Lies die bedienungsanleitung für Gemini GSF10BG (1 Seiten) kostenlos online; sie gehört zur Kategorie Ventilator. Dieses Handbuch wurde von 3 Personen als hilfreich bewertet und erhielt im Schnitt 4.3 Sterne aus 2 Bewertungen. Hast du eine Frage zu Gemini GSF10BG oder möchtest du andere Nutzer dieses Produkts befragen? Stelle eine Frage
Seite 1/1
3、定時設置
在開機狀態下，輕觸定時按鍵 ，可設定風扇定時關機,定時關機採用累計定時方案,
定時總時間長為7小時，每一次按鍵動作增加一個小時定時時間，每按一下,蜂鳴器短響
一聲,對應LED燈點亮:
2、風速調節
開機狀態下，輕觸風速按鍵 ，風扇以一檔...二檔...三檔...一檔...迴圈。
1、開/關機
插上電源，蜂鳴器長響一聲，此為待機狀態，輕觸開關按鍵 ,風扇啟動,風速一檔指
示燈點亮，風扇以低檔風速運行。
在開機狀態下，24小時無操作後，風扇會自動關機。
4、搖頭設置
在開機狀態下，輕觸搖頭按鍵 ，風扇開啟搖頭，再次輕觸搖頭按鍵 ，搖頭關閉。
5、氛圍燈光設置
風扇運轉時，按氛圍燈按鍵 ，可開啟氛圍燈功能。按一次為2檔，按兩次為1檔，按
第三次關閉燈光。 如果關閉風扇，氛圍燈也會相應關閉。
注意：該燈僅用於氣氛照明、放鬆壓力或營造溫馨的環境。請勿將其用作日常照明。
Do not throw this product away with other household waste. When no longer in
use, the product must be sent to the appropriate department for recovery and
recycling. For information about the collection system, please contact your
local government. If electrical appliances are placed in landfills
or garbage dumps, hazardous substances can seep into groundwater and enter
the food chain, damaging your health and life.
1
Please read this instruction manual carefully
before use and keep it for future reference.
請於使用前仔細閱讀本說明書並加以保存。
2
SAFETY INSTRUCTION MAIN PARTS
3
PRODUCT SIZE
4
INSTALLATION METHOD
5
OPERATION INSTRUCTION
6
DISASSEMBLY INSTRUCTIONS
TROUBLE SHOOTING
7
CLEANING MAINTENANCE AND SAFETY MATTERS
Users are not allowed to disassemble or replace the internal components of the fan at will.
If there is a malfunction, they must contact the after-sales service department for repair.
If there are any technical improvements to this product in the future, no further notice will be
given.
If there are any changes to the appearance or color of the product, please refer to the actual
product.
This product has strong wind power, and it is not suitable for infants and elderly people to
blow directly for a long time.
Do not use the mood lighting as daily lighting to avoid danger, please use qualified LED light
as daily lighting usage.
When the power cord or product is found to be damaged or unsafe, please suspend use. It
should be replaced by the factory or its after-sales service agent, or qualified personnel. Do
not repair or inspect it on your own.
Children, elderly people or patients who have lost their ability to take care of themselves
should use this product under adult supervision to prevent accidents.
This product should be placed out of reach of young children and should be properly taught
not to use it as a toy.
To avoid electric shock, no component should come into contact with water.
There should be no objects blocking the air inlet/outlet.
Please use this product in an environment of 0-40 , and do not place the fan in the ° C
bathroom, damp or extremely high temperature areas to avoid damaging the product.
Please keep the fan away from soft objects such as curtains and door curtains to avoid
getting caught inside the fan.
Before cleaning or moving the product, please unplug the power plug.
When the fan is not used for a long time, please unplug the power plug to avoid shortening
the product life and causing accidents or dangers when the product is in standby mode for a
long time.
The product should be kept clean and regularly maintained.
Please do not put your fingers, other body parts or debris into the air inlet/outlet to avoid
injury and damage to the product.
Please do not place wet towels or cloths on the product by hand to avoid electric leakage
and electric shock accidents.
Before removing the protective housing, ensure that the fan is disconnected from the power
supply to avoid accidents during product operation.
If the power cord is damaged, it must be replaced by the manufacturer, its maintenance
department or a professional in a similar department in order to avoid danger.
Timing
Wind speed
Switch
Remote control
Oscillation
Mood lighting
(Please remove the battery insulation strip before first use)
Control panel
Mood lighting
Pole 1
Pole 2
Remote
control
storage
Air inlet network Fan blade Nut Air outlet network
310mm
949mm
310mm
949mm
10" AIR CIRCULATION
TABLE & STAND FAN
GSF10BG
Notice: When installing the fan, do not power on to prevent electric shock accidents.
1.Align column 1 with the chassis threaded hole, align column 2 with the threaded hole of
column 1, align the machine head with the threaded hole of column 2, and rotate clockwise
until it is tightened. (As shown in Figure 1)
2.The column is detachable, and the machine head is directly connected to the chassis for use
as a table fan. (As shown in Figure 2 below)
USER GUIDE
After assembling the fan components according to installation requirements, place the fan on
a stable ground or desktop and plug it into a household power outlet.
After preparation, the fan can be used by turning it on or off.
Stand column 1
Chassis
Stand column 2
Fan main body
Figure 1
Floor standing
state 1
Floor standing
state 2
Desktop
state
or or
Figure 2
1. On/Off
Plug in the power and the buzzer will sound . This is the standby mode. Lightly touch On/Off
button to start the fan. The first speed indicator light will light up, and the fan will run at a low
speed.
When turned on, the fan will automatically shut down after 24 hours of inactivity.
2. Wind Speed Regulation
When turned on, lightly touch the wind speed button , and the fan will cycle from first gear to
third gear in sequence.
3. Timing Setting
In the power on state, lightly touch the timer button to set the fan to shut down at a fixed
time. The timer shut down adopts a cumulative timer scheme, with a total timer time of 7 hours.
Each button action adds one hour of timer time. When pressed, the buzzer will sound briefly,
and the corresponding light will light up.
4. Oscillation Setting
In the power on state, lightly touch the oscillation button to turn on the fan and oscillation.
Then, lightly touch the oscillation button again to turn off the oscillation.
5. Mood Lighting Setting
When running the fan, press the Mood Lighting button to turn on the mood light function.
Press once for 2 gear, press twice for 1 gear, press the third time to turn off the light. If turn off
the fan, mood lighting will be turned off accordingly.
NOTE: The light is only used for mood lighting purpose, relax the stress or make a welcoming
environment. Do not use it as a daily lighting.
Timing button
Wind speed button
Timing light Wind speed indicator light
On/Off button
Oscillation button
Mood lighting button
Instructions for disassembling the air outlet network, install the air outlet net in reverse order
Use a Phillips screwdriver to
rotate clockwise to remove
the protective screw for the
air grille
Rotate the air outlet net
counterclockwise and
unlock the lock of the air
outlet net
Remove the
air inlet net
Use a Phillips screwdriver to
rotate counterclockwise to
remove the protective screw
for the air inlet network
Turn the air inlet net
clockwise to unlock
the air inlet net lock
Remove the air
inlet net
Instructions for disassembling wind blades, install the wind blades in reverse order
Instructions for disassembling the air inlet network, install the air inlet network in reverse order
Rotate clockwise to remove the
fan blade nut
Pull the blade forward and remove
the blade
Front of the wind blade
1.When cleaning, maintenance or moving the product, must first turn off the product and then
unplug the power.
2.The fan must be completely stopped to clean, so as to avoid injury.
3.Do not immerse the power cord or the host in water to clean or wash under the faucet, the
internal parts of the fan do not touch water.
4.Do not use detergent, wire brush, gasoline, alcohol, vinegar or other volatile corrosive liquid
cleaning products, so as not to damage the product.
5.Clean the surface of the fan with a slightly damp cloth.
6.After cleaning, the product must be completely dry before it can be connected
Fault description
Machine
not working
Noise
No light
Cause Analysis
The power cord is not
properly plugged in
The power supply is
disconnected
The switch button is not
pressed
Fan blade cracking
Motor failure
Lamp strip welding
detachment
The light strip lead is not
properly connected
Treatment Measures
Insert the plug properly
Replacing the power supply
Press the switch button again
Replacing fan blade
Replacing motor
Open and inspection light strip
welding position
Check the wiring status of the lead
PRODUCT SPECIFICATION
*The final product specification may be varied according to a different lot of matetial and
actual input voltage power of the usage area.
Product Name
Model Number
Rated Voltage
Rated Frequency
Rated Power
Product size
Net Weight
10" AIR CIRCULATION TABLE & STAND FAN
GSF10BG
AC 220-240V
50-60Hz
30W
949(H) x 310(W) x 310(D) mm
3.38kg
1 2
主要零件 產品尺寸 安裝方法
使用指南
拆卸說明 清潔保養與安全事項操作說明
34567
圖一
圖二
本產品不斷改進中，如功能有所更改，恕不另行通知
如有疑問，請與客戶服務中心聯絡。不便之處，敬請原諒。
The product specifications may be changed without prior notice.
Please contact customer service for details if necessary.
說明書內容以英文版本為準
If there is any inconsistency or ambiguity
between the English version and the Chinese version,
the English version shall prevail.
客戶服務中心 DCH ToolBox Customer Service Centre
香港九龍灣啟祥道 號大昌行集團大廈 樓20 4
4/F, DCH Building, 20 Kai
Cheung Road, Kowloon Bay, Hong Kong
客戶服務熱線 Customer Service Hotline: (852) 8210 8210
電郵地址 E-mail: 8210service@gilman-group.com
網址 Website: www.gilman-group.com
於網上登記新產品保養
Register your product online
www.dchtoolbox.com
保養登記
Warranty Registration
Model No.:
Serial No.:
Dealer:
Date of Purchase:
Invoice No.:
小電維修服務 自攜點 -
Repair Service - Collection Points
用戶不得隨意拆卸更換風扇內部零部件，如有故障，須與售後服務部門聯繫維修。
若本產品日後有技術改進，恕不另行通知。
產品外觀、顏色若有改動，請以實物為准。
個本產品風力強勁，嬰兒、老人不宜長時間直吹。
當電源線或產品發現有破損或不安全時，請暫停使用，應由工廠或其售後服務代理
商，或具有專業資格的人員來更換，切勿自行維修檢查。
小孩、喪失生活自理能力的老人或病人請在成人監護下使用本產品，以防發生意
外。
本產品應放置於幼兒伸手不及之處，並正確教導幼兒，勿將本產品視為玩具使用。
為了避免觸電，任何部件均不能與水接觸。
不能有任何物件阻隔進/出風口。
請在0~40°C環境下使用本產品，不要把風扇放在浴室、潮濕及非常高溫的地方，以
免損壞產品。
請把風扇遠離窗簾、門簾等柔軟物件，以免捲入風扇內。
當清潔或移動產品前，請拔除電源插頭。
當長時間不使用風扇的時候，請拔除電源插頭，以免產品長時間在備用狀態下縮短
產品壽命及造成意外或危險。
產品應保持清潔，及定期保養。
重要安全事項
故障排除
產品規格
進風網 風葉 螺母 出風網
遙控器
收納處
控制面板
燈光
立柱2
立柱1
搖頭
風速
燈光
定時
開關
遙控器
(首次使用請拔出電池絕緣片)
注意:安裝風扇時，禁止通電，以防發生觸電意外。
1、依次將立柱1對準底盤螺紋孔、將立柱2對準立柱1螺紋孔、將機頭對準立柱2螺紋
孔，順時針旋轉直至旋緊。(如下圖一)
2、立柱可拆卸，機頭直接與底盤相連，作為台扇使用。(如下圖二)
機頭
立柱2
立柱1
底盤
或 或
落地式狀態一 落地式狀態二 臺式狀態
請按安裝要求組裝好風扇各部件後，將風扇置於平穩的地面或桌面將變壓器輸入插
頭插入家用電源插座。
準備完畢後，可通過開關使用風扇。
定時指示燈
定時按鍵
搖頭按鍵
風速指示燈
風速按鍵
燈光按鍵
開關按鍵
拆卸出風網說明，安裝方法按拆卸方法逆向操作。
用十字螺絲批順時針旋
轉拆卸出風網保護螺釘
逆時針旋轉出風網解開
出風網鎖扣
拆卸風葉說明，安裝方法按拆卸方法逆向操作。
順時針旋轉，卸風葉鎖母 向前抽拉風葉，拆卸風葉
卸下進風網
拆卸進風網說明，安裝方法按拆卸方法逆向操作。
用十字螺絲批逆時針旋
轉拆卸進風網保護螺釘
順時針旋轉進風網，解
開進風網鎖扣
卸下進風網
風葉正麵
1、當清潔、保養或移動產品前，必須先關閉產品然後拔除電源插頭。
2、必須待風扇完全停止運轉後 ，才能清潔，以免受傷。
3、切勿將電源線或主機浸在水中清潔或在水龍頭下沖洗，風扇內部零件不可沾水。
4、切勿使用清潔劑、鋼絲刷、汽油、酒精、醋或其他揮發腐蝕性液體清潔產品，以免
損壞產品。
5、用微濕的布清潔風扇表面即可。
6、清潔完畢，必須待產品完全乾燥後，才可連接電源使用。
7、如長時間不使用，請將產品收藏回包裝盒內並放置在乾燥陰涼且安全的地方。
故障描述 處理措施原因分析
變壓器未插好
供電體無電
未按壓到開關按鈕
風葉開裂
電機損壞
燈帶焊接脫落
燈帶引線未接好
機器不能工作
異音
不亮燈
接插好變壓器電源線插頭
更換供電體
重新按壓開關按鈕
更換風葉
更換電機
打開檢查燈帶焊接位置
檢查引線接線狀態
10吋空氣循環檯面座地兩用風扇
GSF10BG
AC 220-240V
50-60Hz
30W
949(高) x 310(闊) x 310(深) 毫米
3.38公斤
Produktspezifikationen
| Marke: | Gemini |
| Kategorie: | Ventilator |
| Modell: | GSF10BG |
Brauchst du Hilfe?
Wenn Sie Hilfe mit Gemini GSF10BG benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten
Bedienungsanleitung Ventilator Gemini
1 August 2025
14 Juli 2025
11 Juli 2025
21 Juni 2025
14 Juni 2025
16 August 2024
16 August 2024
15 August 2024
14 August 2024
13 August 2024
Bedienungsanleitung Ventilator
- Home Electric
- Fantini Cosmi
- EasyMaxx
- Defy
- Vortice
- Bestron
- StarTech.com
- Taurus
- H.Koenig
- Sunbeam
- Modern Fan Co.
- Hikoki
- V-TAC
- Goobay
- JAP
Neueste Bedienungsanleitung für -Kategorien-
2 August 2025
2 August 2025
2 August 2025
2 August 2025
2 August 2025
2 August 2025
2 August 2025
2 August 2025
2 August 2025
2 August 2025
