POWER SUPPLY REQUIREMENTS:

Voltage: 9VDC Current: 500mA

Polarity: Center-Negative

This device comes equipped with an Electro-Harmonix 9.6DC-500

power supply. Use of the wrong adapter or a plug with the wrong

polarity may damage the device and void the warranty. Do not

exceed 10.5VDC on the power plug. Power supplies rated for

less than 500mA may cause the device to act unreliably.

IN THE BOX:

Oceans Abyss

Advanced Reverb Laboratory

9.6VDC / 500mA Power Supply

USB-C Cable

User Reference Manual

Warranty/Compliance Insert

Table of Contents

Quick Start Guide ...............................................................2

Top Panel Controls ..............................................................8

Connections ...................................................................11

OLED Display & Main Views ......................................................13

FX Editor ......................................................................22

FX Block Guide .................................................................26

Tap Divisions ..................................................................34

Global Settings Menu ...........................................................36

Presets .....................................................................37

Expression ..................................................................38

MIDI ........................................................................38

EXT Footswitches ............................................................39

Input/Output. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40

Display .....................................................................40

Preferences .................................................................41

Factory Reset ................................................................41

Firmware ...................................................................41

Specications ..................................................................42

EHXport

™

Computer Application .................................................42

Appendix ......................................................................43

Signal Path Connectors .......................................................43

Global MIDI CC Map ..........................................................44

Reverb CC Map ..............................................................45

Unique Reverb Parameters CC Map ............................................46

FX Loop CC Map .............................................................48

Delay & Modulation CC Map ..................................................48

Utility FX CC Map ............................................................50

Thank you for purchasing the EHX Oceans Abyss. The Oceans Abyss expands on

Electro-Harmonix’s highly acclaimed reverb technology to deliver a truly immersive

FX workstation centered around independently programmable dual reverb engines with

with ten full-stereo reverb algorithms including Hall, Spring, Shimmer, and more. Place

two reverbs into a customizable signal path with additional FX blocks like delay, modu-

lation, gain, and EQ. Featuring 128 presets, a stereo FX loop, expression, MIDI, and USB for

preset creation and management on your PC/Mac. Dive deeper with the Oceans Abyss!
