Diatomaceous Earth Pool Filters
DEV
Essential installation and startup instructions are included in this manual.
Additional operation and troubleshooting information is available online by
scanning the QR code with your phone or visiting jandy.com
WARNING
FOR YOUR SAFETY – This product must be installed and serviced by a contractor who is licensed and qualifi ed in pool
equipment by the jurisdiction in which the product will be installed where such state or local requirements exist. The
maintainer must be a professional with suffi cient experience in pool equipment installation and maintenance so that all of
the instructions in this manual can be followed exactly. Before installing this product, read and follow all warning notices and
instructions that accompany this product. Failure to follow warning notices and instructions may result in property damage,
personal injury, or death. Improper installation and/or operation may void the warranty.
Improper installation and/or operation can create unwanted electrical hazard which may cause serious injury, property
damage, or death.
ATTENTION INSTALLER – This manual contains important information about the in stal la tion, operation and
safe use of this product. Thisinformation should be given to the owner/operator of this equipment.
Installation and Operation Manual
Manuel d’installation et d’utilisation
Manual de instalación y operación
Page 2
ENGLISH Jandy
®
Diatomaceous Earth Pool Filters | Installation & Operation Manual
EQUIPMENT INFORMATION RECORD
DATE OF INSTALLATION
INSTALLER INFORMATION
INITIAL PRESSURE GAUGE READING (WITH CLEAR FILTER)
PUMP MODEL
HORSEPOWER
FILTER MODEL
SERIAL NUMBER
NOTES:
Table of Contents
Section 1. Safety Information ...................... 3
1.1 Important Safety Warning ......................... 3
1.2 General Safety Instructions ...................... 3
Section 2. General Information .................... 4
2.1 Introduction ............................................... 4
2.2 Description ................................................ 4
2.3 General Requirements .............................. 4
2.4 DE Requirements ...................................... 4
2.5 Specifications and Dimensions ................ 4
Section 3. Installation Instructions .............. 5
3.1 Filter Location ........................................... 5
3.2 Anchor Bracket Installation ....................... 5
3.3 Filter Preparation ...................................... 5
3.4 Filter Plumbing .......................................... 6
3.5 Clamp Installation, DEV Series ................. 7
Section 4. Start-Up and Operation .............. 8
4.1 Preparing Diatomaceous Earth ................. 8
4.2 Coating the Filter Grids ............................. 8
4.3 New Pool and Seasonal Start-up ............. 8
4.4 Valve Operation......................................... 9
Section 5. Filter Disassembly
and Assembly .............................. 9
5.1 Filter Tank Disassemby/Assembly ............ 9
5.2 Filter Grid Disassembly/Assembly .......... 10
Section 6. Maintenance .............................. 10
6.1 General Maintenance .............................. 10
6.2 Backwashing .......................................... 10
6.3 Pressure Gauge ...................................... 10
6.4 Cleaning the Filter Grids with Water ....... 11
6.5 Cleaning Filter Grids with Muriatic Acid . 11
Section 7. Winterizing ................................. 11
Section 8. Troubleshooting ........................ 11
Section 9. Parts List and Exploded View .. 13
9.1 Jandy DEV Filter Parts List ..................... 13
9.2 Exploded View of Jandy DEV Filter ........ 13
Section 10. Head Loss Curves ..................... 14
10.1 Jandy DEV Filter Design Head
Loss Curves ............................................ 14
