approved building wire to the Recessed Low Voltage Mid-Size Plate with Duplex Surge
Suppressor, be sure the power is off by switching the circuit breaker to off or removing the fuse(s). Test the power to make sure the power is
off. Be sure to install the Mid-Size Plate with Duplex Surge S pressor in accordance with the National Electrical Code (NEC) and local codes. up
Installation Instructions:
DataC Elect ic Incomm ron s, .
63 acht ee ee49 Pe r Str t
Norcro , G 30 -1 5 ss A 071 72
888 3. 97.22 7 7
770 2. 20.66 8 5
www m lectroni m.dataco me cs.co
In ll ion struct staion / In at Sheet
DataComm Electronics 45-0081 Recessed Low Voltage Mid-Size Plate with Duplex Surge Suppressor
Parts Included:
1. 45-0081 Recessed Low Voltage Mid-Size Plate
2. Electrical Outlet Box
3. 15 Amp/125 Volt Duplex Surge Suppressor
4. Four (4) Screws
Tools Neede d:
1. Drywall Saw
2. 6 Ft. Tape Measure
3. Pencil
4. Screwdr er iv
Figure 1 – Front View
Figure 2 – Back View
Fig. 1
Fig. 2
Figure 1
Top view - shows needed space between the drywall and the studs.
Receptacle side of the Mid ize Plate should be 3” from the stud but no -S
more than 5” (review picture carefully).
Figure 2
Using the template supplied (see page 3 of instruction sheet), trace the opening needed. Using a drywall saw,
cut a hole in the drywall the size of the template. before tracing your opening. See Figure 1 Remember, the
plates are designed to be mounted between the studs.
Page 1 of 3 10/1/12
Concealed Wiring
(hidden in wall)
Flat Screen TV
Concealed Wiring
(hidden in wall)
Flat Screen TV
