CAN@net II
Intelligent PC/CAN Interface
USER MANUAL
E NGLISH
HMS Technology Center Ravensburg GmbH
Helmut Vetter- -Straße 2
88213 Ravensburg
Germany
Tel.: +49 751 -0 56146
Fax: +49 - 751 56146 29
Internet: www.hms- networks.de
E- - -n Mail: info ravensburg@hms etworks.de
Support
For problems or support with this product or other HMS products please
request support at www.ixxat.com/support.
Further international support contacts can be found on our webpage
www.ixxat.com
Copyright
Duplication (copying, printing, microfilm or other forms) and the electronic
distribution of this document is only allowed with explicit permission of HMS
Technology Center Ravensburg GmbH. HMS Technology Center
Ravensburg GmbH reserves the right
to change technical data without
prior announcement. The general business conditions and the regulations
of the license agreement do apply. All rights are reserved.
Registered trademarks
All trademarks mentioned in this document and where applicable third
party registered are absolutely subject to the conditions of each valid label
right and the rights of particular registered proprietor. The absence of
identification of a trademark does not automatically mean that it is not
protected by trademark law.
Document number: 4.01.0086.20000
Version: 2.0
1 Introduction .................................................................................... 5
1.1 Overview ................................................................................. 5
1.2 Features .................................................................................. 5
1.3 Support ................................................................................... 6
1.4 Returning Hardware ............................................................... 6
2 Installation ...................................................................................... 7
2.1 Software Installation .............................................................. 7
2.2 Hardware Installation ............................................................. 7
3 Connections and Indicators .......................................................... 8
3.1 Pin Allocation ......................................................................... 8
3.1.1 Power Connector ..................................................................... 8
3.1.2 Ethernet Socket ........................................................................ 9
3.1.3 CAN Bus Connector ............................................................... 10
3.2 Indicators .............................................................................. 10
3.2.1 Power LED (PWR) ................................................................. 11
3.2.2 Status LED (CPU) .................................................................. 11
3.2.3 Ethernet LED (ETH) ............................................................... 12
3.2.4 Collision LED (COL) ............................................................... 12
3.2.5 Link/Data Activity LED (ACT) ................................................. 13
3.2.6 CAN LED (CAN) ..................................................................... 13
3.3 CAN Bus Termination .......................................................... 14
4 Configuration................................................................................ 14
4.1 Configuration Tool ............................................................... 14
4.1.1 Overview ................................................................................ 14
4.1.2 Usage ..................................................................................... 15
4.2 Resetting the Network Parameters ..................................... 15
5 Appendix....................................................................................... 17
5.1 Technical specifications ...................................................... 17
5.2 Default Network Settings ..................................................... 18
5.3 Windows Firewall Settings .................................................. 19
5.3.1 CAN@net II/VCI ..................................................................... 19
5.3.2 CAN@net II/Generic .............................................................. 19
5.4 Accessories .......................................................................... 20
5.4.1 CAN Bus Termination Resistor .............................................. 20
