Install bulb (Q) (not included) in accordance with the
fixture’s specifications. Do not exceed the recommended
maximum wattage.
2641-01
Carefully remove all contents from the carton. See the
important notes above. Shut off the power at the circuit
breaker and completely remove the old fixture from the
ceiling, including the old crossbar. Remove the crossbar
assembly from the bag. Crossbar (B) contains several
pairs of threaded holes. Find the pair of holes that matches
the spacing of the holes on the junction box and the fixture’s
canopy. Two mounting screws (A) should be attached to
crossbar (B). You may need to tighten nuts (C) to hold these
screws in place. Pull the house wires through the center of
crossbar (B). Place crossbar (B) over the junction box so
that mounting screws (A) are vertical and aligned with
the hole locations on the fixtuer’s canopy (F). Secure
crossbar (B) to the junction box by tightening the screws.
crossbar
crossbar
There are an 18 inch rod (K), a 12 inch rod (L), and a 6 inch
rod (M) included for each fixture. Rod (L) is wired. Determine
the correct number of rods needed for proper hanging height.
To lengthen the fixture, add additional rods. If additional rods
are needed, contact the place of purchase to order. To shorten
the fixture, trim the wires to the desired length, leave at least 8
to 10 inches of wire in addition to the desired hanging length
and discard any excess rods. Keep in mind that you must use
at least the provided 6 inch rod (M) to hang the fixture. Thread
the wires through the rods and pull the wires until taut before
connecting the rods together with connectors (J). Screw bottom
of rod (M) with connector (J) onto nipple (N) on the fixture.
Screw the nipple of the top rod onto swivel post (I) of canopy
(F). Pull the fixture wires through the top of the canopy.
Cover the junction box with canopy (F) by tightening nuts
(H) onto the exposed mounting screws (A).
