Seite 1/8
24702
EN
Original Instructions
Version 1
April 2024
6 - 42V DC
CIRCUIT TRACER
AND DETECTOR
User Manual for: Circuit Tracer And Detector
Stock No: 24702
Part No: ETCT
Read this manual in full before using this product and
retain it for future use. Always use the latest version of
the manual.
Please visit for the drapertools.com/manuals
latest version.
1.
– 2 –
2. Product Introduction
2.1 Intended Use
This product is designed to quickly & eortlessly detects
short & open circuits without damaging the wire insulation.
Equipped with a sensitivity controller & exible probe for
restricted areas. Suitable for automotive fault nding &
repairs on direct currents.
Any other application beyond the conditions established
for use will be considered misuse. Draper Tools accepts no
responsibility for improper use of this product.
This product is suitable for use by enthusiasts and
tradespersons alike.
2.2 Specication
Stock No. 24702
Part No. ETCT
Voltage Range: 6 - 42V DC
Power Supply: 2 x PP3 9V (batteries not supplied)
Net Weight: 186g
Detector Dimensions (L X W X H): 192 X 51 X 34mm
Sender Dimensions (L X W X H): 69 X 63 X 28mm
Flexible Probe Length: 172mm
Flexible Probe Diameter: 5mm
Positive Lead Length: 90mm
Negative Lead Length: 90mm
3. Health and Safety Information
– 3 –
4. Symbols
Important: Read all the Health and Safety instructions before attempting to operate, maintain or repair this product.
Failure to follow these instructions may result in injury or damage to the user, the product or the workpiece.
• ALWAYS follow the instructions and procedures listed
in the vehicle’s service manual before using this
device.
• Exceeding the limits listed in this manual may cause
physical injury or permanent damage to the device,
part and circuits being tested.
• Only for testing DC voltage. connect to NEVER
circuits exceeding DC 42 voltage.
• DO NOT use on AC voltage.
• DO NOT apply to any circuits which directly or
indirectly connect to AC lines or other AC power
sources.
• DO NOT use on ignition system components or
circuits.
• Before using this device check the vehicle’s wiring.
Disconnect any part of the system such as air bags,
electronic control modules etc, which are sensitive to
voltage or current pulses.
• After checking the vehicle, ensure that all the
disconnected connections are correctly restored.
WARNING! DO NOT attempt to repair or service
unless qualied to do so.
• DO NOT allow water inside the case.
• use this device if the tester, leads or probe DO NOT
are damaged in any way or if there is evidence of
battery leakage.
• The battery must be replaced with one with the same
specication.
• When replacing the battery check that it is tted in
the correct +/- orientation.
• DO NOT attempt to repair this device; it contains no
user-serviceable parts.
• Remove the battery when storing the tester for
extended periods.
• DO NOT store in a place of high temperature or
humidity.
Read the instruction manual
Warning!
Do not incinerate or throw onto re
WEEE – Waste Electrical & Electronic Equipment
Do not dispose of Waste Electrical & Electronic Equipment
in with domestic rubbish.
