FLIR

LADYBUG

®

5

USB 3.1

30 MP, 360° SPHERICAL CAMERA IMAGING SYSTEM

The Ladybug5 spherical imaging system boasts an impressive 30 MP resolution covering 90%

of a full sphere; a 5 Gbit/s USB 3.0 interface; and a ground-breaking post-processing workow that

provides high dynamic range, superb image quality and maximum user exibility. It is an excellent

choice for applications in geographic information systems (GIS); vehicle-based photogrammetry;

situational awareness; and entertainment solutions for lighting models, full dome projection content,

and other immersive experiences.

POST PROCESSING WORKFLOW

FOR DYNAMIC RANGE

The workow starts with Ladybug5 capturing, compressing,

and transmitting full bit depth 12-bit RAW images. Users then

use LadybugCapPro’s post processing toolbar to apply white

balance, gamma, smear correction, and other image processing

functions for maximum dynamic range.

USER FLEXIBILITY

The capture and post workow model allows users to maintain

exibility by being able to return to the original content and re-

apply post processing steps as desired.

HIGH BANDWIDTH INTERFACE

Leverages USB 3.0 interface that makes 12-bit RAW imaging

possible.

Hardware Development Kit

KEY FEATURES

www.flir.com/iis

MODELVERSIONMPIMAGING SENSOR

LD5-U3-51S5C-44R

LD5-U3-51S5C-44B

Red

Black

30MP(5MPx

6sensors)



SonyICX655CCDx6,2/3",3.45µm



Globalshuer



2048x2448at

10FPS JPEG Compressed

5FPS Uncompressed

A/D Converter12-bit

ImageDataOutput8-,12-,or16-bit,RaworJPEGcompressed

ImageDataFormatsRaw8,Raw12,Raw16inuncompressedandJPEG

ParalImageModesPixelbinningandregionofinterest(ROI)modes

ImageProcessingShuer,gain,whitebalance,gammaandJPEGcompression,areprogrammableviasoware

Shuer

Globalshuer;Automac/manual/one-push/extendedshuermodes

0.02msto2seconds(extendedshuer)

Gain

Automac/manual/one-pushmodesfor8-bitformats;manualmodefor12-bitformats

0-18dB

Gamma0.50to4.00

WhiteBalanceManual

HighDynamicRangeCycle4gainandexposurepresets

DigitalInterfaceUSB3.0withlockingscrewsforsecureconnecon

TransferRates5Gbit/s

GPIO12-pinGPIOconnectorforexternaltriggerinput,strobeoutput,andcamerapower

ExternalTriggerModesStandard,bulb,skipframes,overlapped,andmulshottriggermodes

MemoryChannels2memorychannelsforcustomcamerasengs

CaseMachinedaluminumhousing,anodizedredorblack;singleunit,IP65 cerfied

Dimensions197mmdiameter,160mmheight(withlenshoods)

Mass3.0kg

PowerConsumpon12-24V,13WviaGPIO

MachineVisionStandardIIDCv1.32

CameraControlviaLadybugSDK,CSRs,orthirdpartysoware

CameraUpdatesIn-fieldfirmwareupdates

Opcs6highquality4.4mmfocallengthlenses

FieldofView90%offullsphere

SphericalDistanceCalibratedfrom2mtoinfinity

FocusDistance~200cm.Objectshaveanacceptablesharpnessfrom~60cmtoinfinity

EnvironmentalSensorsTemperature,Barometer,Humidity,Accelerometer,Compass

TemperatureOperang:0°to45°C;Storage:-30°to60°C

HumidityOperang: 20to80%(nocondensaon);Storage:20to95%(nocondensaon)

Compliance

Environmental Protecon

CE,FCC,RoHS

IP65

OperangSystemWindows7orWindows8,64-bitwith8GBRAM

Warranty2Years

Specifications
