Seite 1/2
Series LED User Guide
Note:The technical data are subject to change without notice.
OYB5
What’s Included
Safety Instructions
1 x OYB5 Light Fixture
1 x Power Adapter
1 x Power Cord
1 x Barn Door
1 x Yoke
1 x Light Bag
1 x Dual Battery Charger
2 x Batteries
1. When using the light, check that the environment is dry and well-ventilated.
2. Do not expose the fixture to rain or moisture.
3. The voltage should not exceed the recommended values.
4. Do not look directly at the light bulbs with naked yes when the light is on.
5. Do not place the light near flammable or volatile solvents such as alcohol or gasoline.
6. Please disconnect the power if the light not used for an extended period of time
7. If the light fixture is not working normally, please contact Ikan. The product should be
only be repaired by a qualified technician.
Please do not dissemble/re-assemble.
Product Information
Overview
Specifications
Thank you for buying the Onyx 5 Bi-Color Aluminum LED Light from Ikan. Please carefully
read the guide before operating the product.
The Onyx Half x 1 Bi-Color Aluminum LED light is fitted with 900 high quality LED lights. The
aviation grade aluminum panel design allows for better heat ventilation. The OYB5 provides a
flicker-free experience when adjusting the brightness (10%-99%) and color temperature
(3200K-5600K). The OYB5 can be controlled remotely with either the included remote control
or DMX via the Ethernet port. Having the option of being powered either by the power adapter
or two Sony “L” style batteries, the OYB5 can meet both your studio or on the field needs.
Ethernet DMX ports
1
3
4
2
5
6
11
10
13
12
7
8
9
Vents
2.4G Antenna
LED display
Yoke locking knobs
Adjustment knob
Power switch
Yoke
Power socket
DMX/remote
control switch button
Battery location
Channel button
Battery check button
5
6
12
7
9
1
2
3
4
10
8
11
Vents
2.4G Antenna
LED display
Yoke locking knobs
Adjustment knob
Power switch
Power socket
DMX/remote control switch button
Press "DIMMER/COLOR", when the “DIMMER” light is on, the adjustment knob increases or decreases the brightness.
When the “COLOR” light is on, the adjustment knob increases or decreases the color temperature.
RJ45 interface connection, can support the DMX512.
DMX socket
Battery location
Battery check button
Channel button
Press the "CHANNEL" button to toggle the option for the knob adjust the wireless or DMX512 channels.
Press the “Battery” button to view the battery life remaining in batteries. (Only when batteries are in use)
Press the "DIMMER/COLOR" button twice to enter full power under 4400K color temperature model,
the adjustment knob to adjust the brightness 10 ~ 99%.
Full Power Mode
Model OYB5
Output Power 54W
Luminous Flux 6480 LM
LED Quanty 900
Color Temperature 3200K - 5600K
Color Rendering Index ≥ 95
Dimmer 10% - 99%
Remote Control 99 Channels 2.4G Wireless Remote Control
Remote Control Distance 150 feet
DMX512 Yes (Ethernet interface)
Baery Type Sony "L" Style Baeries
DC Power Input DC13-19V
Fixture Size 14.5 x 11 x 1.75 in.
Fixture Weight 4 lbs
When the "DMX" corresponding indicator light is on only DMX controller can be controlled.
When the "2.4G" corresponding indicator light is on either the 2.4 G remote control or manual control can be used.
