I N S T A L L A T I O N G U I D E

for the

SB-N-TTNCRW2G/10TW3

SKU# 94699

2016-Up Nissan Titan Crew Cab Trucks

• Installation requires appropriate tools and safety equipment.

Professional installation is recommended.

• If you prefer to perform your own installation, please read this

installation guide completely before beginning.

• Before cutting or drilling, check for potential obstacles behind

mounting surfaces.

• Mount this product securely to prevent damage or injury in

severe conditions.

INSTALLATION

DIFFICULT Y:

EST IMAT ED T IME:

1 HOUR

Enclosure Type: Sealed

Driver Type: 10TW3-D8

Nominal Impedance: 2 ohms

Continuous Power Handling: 800 watts (RMS method)

Continued on Next Page

OUT

SB-N-TTNCRW2G/10TW3 INSTR_SKU# 011574

I N C LUD E D H A R D W A R E

Continued on Next Page

Page 2 • JL Audio, Inc., 2022

SB-N-TTNCRW2G/10TW3 INSTR_SKU# 011574

BOM ID DescriptionQty SKU

1 4 154090 M6 - 1 x 20 mm Hex Head Screw

2 4 154091 M6 Split Lock Washer

3 4 154092 M6 Oversized 18 mm OD Flat Washer

4 2 154449 Bracket

5 4 154450 3/8 - 16 x 1-1/4” Flanged Button Head Screw

P O W E R R E C O M M E N D AT I O N

JL Audio recommends high quality ampliers such as the JL Audio XD600/1v2. The diagram below shows the recommended crossover settings for the XD600/1v2. For a detailed description of the

amplier settings, consult the owner’s manual for the amplier. If another amplier is being used, please reference this illustration and use similar settings on that amplier.

C O N N E C T I O N S

Using quality power, signal, and speaker wire is essential in ensuring the performance of your Stealthbox®. JL Audio recommends using a 4 AWG power kit such as the XD-PCS4-1B for your

Stealthbox® amplier. Other kits are available should you be using more than one amplier. Signal wire such as the JL Audio Premium Audio Interconnect Cables should be used to provide signal for
