VersaTemp
™
JRT Series Heat Pump
WARNING
FOR YOUR SAFETY – This product must be installed and serviced by a contractor who is licensed and qualified in pool equipment by the jurisdiction in which the
product will be installed where such state or local requirements exist. The maintainer must be a licensed HVAC technician certified in heat pump repair and
maintenance by the jurisdiction in which the product will be installed where such state or local requirements exists. The technician must possess and comply with all
certifications and regulations regarding the purchasing, handling, transportation and reclamation of R410A refrigerant. In the event no such state or local requirement
exists, the installer or maintainer must be a professional with sufficient experience in pool equipment installation and maintenance so that all of the instructions in
this manual can be followed exactly. Before installing this product, read and follow all warning notices and instructions that accompany this product. Failure to follow
warning notices and instructions may result in property damage, personal injury, or death. Improper installation and/or operation may void the warranty.
Improper installation and/or operation can create unwanted electrical hazard which may cause serious injury, property damage, or death.
ATTENTION INSTALLER – This manual contains important information about the installation, operation and safe use of this product.
Thisinformation should be given to the owner/operator of this equipment.
Installation and Operation Manual
Manuel d’installation et d’utilisation
Manual de instalación y operación
Page 2
ENGLISH Jandy
®
VersaTemp
™
JRT Series Heat Pump | Installation & Operation Manual
Table of Contents
EQUIPMENT INFORMATION RECORD
Date Of Installation ___________________________________________________________________
Installer Information __________________________________________________________________
Initial Pressure Gauge Reading (with Clean Filter) ____________________________________________
Pump Model ___________________________ Horsepower___________________________________
Notes _____________________________________________________________________________
__________________________________________________________________________________
__________________________________________________________________________________
Section 1. General Information .................... 3
1.1 Introduction ............................................... 3
1.2 Consumer Information & Safety................ 3
1.3 Warranty.................................................... 5
1.4 Codes and Standards ............................... 5
1.5 Technical Assistance ................................ 5
1.6 Materials Needed for Installation .............. 5
1.7 Specifications ........................................... 6
Section 2. Installation Instructions .............. 8
2.1 General Information .................................. 8
2.2 Location Requirements ............................. 8
Section 3. Water Connections .................. 10
3.1 Plumbing Layout .................................... 10
3.2 Water Connections at HeatPump .......... 10
3.3 Check Valve Installation .......................... 10
3.4 Multiple Unit Installation ......................... 10
3.5 Head Loss Curves ................................. 12
Section 4. Electrical Connections ............. 13
4.1 General Information ................................ 13
4.2 Main Power ............................................. 13
4.3 Bonding .................................................. 16
4.4 Optional Remote Controls ...................... 16
Section 5. Operation ................................... 19
5.1 Initial Startup Precautions ....................... 19
5.2 Operating the Controller ......................... 19
5.3 Chiller Operating Feature ........................ 20
5.4 User Setup Options ................................ 21
5.5 Set Point Lockout ................................... 21
5.6 Water Pressure Switch Adjustment ........ 22
5.7 Hot Gas Defrost ...................................... 22
Section 6. General Maintenance ................ 23
6.1 Water Chemistry ..................................... 23
6.2 Winterizing .............................................. 23
6.3 Spring Startup......................................... 23
6.4 Inspection and Service ........................... 24
Section 7. Professional Maintenance
andService ................................ 25
7.1 Heat Pump Design .................................. 25
7.2 Heat Pump Components
and Operation ......................................... 25
Section 8. Troubleshooting ........................ 26
8.1 Troubleshooting Guide ............................ 26
8.2 Diagnostics ............................................. 27
Section 9. Replacement Parts ................... 28
9.1 Ordering Information ............................... 28
9.2 Jandy JRT Heat Pumps
Parts List ................................................. 28
9.3 Jandy JRT Heat Pumps
Exploded View ........................................ 30
9.4 Jandy JRT Single Phase
Electric Box ............................................. 31
9.5 Jandy JRT Three Phase
Electric Box ............................................. 32
