AM-1 Series

™

THERMOSTATIC MIXING VALVES

SUBMITTAL SHEET

APPLICATION

The Honeywell AM-1 series accurately adjusts, maintains, and limits the hot water temperature to a desired setting selected by

the user. By installing a Honeywell AM-1 mixing valve, raising water heater storage temperature setting, and limiting mixed outlet

water temperature to a safe temperature, more usable hot water is available.

Specications

Design: Straight-Through (hot and cold at the same level)

Maximum Pressure: 150 psi (1034 kPa)

Certications: ASSE, CSA and IAPMO listed

Patent Information: U.S. Patent No. 6,079,625

Warranty: 1 year limited warranty

Materials

Body:Teon

®

-Coated, Nickle-Plated Brass

Shuttle: Teon

®

-Coated Brass

O-Rings: EPDM RUbber

**Lead free models available, add LF to the end of the part

(Example, AM100-1LF)

Model Number

Pipe

Size

Operating

Temp

Cv

ASSE

Certs.

Dimensions

ABC

NPT

AM100-11/2”70°F - 145°F3.210175.82.73

AM101-13/4”70°F - 145°F3.810175.82.73

AM102-11”70°F - 145°F4.310175.82.73

AM100C-11/2”70°F - 120°F3.210175.82.73

AM101C-13/4”70°F - 120°F3.810175.82.73

AM102C-11”70°F - 120°F4.310175.82.73

Union Sweat

AM100-US-11/2”70°F - 145°F3.910175.72.74.4

AM101-US-13/4”70°F - 145°F3.910175.72.94.9

AM102-US-11”70°F - 145°F3.910175.73.56.1

AM100C-US-11/2”70°F - 120°F3.910175.72.74.4

AM101C-US-13/4”70°F - 120°F3.910175.72.94.9

AM102C-US-11”70°F - 120°F3.910175.73.56.1

AM100R-US-11/2”70°F - 180°F3.9N/A5.72.74.4

AM101R-US-13/4”70°F - 180°F3.9N/A5.72.94.9

AM102R-US-11”70°F - 180°F3.9N/A5.73.56.1

AM100C1070-US-11/2”70°F - 120°F1.81017, 10705.72.74.4

AM101C1070-US-13/4”70°F - 120°F1.81017, 10705.72.94.9

Union CPVC

AM100-UCPVC-11/2”70°F - 145°F3.910175.82.84.7

AM101-UCPVC-13/4”70°F - 145°F3.910175.82.84.7

AM100C-UCPVC-11/2”70°F - 120°F3.910175.82.84.7

AM101C-UCPVC-13/4”70°F - 120°F3.910175.82.84.7

AM100C1070-UCPVC-11/2”70°F - 120°F1.81017, 10705.82.84.7

AM101C1070-UCPVC-13/4”70°F - 120°F1.81017, 10705.82.84.7

Model Number

Pipe

Size

Operating

Temp

Cv

ASSE

Certs.

Dimensions

ABC

Union Threaded

AM100-UT-11/2”70°F - 145°F3.910175.92.94.9

AM101-UT-13/4”70°F - 145°F3.910176.63.86.5

AM102-UT-11”70°F - 145°F3.910176.83.97

AM100C-UT-11/2”70°F - 120°F3.910175.92.94.9

AM101C-UT-13/4”70°F - 120°F3.910176.63.86.5

AM102C-UT-11”70°F - 120°F3.910176.83.97

AM100R-UT-11/2”70°F - 180°3.9N/A5.92.94.9

AM101R-UT-13/4”70°F - 180°3.9N/A6.63.86.5

AM102R-UT-11”70°F - 180°3.9N/A6.83.97

AM100C1070-UT-11/2”70°F - 120°F1.81017, 10705.92.94.9

AM101C1070-UT-13/4”70°F - 120°F1.81017, 10706.63.86.5

AM102C1070-UT-11”70°F - 120°F1.81017, 10706.83.97

Union PEX

AM100-UPEX-11/2”70°F - 145°F3.910176.03.05.1

AM101-UPEX-13/4”70°F - 145°F3.910176.03.05.1

AM100C-UPEX-11/2”70°F - 120°F3.910176.03.05.1

AM101C-UPEX-13/4”70°F - 120°F3.910176.03.05.1

AM100R-UPEX-11/2”70°F - 180°F3.9N/A6.03.05.1

AM101R-UPEX-13/4”70°F - 180°F3.9N/A6.03.05.1

AM100C1070-UPEX-11/2”70°F - 120°F1.81017, 10706.03.05.1

AM101C1070-UPEX-13/4”70°F - 120°F1.81017, 10706.03.05.1

Job Name

Engineer

Mechanical Contractor

Contractor’s P.O. No.

Representative

Notes

Model(s)

Qty. Notes

Qty. Notes

Qty. Notes

Approval

Service

Tag No.

M33965

A

B

C

A

B

3-5/32

(80)

C

NPT

UNION

68-3098-01

®

CU

S

U

P

C

®

Dimensions
