Seite 1/12
FR - MANUEL D'UTILISATION - P. 3
DE - BEDIENUNGSANLEITUNG - S. 5
NL - HANDLEIDING - P. 6
ES - MANUAL DE USO - P. 7
SI - NAVODILA ZA UPORABO - S. 8
RO - MANUAL DE UTILIZARE - P. 10
FUNCTION DESCRIPTION & CHANNEL CHART - P. 11
Ref.
LEDSPOT10W (15-1097)
LED SPOT LIGHT
MANUAL
Imported from China by LOTRONIC S.A.
Avenue Zénobe Gramme 9
B-1480 Saintes
View the item on our website
Manual - LEDSPOT10W
2
©Copyright LOTRONIC 2019
INSTRUCTION MANUAL
EXPLANATION OF SYMBOLS
The unit complies with CE standards
For indoor use only
Don’t stare into the light beam
SAFETY INSTRUCTIONS
• Please read these instructions carefully, they include important information about the installation, usage and
maintenance of this product.
• Always make sure that you are connecting to the proper voltage, and that the line voltage you are connecting
to is not higher than that stated on the decal or rear panel of the xture.
• This product is intended for indoor use only!
• To prevent risk of re or shock, do not expose xture to rain or moisture. Make sure there are no ammable
materials close to the unit while operating.
• The unit must be installed in a location with adequate ventilation, at least 50cm from adjacent surfaces. Be
sure that no ventilation slots are blocked.
• Maximum ambient temperature (Ta) is 40°C. Do not operate the xture at temperatures higher than this.
• In the event of a serious operating problem, stop using the unit immediately. Never try to repair the unit by
yourself. Repairs carried out by unskilled people can lead to damage or malfunction. Please contact the near
-
est authorized technical assistance center. Always use the same type of spare parts.
• Avoid direct eye exposure to the light source while it is on.
• The product is for decorative purposes only and not suitable as a household room illumination.
• The light source of this device is not replaceable. If it is defective, the entire unit must be discarded.
FEATURES:
• Display of running time
• Temperature control
• Manual Focus
HOW TO CONTROL THE UNIT
Access control panel functions using the four panel buttons located directly underneath the LCD Display.
Button Function
MENU Used to access the menu or to return to a previous menu option
UP Scrolls through menu options in ascending order
DOWN Scrolls through menu options in descending order
ENTER Used to select and store the current menu or option within a menu
MOUNTING
1. The spot light can be put everywhere, but you must leave a distance of at least 0.5m between the spot light
and an object. Keep the light stable
2. Connection to a DMX controller: The DMX512 signal must be connected to the INPUT and OUTPUT sockets
of the unit. Keep the cable run as short as possible in order to avoid signal losses and interference from other
units. The cable length should not be longer than 100m.
3. Use an standard 3-pin XLR lead to connect the unit to a DMX controller. The XLR connector is wired as
follows:
XLR WIRING
Pin 1 = Ground
Pin 2 = Data Compliment (negative)
Pin 3 = Data True (positive)
4. The focus can be set manually.
5. Display of running time (Press Down and Enter button)
UP
DOWN
MENU ENTER
8.8.8.8.
