Seite 1/4

IMPORTANT INFORMATION

Safety warnings

Danger!

Failure to observe the warning may result in life-threatening

injury by electric shock.

- The appliance must not be placed

immediately below a power socket.

- Do not use the heater close to bath,

wash-basin, shower and swimming

pool.

- If you intend to x your appliance to the

wall, make sure that the switch or other

control devices are not within reach of

persons in the bath or shower.

- If the power cable has been damaged, it

must be replaced by the manufacturer

or the service centre or by an expert

sta member so as to avoid all risks.

Important!

Failure to observe the warnings could result in injury or damage

to the appliance.

- The appliance can be used by children

at least 8 years old and by persons with

reduced physical, mental and sensory

capacities or with inadequate experience

and knowledge, as long as they are

carefully supervised or instructed on

how to safely use the appliance and

the hazards involved. Make sure that

children do not play with the appliance.

Cleaning and maintenance performed

by the user must not be performed by

children without supervision.

- Children less than 3 years old should be

kept away from the appliance unless

continuously supervised.

- Children between 3 and 8 years old

may only switch the appliance on and

o, provided that it has been placed

or installed in its normal operating

position, they are carefully supervised

and instructed concerning use of

the appliance in a safe way and they

understand the hazards involved.

Children between 3 and 8 years old

should not insert the plug, adjust

and clean the appliance or perform

maintenance on it. ATTENTION: Some

parts of the appliance can become very

hot and cause burns. Pay particular

attention when children and vulnerable

persons are present.

- ATTENTION: to avoid any danger caused

by an accidental reset of the safety

system, this appliance must not be

powered through an external timer.

- Do not use the appliance in small rooms

when they are occupied by persons that

are not capable of leaving the room on

their own, unless constant supervision

is provided.

Danger of burns!

Failure to observe these warnings may cause burns.

- ATTENTION: to avoid

overheating, do not cover the

appliance for any reason during

operation, this would cause dangerous

overheating.

- The use of an extension lead is not recommended as it

could overheat during operation of the appliance.

Note:

This symbol indicates recommendations and important

information for the user.

- Never use the appliance to dry laundry.

- Do not place the power cable on the appliance when it is

hot.

- For greater eciency position the device away from

draughts.

- Only use the heater in an upright position.

- The appliance must be positioned at a minimum distance

of 80cm from curtains or other movable objects sensitive

to heat.

- The rst time you use the appliance it may emit smells. It

is advisable to let it run for at least 15 minutes with the

thermostat at the maximum setting and then ventilate

the room. A little smoke may be emitted due to the

protective substances applied to the heating element

before transport.

- Do not position the appliance on deep-pile carpets or

rugs, to avoid obstruction to the air intake grille located

under it.

- Do not obstruct the hot air outlet grille or the air intake

grille on the bottom of the appliance.

- Position the appliance so that the plug and the power

socket can be easily reached after installation.

- Do not use this appliance in a room whose surface area is

less than 4 m

- An anti-tilt safety device turns the appliance o if it falls

over or is positioned inappropriately so as to jeopardise

safety. The appliance resumes operation after being

placed in an upright position again.

- The appliance is tted with a safety cuto device

which will switch the appliance o in case of accidental

overheating.

To reset the cuto, disconnect the plug from the power

socket for a few minutes, remove the cause of overheating

then reconnect the appliance. If this abnormal situation

happens several times, contact customer service.

This appliance conforms to the following EC directives:

- Low Voltage Directive 2006/95/EC and subsequent

amendments

- Directive 2004/108/EC on electromagnetic compatibility

(EMC) and subsequent amendments

Disposing of the appliance

The appliance must not be disposed of with household

waste but must be taken to an authorised waste

separation and recycling centre.

DESCRIPTION

A Warning lamp

B Thermostat

C Power selector

D Slider

E Timer

General instructions

Remove the appliance from the packaging.

Check that neither the appliance nor the power cable has

been damaged during transport. Do not operate the heater if

damaged. Remove all publicity material from the appliance.

The appliance is suitable for free-standing or wall-mounted

usage. Do not assemble the feet if wall-mounted.

Electrical connection

- Before connecting the appliance to the power socket,

check that the voltage indicated on the appliance rating

plate is the same as your electrical system and that it can

support the power consumption (Watt) indicated.

- If more than one appliance is used at the same time, it is

important to ensure that the electrical system is able to

support the power required.

Use on the oor, feet assembly

Tools required:

Screwdriver PH2x100 (crosshead)

2 supplied screws 3.5x13 PH ( ) F

Place the appliance on a stable surface.

For mounting the feet, proceed as follows:

- Insert the two hooks in the slots and rotate the foot until

it is engaged as shown in gure 2.

- Insert the two pins in their respective holes.

- Fix the foot with the screw ( ) supplied (gure 3).F

- See Figure 4 for the minimum distances of the device

from the walls. The measurements are indicated both for

models equipped with fan "

and for models without.

Important! never use the appliance without feet if it is

not mounted on the wall.

Installation on the wall

The kit for wall installation contains:

2 metal brackets for mounting above ( )G

2 metal brackets for mounting below ( ) H

2 screws 3.5 x 9.5 PH ( ) I

4 screws 4.5 x 25 PH ( ) J

4 plastic wall plugs 6 x 30 ( ) K

Tools required for installation and estimated time for

installation

Screwdriver PH 2x100 (crosshead)

Estimated time for installation: 30 minutes

Before installing the unit, ensure the following:

a. The device must not be placed directly under a

power socket.

b. The plug and power socket must be easy to reach

after installation.

c. No electric cables or other pipework could be

damaged during installation.

d. Keep away from curtains or ammable materials.

For wall mounting, proceed as follows:

Place the appliance on a stable surface. Use a screwdriver to x

the two brackets with screws as shown in Fig. 6. H I

1. Before drilling the wall, mark the exact spot, respecting

the minimum distances as shown in Fig. 5. The

measurements are indicated both for models equipped

with fan "

and for models without.

2. Drill following the marks that you have made and insert

the wall plugs . For brick walls use a masonry bit K

of 6 mm. For plasterboard or false walls (empty), we

recommend the use of appropriate screws and anchors

(not supplied).

3. Fix the 2 metal brackets to the wall using the screws G J

provided.

4. Hang the appliance on the brackets.

5. Mark the lower xing points corresponding to the holes

of the brackets . Remove the appliance, drill the lower H

holes and insert the wall plugs . K

6. Now you can hang the unit on the brackets and secure the

bottom of the appliance with the 2 screws remaining. J

USE

Operation and use

Insert the plug into the socket and switch on at the socket if

necessary, turn the thermostat knob ( ) to position 6 and turn B

the appliance on via the power selector ( ) as follows: C

• The warning lamp ( ) lights up. A

• Turn the power selector knob to to select minimum Min

power.

• Turn the power selector knob to to select medium Med

power.

• Turn the power selector knob to to select maximum Max

power.

• To switch o the appliance completely: turn the power

selector to "0" and the thermostat to

then disconnect

at the power socket.

Adjusting the thermostat

When the room has reached the required temperature, turn the

thermostat knob ( ) slowly anticlockwise until you hear a click B

and no further. The warning lamp ( ) goes out. A

The thermostat will automatically maintain the temperature.

In spring or autumn or on mild days, you can save energy by

using minimum power.

Freezing protection

With the knob of the thermostat ( ) in position B

and one

of the power levels selected, the appliance will maintain the

room at a temperature of about 5°C preventing freezing with

minimum energy consumption.

Models with fan

The appliance is equipped with a fan that provides even more

rapid and uniform heating.

To start this function, turn the power selector ( ) to Max C

Models with 24-hour timer

When the appliance is connected to the power supply the timer

is always active so as to stay synchronized with the local time.

To operate the appliance without timer, position the timer

slider ( ) to D

To operate the appliance at the times set, position the timer

slider to

(

Fig. 1) and proceed as follows:

• Check the time on your clock or watch. If it is 10.00 for

example, turn the numbered programmer disk until the

number 10 coincides with the pointer marked on the

programmer device.

• Set the periods of time during which you want the

appliance to operate by pushing the teeth outwards (see

gure). Each tooth corresponds to a period of 30 min. At

the end of the procedure, the sectors corresponding to the

periods of operation will be visible.

• In this way, the appliance will function automatically

each day at the times set. (Important: the appliance must

always be connected to the power supply).

• To modify the settings, return the teeth to the initial

position and set the new operating periods.

• To turn the appliance o, turn the power selector to "0".

MAINTENANCE

Before carrying out any maintenance, disconnect the appliance

from the power supply and wait for it to cool down completely.

This appliance requires no particular maintenance.

It is sucient to remove dust with a soft, dry cloth. Never use

abrasive powders or solvents.

If necessary remove areas of concentrated dirt with a vacuum

cleaner.

TECHNICAL CHARACTERISTICS

Power supply See appliance rating plate

Power consumption "

Produktspezifikationen

Marke:	DeLonghi
Kategorie:	Heizung
Modell:	HSX 3320 FTS
Timer:	Ja
Breite:	683 mm
Tiefe:	90 mm
Produktfarbe:	Weiß
Steuerung:	Drehregler
Höhe:	460 mm
AC Eingangsspannung:	230-240 V
AC Eingangsfrequenz:	50 Hz
Typ:	Elektrischer Raumheizlüfter
Leistung:	2000 W
Anzahl der Leistungsstufen:	3
Wärmequelle:	Elektro
Anzeigelicht:	Ja
Griff(e):	Ja
Regelbare Temperatur:	Ja
Überhitzungsschutz:	Ja
Heizleistung:	2000 W
Geeignet für:	Drinnen
Wandmontage:	Ja
Maximale Timer-Zeit:	24 h
Hitzeleistung (min):	800 W
Geeignet bis zu Zimmergrößen von:	60 m³
Frostschutz:	Ja
