INTRO |

Hey there, thanks for buying this DIY kit! We – Erica Synths and Moritz Klein – have

developed it with one specific goal in mind: teaching people with little to no prior

experience how to design analog synthesizer circuits from scratch. So what you’ll find in

the box is not simply meant to be soldered together and then disappear in your rack. !

Instead, we want to take you through the circuit design process step by step, explaining

every choice we’ve made and how it impacts the finished module. For that, we strongly

suggest you follow along using LABOR, which is an all-in-one circuit prototyping tool

1

that allows you to experiment and play around with your components in a non-permanent

way. To help you with this, we’ve included suggested breadboard layouts in select

chapters.!

In addition to this, you can also experiment with some of the chapter’s circuits in a circuit

simulatorcalled CircuitJS. CircuitJS runs in your browser. You’ll find weblinks in the

footnotes which will direct you to an instance that already has example circuits set up for

you. We strongly encourage you to fiddle with the component values and general

structure of those circuits to get a better understanding of the concepts we’re laying out.!

Generally, this manual is intended to be read and worked through front to back, but there

were a few things we felt should go into a dedicated appendix. These are general

vignettes on electronic components & concepts, tools, and the process of putting the

module together once you’re done experimenting. Don’t hesitate to check in there

whenever you think you’re missing an important piece of information. Most importantly

though: have fun!!

TABLE OF CONTENTS

CIRCUIT SCHEMATIC ……………………..…………………………………………………."2!

BILL OF MATERIALS ……….……………………………………………………….…..…… "3!

USAGE WITH MKI x ES LABOR …………………………………………………………….."5!

CIRCUIT DESIGN CLOSE-UP …………………………………………………………..…… "7

COMPONENTS & CONCEPTS APPENDIX ……………………………………………..…. "24!

TOOLS APPENDIX ……………………………………………………………………….…… "37!

MODULE ASSEMBLY APPENDIX ……………………………………………………….…. "40!

SOLDERING APPENDIX ………………………………………………………………….….. "52!

TROUBLESHOOTING APPENDIX ………………………………………………………….. 55!

You can also use a standard breadboard, but this will require you to get a little creative when

1

adapting the suggested layouts – plus you’ll need to do some additional engineering to get the

different supply voltages.

1
