Seite 1/12

10/100/1000 Base-T

to Gigabit Fiber

Media Converter

DA-MC1101

Operation Manual

Before Using the Product

FCC Compliance Statement

This device complies with part 15 of the FCC Rules.

Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and

(2) This device must accept any interference received,

including interference that may cause undesired operation.

Note: This equipment has been tested and found to comply with the limits for a Class A

digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference when the equipment is operated in a

commercial environment.

This equipment generates, uses and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions, may cause harmful interference to

radio communications. Operation of this equipment in a residential area is likely to cause

harmful interference in which case the user will be required to correct the interference at

his own expense.

User’s Caution Statement

Caution: Any changes or modifications to the equipment not expressly approved by the

party responsible for compliance could void your authority to operate the equipment.

Product Overview

DA-MC1101 is designed to fulfill requirements for forming a Gigabit network, and can

extend a connection up to 10KM using fiber optic cables.

The LED indicators located on the front panel of DA-MC1101 shows the operating status

of the product.

Product Features

●Supports automatic negotiation feature

●Supports automatic MDI/MDI-X detection

●Supports LED status indicators

●Mode switching using DIP switches

Accessories

The product consists of the following components.

Power FDX

Status

Speed

Diag

Link / Act

Main Unit (DA-MC1101)

5V DC adapter Operation Manual

Overview

Front

LED indicators

RJ45 port

SFP Slot

Power FDX

Status

Speed

Diag

Link / Act

Produktspezifikationen

Marke:	IDIS
Kategorie:	Nicht kategorisiert
Modell:	DA-MC1101
Breite:	71 mm
Tiefe:	94 mm
Gewicht:	160 g
Produktfarbe:	Black, Red
Übertragungstechnik:	Kabelgebunden
Höhe:	26 mm
Betriebstemperatur:	0 - 50 °C
Zertifizierung:	FCC, CE, KC
Stromverbrauch (Standardbetrieb):	3.4 W
Anzahl Ethernet-LAN-Anschlüsse (RJ-45):	1
Maximale Datenübertragungsrate:	1000 Mbit/s
LED-Anzeigen:	Status
Auto MDI/MDI-X:	Ja
Ethernet Schnittstellen Typ:	Gigabit Ethernet
Eingangsspannung:	5 V
Eingangsstrom:	1.6 A
Maximal mögliche Übertragungsstrecke:	100 m
unterstütze Kabeltypen:	Cat5
Wellenlänge:	- nm
Optischer Kabelverbinder:	SFP
Converter Eingangsschnittstelle:	10Base-T, 100Base-T, 1000Base-T
Converter output Oberfläche:	1000Base-LX, 1000Base-SX
