INTRODUCTION
Thank you for choosing a De’Longhi product.
Please take a few moments to read the instructions to avoid risks
or damage to the appliance.
Symbols used in these instructions
Important warnings are identied by the symbols below.
It is important to respect the warnings.
Failure to respect the warnings could lead to electric shock,
serious injury, burns, re or damage to the appliance.
Important!
Failure to observe the warning could result in injury or damage
to the appliance.
Danger of burns!!
Failure to observe the warning could result in burns or scalds.
Please note:
This symbol indicates recommendations and important
information for the user.
IMPORTANT WARNINGS
Safety warnings
Important!
- This appliance can be used by children
aged from 8 years and above and
persons with reduced physical, sensory
or mental capabilities or lack of
experience and knowledge if they have
been given supervision or instruction
concerning use of the appliance in a
safe way and understand the hazards
involved. Children shall not play with
the appliance. Cleaning and user
maintenance shall not be made by
children without supervision.
- Children of less than 3 years should
be kept away unless continuously
supervised.
- Children aged from 3 years and less
than 8 years shall only switch on/
o the appliance provided that it has
been placed or installed in its intended
normal operating position and they have
been given supervision or instruction
concerning use of the appliance in a
safe way and understand the hazards
involved. Children aged from 3 years
and less than 8 years shall not plug in,
regulate and clean the appliance or
perform user maintenance. CAUTION —
Some parts of this product can become
very hot and cause burns. Particular
attention has to be given where children
and vulnerable people are present.
- WARNING: In order to avoid
overheating, never under
any circumstances cover the
appliances during operation, as this
would lead to dangerous overheating.
- The body of this radiator is lled with
a precise quantity of special oil, so that
repairs requiring the opening of the oil
body must only be made by the service
agent. Any oil leakage must be reported
to the Customer Experience, see enclosed
guarantee for details.
- The appliance must not be located
immediately below a xed socket-outlet.
- Do not use the heater in the vicinity of
bathtubs, wash basins, showers, sinks
and swimming pools.
- If the power cable has been damaged, it
must be replaced by the manufacturer
or the technical service centre or by a
qualied person so as to avoid all risks.
- ATTENTION: in order to avoid any danger
caused by an accidental resetting of the
safety system, this appliance must not
be powered through an external timer.
9
Please note:
- Never use the heater to dry laundry.
- Never place the power cable on top of the heater while it is
hot.
- We recommend that you not place the heater in a draught,
because strong draughts of air may adversely aect the
equipment’s operational eciency.
- Only use the heater in an upright position.
- The heater must be positioned at least 50cm from furniture
or other objects.
- The rst time you use the appliance, operate it of at least 15
minutes with the thermostat at maximum to eliminate the
“new” smell. A little smoke due to the protective substances
applied to the heating element before transport may be
given o.
- Do not obstruct the hot air outlet grilles or the air intake
grille on the bottom of the appliance.
- Position the appliance so that the plug and the outlet can
be easily reached even after installation.
- Do not use the appliance in rooms less than 4 m
2
in area.
- The appliance is tted with a safety device which will
switch o it in case of accidental overheating. To reset,
please contact Customer Experience, see enclosed
guarantee.
Danger of burns!!
- The use of an extension lead is not recommended, as
overheating of the extension lead may occur during the
operation of the heater.
The appliance complies with the following EC directives:
- Low Voltage Directive 2006/95/EC and subsequent
amendments;
- EEC Directive 2004/108 on electromagnetic compatibility
(EMC) and subsequent amendments;
Disposing of the appliance
In compliance with European directive 2002/96/EC,
the appliance must not be disposed of with household
waste, but taken to an authorised waste separation and
recycling centre.
DESCRIPTION
A Thermostat
B Power selector
C/D/E Power indicator lights MIN, MED, MAX) (
F Cord holder
G Wheel
USE
Fitting the wheels
Turn the radiator upside down on a rug or soft surface to prevent
damaging the paint nish. Fully unfold the wheels by turning them
outwards (Fig. 1). Turn the radiator back to its upright position.
Caution
Always operate the heater in upright position only (wheels on
the bottom, controls on top).
Any other position could create a hazardous situation.
Location
The heater should not be placed immediately below a power
outlet. Do not use this radiator in rooms with a oor area of less
than 4 m
2
(43 sq. ft. ).
Connection
- Before using the appliance check that your supply voltage
is the same of that shown on the rating label of the unit and
that the power socket and power supply line correspond to
the load specied.
- Check also the current capacity of your fuses. CONNECT
YOUR HEATER TO EARTH PROVIDED SOCKET ONLY.
- This appliance complies with directive 2004/108/ec on
electromagnetic compatibility. Keep loose clothing or
bedding, furniture and ammable material away from the
heater's wall outlet.
Turning on
Insert the plug into an electrical outlet, rotate the thermostat
dial to maximum and turn the unit on as follows using the power
selector:
- Turn the power selector to position MIN to select minimum
output (the min light will be on).
- Turn the power selector to position MED to select medium
output (the min/med lights will be on).
- Turn the power selector to position MAX to select maximum
output (the lights will be on).
Adjusting the thermostat
When the room has reached the desired temperature, turn the
thermostat dial slowly in an anti-clockwise direction until you
hear a "click" and not beyond it. The thermostat will then adjust
Fig. 1
10
the set temperature automatically and keep it constant.
If your unit is a three-output version, in intermediate seasons
or on days when temperatures are not particularly cold, select
minimum output to optimize savings and consumption.
Antifreeze function
Turn the thermostat dial to the position and the power
selector to position MAX. The appliance will maintain a minimum
room temperature of approximately 5°C, thus preventing
freezing while conserving energy. In models that come with a
timer, teeth must be set in the inward position.
Reminder
To completely shut the appliance o, turn the power selector to
the "0" position and then unplug the appliance from the outlet.
UNITS WITH TIMER
How to use the timer
To program heating, proceed as follows:
- Look at the time on your clock or watch. If it is 10 p.m., turn
the numbered timer disk clockwise until the number 22 (10
p.m.) on the disk coincides with the pointer ( ) on the s3
timer. Set the periods of time when you want the appliance
to work by pushing the teeth ( ) inward. Each tooth (1 1)
corresponds to a period of 15 minutes. This will leave
visible sectors which correspond to the periods of operation
(2). When set, the radiator will operate automatically each
day during the times programmed (important: the radiator
must always be plugged into the socket).
- To change the programming, move the teeth back into the
initial position and set the new periods of operation.
- If you want to make the appliance operate without
programming, push all the teeth inward. In this case, to
turn the appliance o completely, as well as turning the
dial to the o position, you must also unplug it from the
power outlet to avoid continued operation of the timer.
IMPORTANT: DO NOT ROTATE CLOCK DIAL COUNTER-
CLOCKWISE.
The timer is like an electric clock, and will only work when
plugged into a power supply. When unplugged, the timer stops
and must be later re-set.
SAFETY DEVICE
A safety device switches the heater o in the event of
overheating. To restart the heater, call the nearest De'Longhi
Customer Service.
MAINTENANCE AND SERVICE
Always unplug the heater from the power outlet and allow the
radiator to cool. Wipe radiator with a soft damp cloth; do not use
detergents or abrasives. Should the radiator not be in use over a
certain length of time, wind the cord around the holder and store
it in a dry place. This appliance has been built to last for many
years of trouble-free service. In case of malfunction or doubt,
do not try to repair the heater by yourself: this might increase
the risk of re and electric shock. Call your nearest De'Longhi
Customer Service (see attached list of Service Centers).
TECHNICAL CHARACTERISTICS
Power supply See rating plate
Absorbed power “
TROUBLESHOOTING
PROBLEM CAUSE SOLUTION
The appliance doesn't work - Be sure it is plugged in and that the
electrical outlet is working.
- Check for any obstruction.
- The temperature may be set too low.
- Plug into the power outlet.
- Remove the obstruction and let the
appliance cool down. If the appliance
doesn't work please contact the nearest
De'Longhi Customer Service.
- Set the temperature to a higher position.
