Assembly Instructions: (Manhattan)2243-3P/5

IMPORTANT:

•ALL INSTALLATION WORK SHOULD BE DONE BY ACCREDITED PROFESSIONAL.

•SHUT OFF POWER SUPPLY AT FUSE OR CIRCUIT BREAKER!

•USE ONLY THE SPECIFIED BULBS. DO NOT EXCEED THE MAXIMUM WATTAGE!

PREPARING FOR INSTALLATION

Remove all of the contents from the carton. See the important notes

above. Shut off the power at the circuit breaker and completely remove

the old xture from the ceiling, including the old mounting strap.

1. Take the mounting strap assembly from the parts bag. One end of nipple (F)

should be attached to mounting strap (A) with washer (C) and hex nut (D) in

place. Canopy loop (H) is attached to the other end. Securely attach mounting

strap (A) to the junction box using mounting screws (B) and a screwdriver.

2. Unscrew canopy loop collar (I) from canopy loop (H). Pass canopy (G) over the

mounted canopy loop to test the height. Approximately half of the canopy loop’s

exteriorthreadsshouldbeexposed,andthecanopyloopcollarshouldtsnugly

onto the canopy loop. Remove canopy (G) and adjust the height of nipple (F) and

canopy loop (H) until the desired height is reached.

ASSEMBLING THE FIXTURE

3.Slidecandlesleeves(Q)oversockets(R).Threadthexture’swiresthrough

center rod (O) and connect center rod (O) to the post (M) at the center of the

xture’slampcluster.Attachthetopofcenterrod(O)totoploop(L).Liftcage

(P)upsothatrods(M)andxture’slampcluster(R)isinside.Holdthecageup

and have an assistant attach the bottom hooks of rods (N) to the loops (P) on

the cage. Do not let go of the cage until all rods (N) are attached to loops (P).

Attach the free ends of rods (N) to the holes in top loop (L).

4. By measuring, determine the correct length of chain needed for proper

hanging height. If necessary, use a pair of pliers to open and remove any

excesschain.Attachoneofchainconnectors(K)tochain(J).Passthexture’s

wires through top loop (L). Attach one end of chain connector (K) to top loop

(L)andclosechainconnector(K).Feedthexture’swiresupthroughthe

chain (every three links or so), pulling the wires until taut. Use the free chain

connector (K) to attach chain (J) to canopy loop (H). Slide canopy loop collar

(H) and canopy (G) down onto the chain/wires. Trim the wires to the desired

length plus 8 to 10 inches.

CLEANING TIPS

Treat the xture gently! Regular cleaning will reduce the need for deep cleaning. For regular cleaning, turn off the light and wipe down the

xture with a clean lint-free cotton or microber cloth. Never spray cleaner directly onto the xture.

For Customer Service, please

contact the place of purchase.

CONNECTING THE WIRES

5.Haveanassistantsupportthexture’sweightwhilecompletingthewiring.Refertothewiringdiagramandattachthexture’swiresto

the power supply wires from the junction box. Connect Hot to Hot, Neutral to Neutral, and Ground to Ground. Twist the ends of the wire

pairs together, and then twist on a wire connector. Make sure all twists are in the same direction. If there is no house ground wire coming

fromthejunctionbox,locategroundscrew(E)onthemountingbracket/mountingstrapandwrapthexture’sgroundwirearoundthe

ground screw. Use a screwdriver to tighten the top of ground screw (E) onto the wires and into the mounting bracket/mounting strap.

Tuck the wires into the junction box.

FINISHING THE INSTALLATION

6. Push canopy (G) up to the ceiling and slide canopy loop collar (I) up beneath the canopy. Tightly thread canopy loop collar (I) onto

canopy loop (H) to secure canopy (G) in place.

7.Installlightbulbs(notincluded)inaccordancewiththexture’sspecications.Donotexceedthemaximumrecommendedwattage.

Yourinstallationisnowcomplete.Turnonthepowerandtestthexture.

House Wires

Fixture Wires

Hot

How to Identify the Fixture’s Wires

HotNeutralGround

Smooth

Ribbed

Bare Metal,

Green, or

Green Inner

Thread

Black

White

Black Inner

Thread

White Inner

Thread
