Assembly Instructions: 1323-SF/M3(Ella)
IMPORTANT:
•ALL INSTALLATION WORK SHOULD BE DONE BY ACCREDITED PROFESSIONAL.
•SHUT OFF POWER SUPPLY AT FUSE OR CIRCUIT BREAKER!
•USE ONLY THE SPECIFIED BULBS. DO NOT EXCEED THE MAXIMUM WATTAGE!
For Customer Service, please
contact the place of purchase.
House Wires
Fixture Wires
Hot
How to Identify the Fixture’s Wires
HotNeutralGround
Smooth
Ribbed
Bare Metal,
Green, or
Green Inner
Thread
Black
White
Black Inner
Thread
White Inner
Thread
PREPARING FOR INSTALLATION
Remove all of the contents from the carton. See the
important notes above. Shut off the power at the circuit
breaker and completely remove the old xture from the
ceiling, including the old mounting strap.
1. Mounting strap (A) contains several pairs of threaded holes.
Find the pair of holes that matches the spacing of the holes on
thejunctionboxandyourxture’sbackplate.Keepinmindthat
youwillneedtolineupthekeyholesofmountingstrap(A)with
the holes in canopy (D).
2.Pullthehouse’swiresthroughthecenterofmountingstrap
(A). Place mounting strap (A) over the junction and secure
mounting strap (A) to the junction box with mounting screws
(B) and a screwdriver. Tighten the screws securely. Assemble
canopy (D,E,F) by securing the parts together onto canopy
post (I) using washers (W and H) and nut (G). Twist canopy post
(I)ontopost(V)toconnectthecanopyandxture.
CONNECTING THE WIRES
3.Haveanassistantsupportthextureweightwhile
completing the wiring. Cut away excess wire. Attach the
xture’swirestothepowersupplywiresfromthejunction
box.Connectblacktoblack(orsmooth);whitetowhite(or
ribbed);groundtoground(greenorcopper).Twisttheendsof
thewirepairstogether,thentwistonawireconnector.Make
sure all twists are in the same direction. If there is no ground
wire (green or copper) from the junction box, locate ground
screw(E)onthemountingstrapandwrapthextureground
wire around the green ground screw (E). Use a screwdriver to
securegroundscrew(E)ontothemountingbracket.Tuckall
wires neatly into the junction box.
Please note that this xture may be hung as
a pendant or a semi-ush. Please decide how
you would like the xture to be installed and
refer to the related instructions.
FINISHING THE INSTALLATION
4.Raisecanopy(D,E,F)uptomountingstrap(A).Matchthelocationsoftheholesinthecanopytothekeyholesonmountingstrap(A).
Securecanopy(D,E,F)inplacebythreadingdecorativescrews(C)intothekeyholesonthesidesofmountingstrap(A).Carefullyi
nstall
lightbulbs(notprovided)inaccordancewiththexture’sspecications.Donotexceedthemaximumrecommendedwattage.
5. Refer to the crystal installation sheet and carefully hang crystal strands (O) and (P) as depicted.
6.Arms(L)arenotattachedtothexture’sbody.Threaddecorativescrews(M)intobothposts(N).Threaddecorativenuts(Q)into
bottomcap(R).AttachtheAAcrystaldrop(T)tonial(S).
Yourinstallationisnowcomplete.Turnonthepowerandtestthexture.
FLUSH INSTALLATION
CLEANING TIPS
Treat the xture gently! Regular cleaning will reduce the need for deep cleaning. For regular cleaning, turn off the light and wipe down the
xture with a clean lint-free cotton or microber cloth. Never spray cleaner directly onto the xture.
Please note that there are two different mounting straps included
with the xture. In this conguration, please use the round
mounting strap. Note: post (V) connects directly to canopy post
(I). For pendant installation, please ip the page and review the
diagram for more information).
O
P
R
V
U
S
T
Q
L
N
M
A
C
D
C
B
F
E
I
G
H
W
