www.hager.com
Safety instructions
Electrical equipment must only be installed and assembled by a qualied
electrician in accordance with the relevant installation standards, regulations,
directives and safety and accident prevention directives of the country.
Failure to comply with these installation instructions may result in damage to
the device, re or other hazards.
Function
Switching and dimming of incandescent lamps, high-voltage halogen lamps as well as
dimmable electronic transformers (marked with L, C) with halogen lamps.
Recommendation: Use Osram transformator ET-PARROT 105/220…240 I.
Correct use
-For the ush-mounted installation in standard wall boxes
(recommended wall box depth ≥ 35 mm).
-Only suitable for use in indoor areas with no drip and no spray water.
Product characteristics
-Dimming principle: phase cut-on
-Change-over switch in combination with change-over switch possible.
-Short-circuit proof and overload proof
Technical data
Rated voltage: 230 V~
Frequency: 50/60 Hz
230 V incandescent and halogen lamps: 40 ... 500 W
Electronic transformers (marked with L,C): 40 ... 250 W
Conductor cross-section of screw terminals: max. 3 x 1.5 mm²
Distance of xing holes: 60.3 mm
Operating temperature: -5 ... +45 °C
Relative humidity (without condensation): 5 ... 95 % (at 25 °C)
Standards: BS EN 60669-2-1, IEC 60669-2-1
Mixed operation of 230 V incandescent and halogen lamps as well as electronic
transformers (marked with L,C until smallest maximum load possible.
40-500W Single dimmer
Hager Muse / Hager Inspire
Installation and operating
instructions
