Single Element Cartridge Pool & Spa CS Filters
Models: CS100 CS250
CS150
CS200
Essential installation and startup instructions are included in this manual.
Additional operation and troubleshooting information is available online by
scanning the QR code with your phone or visiting jandy.com
WARNING
FOR YOUR SAFETY – This product must be installed and serviced by a contractor who is licensed and qualified in pool
equipment by the jurisdiction in which the product will be installed where such state or local requirements exist. The
maintainer must be a professional with sufficient experience in pool equipment installation and maintenance so that all of
the instructions in this manual can be followed exactly. Before installing this product, read and follow all warning notices and
instructions that accompany this product. Failure to follow warning notices and instructions may result in property damage,
personal injury, or death. Improper installation and/or operation may void the warranty.
Improper installation and/or operation can create unwanted electrical hazard which may cause serious injury, property
damage, or death.
ATTENTION INSTALLER – This manual contains important information about the installation, operation and
safe use of this product. Thisinformation should be given to the owner/operator of this equipment.
Installation and Operation Manual
Manuel d’installation et d’utilisation
Manual de instalación y operación
Page 2
ENGLISH Jandy
®
Single Element Cartridge Pool & Spa CS Filters | Installation & Operation Manual
Section 1. Important Safety Instructions
READ AND FOLLOW ALL INSTRUCTIONS
1.1 Important Safety Warning
WARNING
• Do not connect system to an unregulated city water system or other external source of pressurized
water producing pressures greater than 35 PSI.
• Pressurized air in system can cause product failure or also cause the filter lid to be blown off
which can result in death, serious personal injury, or property damage. Be sure all air is out of
system before operating or testing the equipment.
MAXIMUM OPERATING PRESSURE OF THE FILTER IS 50 PSI. NEVER SUBJECT THE FILTER TO
ANY OPERATING PRESSURE EXCEEDING 50 PSI.
This filter operates under high pressure. When any part of the circulating system, i.e., filter, pump,
valve(s), clamp, etc. is serviced, air can enter the system and become pressurized when the system
is restarted. Pressurized air can cause product failure or also cause the filter lid to be blown off which
can result in death, serious personal injury or property damage. To avoid this potential hazard, follow
all of the instructions in this manual.
To minimize risk of severe injury or death the filter and/or pump should not be subjected to the piping
system pressurization test.
Local codes may require the pool piping system to be subjected to a pressure test. These
requirements are generally not intended to apply to the pool equipment such as filters or pumps.
Jandy Pro Series pool equipment is pressure tested at the factory.
If however this WARNING cannot be followed and pressure testing of the piping system must include
the filter and/or pump BE SURE TO COMPLY WITH THE FOLLOWING SAFETY INSTRUCTIONS:
• Check all clamps, bolts, lids, lock rings and system accessories to ensure they are properly
installed and secured before testing.
• RELEASE ALL AIR in the system before testing.
• Water pressure for test must NOT EXCEED 35 PSI.
• Water temperature for test must NOT EXCEED 100°F (38°C).
• Limit test to 24 hours. After test, visually check system to be sure it is ready for operation.
Notice: These parameters apply to Jandy Pro Series equipment only. For non-Jandy equipment, consult equipment manufacturer.
Table of Contents
Section 1. Important Safety Instructions .... 2
1.1 Important Safety Warning ......................... 2
1.2 General Safety Instructions ...................... 3
Section 2. General Information .................... 3
2.1 Introduction ............................................... 3
2.2 Description ................................................ 3
2.3 General Requirements .............................. 3
Section 3. Installation Instructions .............. 4
3.1 Filter Location ........................................... 4
3.2 Filter Preparation ...................................... 4
3.3 Filter Installation ........................................ 5
3.4 Locking Ring and Tank Top Assembly
Installation ................................................. 5
Section 4. Start-Up and Operation .............. 6
4.1 New Pool and Seasonal Start-up ............. 6
Section 5. Filter Disassembly
and Assembly .............................. 7
5.1 Filter Element Removal ............................. 7
Section 6. Maintenance ................................ 7
6.1 General Maintenance ................................ 7
6.2 Pressure Gauge ........................................ 8
6.3 Cleaning the Filter Cartridge ..................... 8
6.4 Breather Tube Maintenance ...................... 8
Section 7. Winterizing ................................... 8
Section 8. Troubleshooting .......................... 9
Section 9. Parts List and Exploded View .. 10
