Seite 1/3
car-assistant.pl
FMB010
watches, warns, reminds
GPS vehicle monitoring
GSM communication
warning against possible theft
warning about possible road collision
reminders about important dates
1
WITHOUT FEES
FOR DATA
TRANSFER IN
THE WHOLE
EUROPEAN
UNION!
Your car in the
palm of your hand
car-assistant.pl
Ferguson Sp. z o.o., ul. Dworska 1, 61-619 Poznań, Poland
tel. +48 61 822 05 11, fax +48 61 822 05 59
e-mail: oce@ferguson-digital.eu
www.ferguson-digital.eu
FMB010
is an
alarm system consisting of
a small electronic device and
a free application on the phone.
The sensor is mounted in your
vehicle and connected to the
power supply. It has a permanent
remote connection to the server
and the application over the
cellular network. Thanks to it,
the user receives a number
of functions, eg a theft alarm
with a map or an accident
detection system informing
about a possible collision. The
map and navigation will also
help nd your vehicle left in the
parking lot or in a foreign city.
is an
easy-to-use, real-time tracking
GPS position monitor with
GNSS and GSM connectivity,
which is able to collect device
coordinates and other useful
data for transmission through
the GSM network to the server.
• Plug and follow
• Small and easy to install device - directly
to the car OBDII connector
• Internal GSM and GNSS antenna allowing for
easier (without external antennas) mounting
• Real-time tracking
• Intelligent data collection based on time,
distance, angle, ignition, speed
• Sending the data obtained via GPRS
(TCP/IP and UDP/IP protocols)
• Works in roaming networks
• Current speed
• Over speeding alarm
• Theft alarm
• Information on battery voltage
• Information on switching the ignition on/o
• Battery voltage drop alarm
• Power failure alarm - sabotage
• Alarm for detection of a possible collision
• A reminder about the review
• Reminder about an insurance policy
• Navigation to the vehicle
• Counter of kilometers traveled
• Route history (last 4 months)
• Private/business travel
• Route mapping
• Online application
• Integrated scenarios:
• Excessive speed to protect the driver
and prevent punishment
* Functions dependent on the purchased package - more
information on the website http://car-assistant.pl
car-assistant.pl
Ferguson Sp. z o.o., ul. Dworska 1, 61-619 Poznań, Poland
tel. +48 61 822 05 11, fax +48 61 822 05 59
e-mail: oce@ferguson-digital.eu
www.ferguson-digital.eu
FMB010
Modem
• Name: Teltonika TM2500
• Technology: GSM/GPRS/GNSS
GNSS
• GNSS: GPS, GLONASS, GALILEO, BEIDOU, SBAS, QZSS, DGPS, AGPS
• Receiver: 33 channels
• Tracking sensitivity: -165 dBM
• Accuracy: <3 m
• Hot start: <1 s
• Warm start: <25 s
• Cold start: <35 s
Communication
• Technology: GSM
• 2G band: quad band 850/900/1800/1900 MHz
• Data transfer: GPRS Multi-Slot class 12 (up to 240 kbps)
• Data support: SMS (text/data)
Power
• Input voltage range: 10-30 V DC with overvoltage protection
• Backup battery: 170 mAh 3.7 V Li-Ion battery (0.63 Wh)
Interface
• Digital inputs: 1
• Connector: ODBII socket
• GNSS antenna: internal high gain
• GSM antenna: internal high gain
• USB: 2.0 Micro-USB
• LED signaling: 2 device status LEDs
• Memory: 128 MB internal ash memory
Physical specication
• Dimensions (length x width x height): 50.7 x 49.6 x 25 mm
• Weight: 63 g
Operating environment
• Working temperature: from -25°C to +55°C
• Storage temperature: -40°C to + 70°C
• Operating humidity: 5% to 95% without condensation
• Degree of protection of the housing: IP41
Functions
• Sensors: accelerometer
• Scenarios: current speed, over speeding alarm,
theft alarm, battery voltage, voltage alarm, power
failure alarm - sabotage, accident alarm
Certications
• Regulatory: CE/RED, E-Mark, EAC, RoHS, REACH
EAN: 4779027311722
Packaging: xx pcs
Warning about a possible
trac collision
Too much overload or
impact can be a signal
that an accident has
occurred. The system will ale
and selected people. You wil
immediately see the location
the potential event on the map.
Warning against
possible theft
Each time your car
changes position
without authorization,
you will receive an alarm
about possible theft. You will be able
to follow your vehicle on the map.
Warnings
and echoes
The system noties too
much of the battery
voltage drop. The parental
control function gives
the possibility of warning about
exceeding the set speed limit.
Reminders about
important dates
We took care of other
useful messages,
including ones about
upcoming inspection
dates or scheduled visits to the car
service. The system also makes sure
that the insurance policy is renewed.
