IMPORTANT:

•ALLINSTALLATIONWORKSHOULDBEDONEBYACCREDITEDPROFESSIONAL.

•SHUTOFFPOWERSUPPLYATFUSEORCIRCUITBREAKER!

•USEONLYTHESPECIFIEDBULBS.DONOTEXCEEDTHEMAXIMUMWATTAGE!

PREPARING FOR INSTALLATION

PleaseNote:Thecage,andxturebody(R)arepre-assembled.Removeallofthecontentsfrom

thecarton.Seetheimportantnotesabove.Shutoffthepoweratthecircuitbreakerandcompletely

removetheoldxturefromtheceiling,includingtheoldmountingstrap.Fromthepartsbagremove

themountingstrapassembly.Oneendofnipple(F)shouldbeattachedtomountingstrap(A)with

hexnuts(C,D)inplace.Theotherendshouldhavecanopyloop(H)attached.

Matchthethreadedholesofmountingstrap(A)tothespacingoftheholesonthejunctionbox.

Attachmountingstrap(A)tothejunctionboxusingmountingscrews(B)andascrewdriver.Tighten

securely.Unscrewcanopyloopcollar(I)fromcanopyloop(H).Passcanopy(G)overthemounted

canopylooptotesttheheight.Approximatelyhalfofthecanopyloop’sexteriorthreadsshouldbe

exposed,andthecanopyloopcollarshouldtsnuglyontothecanopyloop.Removecanopy(G)and

adjusttheheightofnipple(F)andcanopyloop(H)untilthedesiredheightisreached.

CLEANING TIPS

Treat the xture gently! Regular cleaning will reduce the need for deep cleaning. For regular cleaning, turn off the light and wipe down the

xture with a clean lint-free cotton or microber cloth. Never spray cleaner directly onto the xture. For deep cleaning, turn off the light

and remove the glass prior to cleaning. Hand wash glass with warm water and mild detergent. Dry with a lint-free or microber cloth.

AssemblyInstructions:(Smyth)2073-4, 2074-4

For Customer Service, contact the

place of purchase.

ASSEMBLING THE FIXTURE

Placexturebody(R)ontoaatsurface.Rod(N)isonthexture’swires,butnot

attachedtothebodyofthexture.Passthexture’swiresthroughrod(N)andpull

thewiresuntiltaut.Twistrod(N)ontothepostatthecenterofthexturebody(R)until

secure.Bymeasuring,determinethecorrectnumberofchainlinksneededforproper

hangingheight.Ifnecessary,useapairofplierstoopenandremoveanyexcesschain.

Attachonechainconnector(K)toeachendofchain(J).Useoneofchainconnectors(K)

toattachchain(J)totoploop(L)andclosethechainconnector.Hooktheendofrod(N)

ontotoploop(L).Pullthewiresthroughtoploop(L).Feedthexture’swiresupthrough

thechain(everythreelinksorso),pullingthewiresuntiltaut.Slidecanopyloopcollar(H)

andcanopy(G)ontothechain/wires.Usethefreechainconnector(K)toattachchain(J)

tocanopyloop(H).

CONNECTING THE WIRES

Haveanassistantsupportthexture’sweightwhilecompletingthewiring.Cutaway

excesswire.Threadthexture’swiresthroughcanopyloopandnipple.Attachthe

xture’swirestothepowersupplywiresfromthejunctionbox.Connectblacktosmooth/

black/transparent(L)wire;whitetoribbed/white/transparent(N)wire;andgroundto

ground(greenorcopper).Twisttheendsofthewirepairstogether,andthentwistona

wireconnector.Makesurealltwistsareinthesamedirection.Ifthereisnogroundwire

(greenorcopper)fromthejunctionbox,locategroundscrew(E)onmountingstrap(A)

andwrapthexture’sgroundwirearoundthegreengroundscrew(E).Useascrewdriver

tosecuregroundscrew(E)ontothemountingbracket/mountingstrap.Tuckallwires

neatlyintothejunctionbox.

FINISHING THE INSTALLATION

Raisecanopy(G)totheceilingandslidecanopyloopcollar(I)upbeneaththecanopy.Tightlythreadcanopyloopcollar(I)ontocanopy

loop(H)tosecurecanopy(G)inplace.

Attachthehooksofrods(M)totoploop(L).Liftcage(P)upsothatrods(M)andxturebody(R)isinside.Holdcage(P)upandhave

anassistantattachthebottomloopsofrods(M)tothehooksinsidecage(P).Donotletgoofthecageuntilallrodsareattachedto

cage(P).Slidecandlesleeves(Q)overthesockets.Installlightbulbs(O)(notincluded)inaccordancewiththexture’sspecications.

Carefullyslideglassshades(S)overcandlesleeves(Q)andsecuretheglassinplacebypushingtheglassdownontothesockettters.

Yourinstallationiscomplete.Turnonthepowerandtestthexture.

Smooth / Black /

Transparent (L)

Black (Hot)

Ribbed / White /

Transparent (N)

Bare Copper / Transparent with

Green Interior / Green

White (Neutral)

Green

(Ground)
