PIKOCORE ASSEMBLY MANUAL

Thank you for purchasing Infinite Digits Pikocore XL DIY kit by Erica Synths!

The Pikocore is a lo-fi music mangler based on the Raspberry Pi, developed by Zack Scholl:

https://infinitedigits.co/wares/pikocore/. The original DIY kit comes in a miniature pocket calcu-

lator form factor, and we at Erica Synths wanted to make it more playable, so we reached out to

Zack and agreed to develop an XL version of the Pikocore that has identical functionality, but

comes with a signature Erica Synths hands-on user interface and proper aluminium enclosure.

The Infinite Digits Pikocore XL by Erica Synths is a full DIY kit that includes all required components

to build an instrument and put into action straight away. The RP board in the kit is pre-pro-

grammed and ready to use.

Before you start soldering, we highly recommend printing out the schematics and part placement

diagram with designators and values and to follow the step-by step instructions below. This will

help you to avoid mistakes during the build process. There are two options for +5V regulators on

the PCB – a switching regulator and a linear voltage regulator (LDO). Because the power con-

sumption of the instrument is comparably small, the kit contains components for a linear voltage

regulator. When building the kit, do not populate DA2, C14, C15, C16, L1 and VD4.
