GETTINGSTARTED

FLIR

FLEA®3

GigE



Vision

Willyoursystemsupportthecamera?

RecommendedSystemConfiguration:

nOS—Windows7,LinuxUbuntu

nCPU—IntelCore2Duo,orequivalent

nRAM—2GB

nVideo—PCIExpress128MB

nPorts—GigE

nSoftware—MicrosoftVisualStudio2005SP1andSP1UpdateforVista(to

compileandrunexamplecode)

Doyouhaveadownloadsaccount?

Ourdownloadspagehasmanyresourcestohelpyouoperateyourcamera

effectively,including:

nSoftware,includingDrivers(requiredforinstallation)

nFirmwareupdatesandreleasenotes

nDimensionaldrawingsandCADmodels

nDocumentation

Toaccessthedownloadsresourcesyoumusthaveadownloadsaccount.

1.Gotoourwebsite:www.flir.com/iis.

2.Intheupperrightcorner,clickRegister.

3.Completetheform,thenclickRegister.

Afteryousubmityourregistration,youwillreceiveanemailwithinstructionson

howtoactivateyouraccount.

Doyouhaveallthepartsyouneed?

Toinstallyourcamerayouwillneedthefollowingcomponents:

nEthernetcable

n8-pinGPIOcable

nC-mountLens

nTripodadapter(optional)

nInterfacecard

FLIRsellsanumberoftheadditionalpartsrequiredforinstallation.Topurchase,

visitourAccessoriespage.

CameraCare

Tocleantheimagingsurfaceofyourcamera,followthestepsoutlinedin

KnowledgeBaseArticle10243.

Extendedexposuretobrightsunlight,rain,dustyenvironments,etc.maycause

problemswiththeelectronicsandopticsofthesystem.

Avoidexcessiveshaking,dropping,ormishandlingofthedevice.

Warning!Donotopenthecamerahousing.DoingsovoidstheHardware

Warranty.

Avoidelectrostaticcharging.

InstallingYourInterfaceCardandSoftware

1.InstallyourInterfaceCard

Ensurethecardisinstalledperthe

manufacturer'sinstructions.

ConnecttheinternalIDEorSATApower

connectoronthecardtothecomputer

powersupply.

Alternatively,useyourPC'sbuilt-inhost

controller,ifequipped.

OpentheWindowsDeviceManager.Ensurethecardisproperlyinstalledunder

NetworkAdapters.Anexclamationpoint(!)nexttothecardindicatesthe

driverhasnotyetbeeninstalled.

2.InstalltheFlyCapture®Software

Note:ForexistinguserswhoalreadyhaveFlyCaptureinstalled,we

recommendensuringyouhavethelatestversionforoptimalperformance

ofyourcamera.IfyoudonotneedtoinstallFlyCapture,usethe

DriverControlGUItoinstallandenabledriversforyourcard.

a.Logintoourdownloadspage.

b.SelectyourCameraandOperatingSystemfromthedrop-downlistsand

clicktheSearchbutton.

c.ClickontheSoftwaresearchresultstoexpandthelist.

d.Clicktheappropriatelinktobeginthedownloadandinstallation.

Afterthedownloadiscomplete,theFlyCapturesetupwizardbegins.Ifthe

wizarddoesnotstartautomatically,double-clickthe.exefiletoopenit.Follow

thestepsineachsetupdialog.

3.EnabletheDriversforthecard

Duringinstallation,youarepromptedtoselectyourinterfacedriver.

IntheInterfaceDriverSelectiondialog,selecttheIwilluseGigEcameras.

ThisselectionensurestheImageFilterdriverisinstalledandenabled.

Note:GigEVisioncamerasonLinuxsystemsusenativeUbuntudrivers.

Touninstallorreconfigurethedriveratanytimeaftersetupiscomplete,usethe

DriverControlGUI.

4.ConfigureIPSettings

Afterinstallationiscomplete,theGigEConfiguratoropens.Thistoolallowsyou

toconfiguretheIPsettingsofthecameraandnetworkcard.

IftheGigEConfiguratordoesnotopenautomatically,openthetoolfromStart

Menu>FlyCaptureSDK>Utilities>GigEConfigurator.Ifpromptedtoenable

GigEenumeration,selectYes.

a.Intheleftpane,selecttheLocalAreaConnectioncorrespondingtothe

networkinterfacecard(NIC)towhichthecameraisconnected.

b.Intherightpane,reviewmaximumtransmissionunit(MTU).Ifnot9000,

enablejumboframesontheNICbyclickingOpenNetworkConnections.

(WhilemostNICssupport9000-bytejumboframes,thisfeaturemaybe

disabledbydefault.)

1/13/2017

Namesandmarksappearingontheproductshereinareeither

registeredtrademarksortrademarksofFLIRSystems,Inc.

and/oritssubsidiaries.

©2010-2017FLIRIntegratedImagingSolutionsInc.Allrights

reserved.
