Seite 1/6
SYSTEM 10
ANALOG INPUT CARDS
1.E.2.10A16-4C
1 GENERAL DESCRIPTION AND SPECIFICATIONS
The Model 10A16-4C is designed for high-accuracy temperature measurement using
platinum
Resistance Temperature Detectors (RTD's). Precision constant-current
excitation is provided for four independent sensor channels, which may be intermixed
as required. RTD inputs are normally set for four-wire cabling, with maximum excita-
tion of one milliampere and input impedance of 10 MΩ, to eliminate common self-heat-
ing and cable-loading errors. However, for an RTD channel with shared current return
and sense signals, three-wire mode is available, if desired, via an internal jumper set-
ting (as explained in Section 3.a, below).
ADDITIONAL 10A16-4C SPECIFICATIONS
RTD Types: Platinum; DIN (European) standard with “ice-point” resistance of 50, 100,
or 200 ohms, or American standard with “ice-point” of 100 ohms
Range and Resolution: See Table 1, below; automatically selected—on an individual
channel basis—when the channel is configured; for System 10 channel “type” codes
assigned to 10A16-4C data channels, see Table 1; for
high RTD resolution, using a
specially modified 10A16-4C card, see Section 3.c, below
Linearization: Internal digital linearization; maximum error: ±0.1° C (±0.2° F)
Excitation (per channel): Nominal 5 V-DC; 1 mA, maximum
Amplifier (per channel):
Input Impedance (Differential): 10 megohms
Offset: Initial: ±0.1 mV; vs. Temperature: ±0.5 µV/°C; vs. Time: ±5 µV/month
Gain Accuracy: ±0.02% of full scale
Gain Stability: vs. Temperature: ±25 ppm/°C; vs. Time: ±20 ppm/month
Filter (per channel): 3-pole modified Butterworth; 3 dB down at 2 Hz; 60 dB down at
25 Hz
Step-Response Settling Time (Full-Scale Output):
To 1% of final value: 0.6 sec
To 0.1% of final value: 0.8 sec
To 0.02% of final value: 1.5 sec
Total System Accuracy (typical, including Model 10A16-4C and system data collec-
tion and processing): see Table 1, below
Auxiliary Outputs: Filtered outputs available on mainframe wire-wrap pins
MODEL 10A16-4C
QUAD PLATINUM RTD
C
ONDITIONER CARD
GENERAL DESCRIPTION AND SPECIFICATIONS 10A16-4C.1
Table 1 RTD Ranges for the Model 10A16-4C
Platinum Typical Maximum Channel
RTDResis- Display System Expected Type
Standard tance Range Resolution
3
Accuracy
4
Error
4
Code
DIN
1
50 Ω -150° C to +600° C 1.0° C ± 1° C ± 1.3° C A9
DIN
1
50 Ω -150° C to +600° C 0.1° C ± 0.2° C ± 0.4° C AA
DIN
1
50 Ω -238° F to +1112° F 1.0° F ± 1° F ± 1.5° F AB
DIN
1
50 Ω -238° F to +1112° F 0.2° F ± 0.3° F ± 0.6° F AC
DIN
1
100 Ω -150° C to +600° C 1.0° C ± 1° C ± 1.3° C A1
DIN
1
100 Ω -150° C to +600° C 0.1° C ± 0.2° C ± 0.4° C A2
DIN
1
100 Ω -238° F to +1112° F 1.0° F ± 1° F ± 1.5° F A3
DIN
1
100 Ω -238° F to +1112° F 0.2° F ± 0.3° F ± 0.6° F A4
DIN
1
200 Ω -150° C to +600° C 1.0° C ± 1° C ± 1.3° C A5
DIN
1
200 Ω -150° C to +600° C 0.1° C ± 0.2° C ± 0.4° C A6
DIN
1
200 Ω -238° F to +1112° F 1.0° F ± 1° F ± 1.5° F A7
DIN
1
200 Ω -238° F to +1112° F 0.2° F ± 0.3° F ± 0.6° F A8
American
2
100 Ω -150° C to +600° C 0.1° C ± 0.2° C ± 0.4° C AD
American
2
100 Ω -238° F to +1112° F 0.2° F ± 0.3° F ± 0.6° F AE
1
α = 0.00385.
2
α = 0.00392.
3
Note that a specially modified version of the 10A16-4C yields resolution of 0.01° C (0.02° F)
when used with System 10 “custom linearization.” See Section 3.c for details.
4
Including ± one count of least significant digit displayed.
2 TRANSDUCER CONNECTIONS
The Model 10A16-4C’s I/O CONNECTOR mates with Daytronic CONDITIONER CON-
NECTOR No. 60322, shown in Fig. 1.5 (in Manual Section 1.E.1). Standard
four-wire
RTD cabling is shown in Fig. 1(a), below. With separate excitation and sense lines, this
mode of cabling normally yields the highest measurement accuracy. However, any
10A16-4C input channel can be set to accommodate the alternative
three-wire cabling
shown in Fig. 1(b). THE APPROPRIATE JUMPER SETTING MUST BE MADE FOR EACH
10A16-4C CHANNEL, DEPENDING ON WHETHER 4-WIRE OR 3-WIRE CABLING IS
BEING USED FOR THAT CHANNEL (see the instructions in Section 3.a, below). Table 2
gives standard pin assignments for the I/O Connector.
IMPORTANT: When cabling the 10A16-4C, you can ensure static protection by con-
necting the SHIELD wire to
Pin 10 as well as to the connector ground lug, as shown in
Fig. 1.
Table 2 Model 10A16-4C Pin Assignments
I/O Connector Conditioner Conditioner
Pin Channel Line
Number Number Function
11+SIGNAL
A1–SIGNAL
21+CURRENT
B1–CURRENT
32+SIGNAL
C2–SIGNAL
42+CURRENT
D2–CURRENT
53+SIGNAL
E3–SIGNAL
63+CURRENT
F3–CURRENT
(cont’d)
10A16-4C.2 TRANSDUCER CONNECTIONS
10A16-4C QUAD PLATINUM RTD CARD
