Seite 1/4
1 GENERAL DESCRIPTION AND SPECIFICATIONS
The Model 10A60-4 is a general-purpose conditioner allowing input of up to four
external voltage signals. Mixed as desired, these may originate from DC-to-DC
LVDT’s, potentiometer-type sensors, and other 2-wire analog signal sources that
pro-
vide their own power supply.
Or they may represent the outputs of other instrument
systems having various voltage levels and grounding configurations.
Inputs can be either floating (differential) or grounded (single-ended). With differential
inputs, generous common-mode range and excellent common-mode rejection elimi-
nate ground-coupling errors and other problems normally associated with off-ground
signal sources. Chopper-stabilized DC amplification with active low-pass filtering
yields smooth and stable measurement of the true average value of the input variable,
even in the face of substantial dynamic content.
ADDITIONAL 10A60-4 SPECIFICATIONS
Transducer Types
: 2-wire DC voltage sources, grounded or floating
Input Voltage Ranges: ±0.5, 1.0, 2.0, 5.0, 10, or 20 V-DC; automatically selected—on
an individual channel basis—when the channel is configured; for the System 10
channel “type” codes assigned to 10A60-4 data channels, see Table 1, below
Amplifier (per channel):
Normal-Mode Range: ±20 V operating; ±200 V without instrument damage
Common-Mode Range: ±50 V operating; ±300 V without instrument damage
Common-Mode Rejection Ratio: DC: -60 dB; at 60 Hz: -70 dB
Input Impedance: Differential: 2 M; Common-Mode: 0.5 M
Offset: Initial: ±0.5 mV; vs. Temperature: ±0.005 mV/°C; vs. Time: ±0.05 mV/month
Gain Accuracy: ±0.02% of full scale typical, following calibration*
Gain Stability: vs. Temperature: ±50 ppm/°C; vs. Time: ±50 ppm/month
Filter (per channel): 3-pole modified Butterworth; 3 dB down at 10 Hz; 60 dB down at
100 Hz
Step-Response Settling Time (Full-Scale Output):
To 1% of final value: 150 msec
To 0.1% of final value: 200 msec
To 0.02% of final value: 250 msec
Auxiliary Outputs: Filtered outputs available on mainframe wire-wrap pins
* Initial (uncalibrated) inaccuracy may be as great as ±1.5% of full scale. Maximum error that
could occur upon replacement of a Model 10A60-4 not followed by calibration is ±3% of full
scale.
MODEL 10A60-4
QUAD VOLTAGE
CONDITIONER CARD
GENERAL DESCRIPTION AND SPECIFICATIONS 10A60-4.1
SYSTEM 10
ANALOG INPUT CARDS
1.E.2.10A60-4
Table 1 10A60-4 “Type” Codes
Full-Scale Channel
Range Type Code
±0.5 V-DC 5A
±1.0 V-DC 5B
±2.0 V-DC 5C
±5.0 V-DC 5D
±10.0 V-DC 5E
±20.0 V-DC 5F
2 TRANSDUCER CONNECTIONS
The Model 10A60-4’s I/O CONNECTOR mates with Daytronic CONDITIONER CON-
NECTOR No. 60322, shown in Fig. 1.5 (in Manual Section 1.E.1). Table 2 gives stan-
dard pin assignments for the I/O Connector.
Cabling for
floating inputs is given in Fig. 1(a). NOTE: To minimize signal noise, it is
recommended that for a floating (ungrounded) input with high common-mode imped-
ance, the COMMON pin be tied to the –SIGNAL line at the connector. Cabling for
grounded inputs is shown in Fig. 1(b).
Table 2 Model 10A60-4 Pin Assignments
I/O Connector Conditioner Conditioner
Pin Channel Line
Number Number Function
11+SIGNAL
A1–SIGNAL
21COMMON
B Not Committed
32+SIGNAL
C2–SIGNAL
42COMMON
D Not Committed
53+SIGNAL
E3–SIGNAL
63COMMON
F Not Committed
74+SIGNAL
H4–SIGNAL
84COMMON
J Not Committed
9,K,10,L Not Committed
10A60-4.2 TRANSDUCER CONNECTIONS
10A60-4 QUAD DC VOLTAGE CARD
