FIND YOUR USER GUIDEONLINE!

Go to www.insigniaproducts.com, then click

Support & Service.

Enter NS-HBTSS116 in the box under Manual,

Firmware, Drivers & Product Information, then click ►.

QUICK SETUP GUIDE

Bluetooth

Shelf

Speakers

NSHBTSS116

RECONNECTING TO A PAIRED DEVICE

When your speaker is not paired to a device, the LED

blinks blue slowly.

PAIRING A BLUETOOTH DEVICE

SUPPORTING NFC

If your Bluetooth device supports Near Field

Communication (NFC), make sure that the NFC feature

is active. Touch the NFC area of your Bluetooth device

to the top of your NS-HBTSS116 speaker to

automatically pair.

Note: If your phone has NFC support but it is running an OS

below Android 4.1, you need to download an NFC Bluetooth

app from Google Play or a similar online store.

LISTENING TO MUSIC

1Make sure that the speaker is paired with your

Bluetooth device (the LED indicator is solid blue).

2Begin playback on your Bluetooth device.

3Adjust the volume on your speaker by rotating the

Volume Standby/source +knob, or pressing the or

– buttons on your remote control or your Bluetooth

device.

: Use the controls on your Bluetooth device or on Note

the remote control to control playback.

CONNECT THE SPEAKERS

Connect the power cable

Plug the power cable into a power outlet or surge

protector.

Connect the speakers

Speakers are connected using the speaker wire that is

provided. Connect the red wire to the red (+) terminals

and the white wire to the black (-) terminals. Use enough

wire to position the speakers where you want them.

TURNING YOUR SPEAKER ON AND OFF

Toggle the switch on the side of your speaker to ON/OFF

the position. The LED indicator blinks. Press the ON

Volume Standby/source knob repeatedly to cycle

through the available modes (AUX, RCA, and Bluetooth),

or press the button on the remote control to select the

mode you want.

CONNECTING WITH BLUETOOTH

1Make sure that your Bluetooth device is turned on and

within 33 feet (10 meters) of your speaker.

2Press the Volume Standby/source knob on the side

of your speaker to cycle to Bluetooth mode or press

the Bluetooth button on the remote control to enter

Bluetooth mode. Your speaker enters pairing mode

and the LED indicator blinks blue.

3Turn on your Bluetooth device and turn on Bluetooth.

Set your device to pairing mode, then select

NS-HBTSS116. See the instructions that came with

your Bluetooth device for information about pairing.

40000If you are asked for a password, enter . When

pairing is complete, the LED indicator lights solid blue.

5To disconnect from the paired Bluetooth device, press

and hold (Bluetooth button) on your remote

control for three seconds. Your speaker disconnects

from the Bluetooth device and enters pairing mode

again.

OVERVIEW

Remote control

Your speaker loses

the Bluetooth

connection if you...

Turn o your speaker

or put in standby/AUX/RCA

mode

Move the Bluetooth device out

of range.

Turn o your Bluetooth device.

Turn o Bluetooth on your

Bluetooth device.

Connect your Bluetooth device

to another Bluetooth device.

To reconnect...

Turn on your speaker and cycle to Bluetooth

mode. Your speaker searches for the last

connected Bluetooth device and reconnects.

Make sure that your Bluetooth device is within

33 feet of your speaker.

Turn on your Bluetooth device, then make sure

that Bluetooth is turned on.

Turn on Bluetooth on your Bluetooth device.

Disconnect your Bluetooth device from the other

Bluetooth device, then set your device to pairing

mode. Select NS-HBTSS116on your Bluetooth

device.

# ITEM

1Volume

Standby/source

knob

2Treble knob

3Bass knob

4On/O switch

5LED Indicator

DESCRIPTION

Press repeatedly to cycle through the available modes

(AUX [default], RCA, and Bluetooth).

Hold down knob to put your speakers in standby mode or

to resume the last mode that was played.

Turn clockwise to increase the volume and turn

counterclockwise to decrease the volume.

Adjusts the treble level.

Adjusts the bass level.

Turns the power on or o.

Indicates the mode (Standby, AUX, and RCA) and pairing

status of the speakers.

POWER

MUTE

VOL

AUX

RCA

SOURCE

Before using your new product, please read these instructions to prevent any damage.

# ITEM

1POWER

2AUX

3Previous

4MUTE

5RCA

6 Bluetooth button

7Next

8Play/Pause

9VOL +

10VOL -

DESCRIPTION

Press to turn on/o standby mode.

Press to enter AUX mode. The green LED indicator light

blinks slowly.

Press to select the previous song while in Bluetooth

mode.

Press to mute or unmute the sound.

Press to enter RCA mode. The green LED indicator

lights solid.

Press to enter Bluetooth mode. The LED indicator

blinks blue.

Press to select the next song while in Bluetooth mode.

Press to play/pause while in Bluetooth mode.

Press to turn the volume up.

Press to turn the volume down.

LED indicator

Blinks green

Solid green

Blinks blue

Solid blue

Solid red

MODE

AUX mode

RCA mode

Bluetooth pairing mode

Bluetooth is paired

Standby mode

Power cable

Speaker Wire

USB 5V 1A

12060Hz

A

INPUT

LSPEAKER

OUTPUT

AUX

OUTPUT

SUB

L

R

RCA

NSHBTSS116RC

Standby/source

PACKAGE CONTENTS

• Speakers (2)

• 4.9 ft. (1.5 m) 3.5 mm audio cable

• 4.9 ft. (1.5 m) RCA cable

• 6.6 ft. (2 m) speaker wire

• Remote control with batteries

• Quick Setup Guide

FEATURES

• Wirelessly stream from any Bluetooth device

• Volume, treble, and bass controls on the side panel

• NFC for easy Bluetooth pairing

• Highly ecient, energy saving design for low power

consumption
