Seite 1/3
51mm
MIN.
CLEARANCE
6"
152mm
3 1/4"
Ø3/32"
2.4mm
(REF.)
SINK
PIN
3-1/4"
83mm
83mm
3-3/4"
95mm
16-7/8"
429mm
7"
178mm
1/2" O.D.
SUPPLY (COLD)
16-1/2"
419mm
LOCKNUT
2-3/8"
60mm
2"
WALL
Ø 7/8"
22mm
ROLL
3
5
3
CAP
38mm
1-1/2" MAX.
SET
SCREW
SEAL BASE WITH
SILICONE CAULK
1. WHEN INSTALLING THIS UNIT, LOCAL, STATE, OR FEDERAL CODES SHOULD BE
ADHERED TO FOR INSTALLATION DIMENSIONS (LOCATIONS), WASTE AND SUPPLY
REQUIREMENTS OTHER THAN SHOWN.
2. THE ANSI Z358.1-2009 STANDARD SPECIFIES EYEWASH NOZZLE HEIGHTS TO BE
83.8cm (33 IN.) TO 114.3cm (45 IN.) ABOVE THE FLOOR AND 15.3cm (6 IN.) MINIMUM
FROM WALL OR NEAREST OBSTRUCTION.
3 DRILL ONE Ø7/8" [22mm] HOLE AND ONE Ø3/32" HOLE WHERE UNIT IS TO BE
INSTALLED. REFER TO MOUNTING HOLE DETAIL.
4. THESE DIMENSIONS MAY VARY ±1/2" [6.4mm].
5 ASSEMBLE EYE/FACE WASH TO ARM, ORIENT TAB ON ASSEMBLY AWAY FROM USER.
APPROVED:
DRAWN:
PART NUMBER
SCALE:
SHEET OF
REVISION
DRAWING TYPE: SIZE: A
BY:ECN NO.
DATE:
DATE:
ECN:
REVISED PER
CHK'D.:
Haws Corporation - All Rights Reserved.
HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
C
R
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
(775) 359-4712 FAX (775) 359-7424
E-MAIL: HAWS@HAWSCO.COM
WEBSITE: WWW.HAWSCO.COM
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
JF
10/96
16
0002080067.D
7610
PULLDOWN EYE/FACE WASH
1:1
1 3
FV
08/01/16
2066
VWC
INSTALLATION
5113
2016
CC
2X 0.53"
13.5mm
2X Ø 1/8"
3.18mm
2X 0.53"
13.5mm
3-3/4"
95mm
7"
178mm
1/2" O.D.
SUPPLY
(COLD)
WALL
3
5
1-1/2" MAX.
38mm
33" TO 45"
83.8cm TO 114.3cm
16-1/2"
419mm
STEP 1
STEP 2
WALL MOUNT
DECK MOUNT
OFF POSITION
OFF POSITION
BASE
SET
SCREW
EYEWASH
CONTROL
VALVE
SEAL BASE WITH
SILICONE CAULK
NOTE DEPTH OF SET SCREW PRIOR TO LOOSENING.
LOOSEN SET SCREW AND ROTATE EYEWASH ARM 90
DEGREES CLOCKWISE (AS SHOWN) WHILE MAKING
SURE TO NOT ROTATE THE SPOOL. RETIGHTEN SET
SCREW IN NEW POSITION. ENSURE SET SCREW IS
PROPERLY SEATED IN THE INDENT. MAKE SURE THE
SET SCREW IS TIGHT AND AT ITS ORIGINAL DEPTH.
ENSURE CORRECT ARM ORIENTATION BEFORE
MOUNTING TO WALL. REFERENCE DRAWINGS AT RIGHT.
BASE
SET
SCREW
SPOOL
UNIT IS SHIPPED IN DECK MOUNT CONFIGURATION. TO
CONVERT TO WALL MOUNT CONFIGURATION, POSITION
ARM IN "DECK MOUNT OFF POSITION" AS ABOVE.
1"
25.4mm
CAP
16-7/8"
429mm
1/2"
12.7mm
SET
SCREW
3-1/4"
83mm
OFF POSITION
DECK MOUNT
FLOOR
LINE
FLOOR
LINE
1. WHEN INSTALLING THIS UNIT, LOCAL, STATE, OR FEDERAL CODES SHOULD BE
ADHERED TO FOR INSTALLATION DIMENSIONS (LOCATIONS), WASTE AND SUPPLY
REQUIREMENTS OTHER THAN SHOWN.
2. THE ANSI Z358.1-2009 STANDARD SPECIFIES EYEWASH NOZZLE HEIGHTS TO BE
83.8cm (33 IN.) TO 114.3cm (45 IN.) ABOVE THE FLOOR AND 15.3cm (6 IN.) MINIMUM
FROM WALL OR NEAREST OBSTRUCTION.
3 DRILL ONE Ø7/8" [22mm] HOLE AND ONE Ø3/32" HOLE WHERE UNIT IS TO BE
INSTALLED. REFER TO MOUNTING HOLE DETAIL.
4. THESE DIMENSIONS MAY VARY ±1/2" [6.4mm].
5 ASSEMBLE EYE/FACE WASH TO ARM, ORIENT TAB ON ASSEMBLY AWAY FROM USER.
APPROVED:
DRAWN:
PART NUMBER
SCALE:
SHEET OF
REVISION
DRAWING TYPE: SIZE: A
BY:ECN NO.
DATE:
DATE:
ECN:
REVISED PER
CHK'D.:
Haws Corporation - All Rights Reserved.
HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
C
R
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
(775) 359-4712 FAX (775) 359-7424
E-MAIL: HAWS@HAWSCO.COM
WEBSITE: WWW.HAWSCO.COM
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
JF
10/96
16
0002080067.D
7610
PULLDOWN EYE/FACE WASH
1:1
2 3
FV
08/01/16
2066
VWC
INSTALLATION
5113
2016
CC
Ø 7/8"
22mm
2X 0.53"
13.5mm
2X Ø 1/8"
3.18mm
2X 0.53"
13.5mm
3
FLOOR
LINE
1. WHEN INSTALLING THIS UNIT, LOCAL, STATE, OR FEDERAL CODES SHOULD BE
ADHERED TO FOR INSTALLATION DIMENSIONS (LOCATIONS), WASTE AND SUPPLY
REQUIREMENTS OTHER THAN SHOWN.
2. THE ANSI Z358.1-2009 STANDARD SPECIFIES EYEWASH NOZZLE HEIGHTS TO BE
83.8cm (33 IN.) TO 114.3cm (45 IN.) ABOVE THE FLOOR AND 15.3cm (6 IN.) MINIMUM
FROM WALL OR NEAREST OBSTRUCTION.
3 DRILL ONE Ø7/8" [22mm] HOLE AND ONE Ø3/32" HOLE WHERE UNIT IS TO BE
INSTALLED. REFER TO MOUNTING HOLE DETAIL.
4. THESE DIMENSIONS MAY VARY ±1/2" [6.4mm].
5 ASSEMBLE EYE/FACE WASH TO ARM, ORIENT TAB ON ASSEMBLY AWAY FROM USER.
APPROVED:
DRAWN:
PART NUMBER
SCALE:
SHEET OF
REVISION
DRAWING TYPE: SIZE: A
BY:ECN NO.
DATE:
DATE:
ECN:
REVISED PER
CHK'D.:
Haws Corporation - All Rights Reserved.
HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
C
R
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
(775) 359-4712 FAX (775) 359-7424
E-MAIL: HAWS@HAWSCO.COM
WEBSITE: WWW.HAWSCO.COM
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
CC
07/07/16
16
0002080067.D
7610
PULLDOWN EYE/FACE WASH
1:1
3 3
FV
08/01/16
5113
FV
INSTALLATION
5113
2016
CC
Ø 7/8"
22mm
2X 0.53"
13.5mm
2X Ø 1/8"
3.18mm
2X 0.53"
13.5mm
OFF
SINK
(REFERENCE)
5"
127mm
MIN. CLEARANCE
RADIUS FOR
FACEWASH STREAMS
6" (152mm) MIN.
CLEARANCE
ON
