I N S T A L L A T I O N G U I D E

for the

SBA-J-JK-FHB

SKU# 99840

2007-2017 Jeep Wrangler (JK)

Thank you for choosing a JL Audio Stealthbox® for your automotive sound system.

With proper installation, your new vehicle-specific enclosed subwoofer system

will deliver years of listening pleasure.

We strongly recommend that you have your new Stealthbox® installed by your

authorized JL Audio dealer. The installation professionals employed by your

dealer have the necessary tools and experience to disassemble and reassemble

your vehicle properly. If you prefer to perform your own installation, please read

this installation guide completely before beginning the process.

If you choose to perform the installation yourself, it is absolutely

vital that the Stealthbox® be properly mounted to the vehicle

according to these instructions. Failure to mount the enclosure

properly presents two problems:

1) The sub-bass performance will suffer due to the movement of the

enclosure caused by the force exerted by the woofer(s).

2) A loose enclosure presents a serious safety hazard in the event of a

collision or sudden deceleration.

INSTALLATION

DIFFICULT Y:

ESTIMATED T IME:

1 HOUR

Fuse Holder Bracket

Continued on Next Page

OUT

SBA-J-JK-FHB INSTR_SKU# 011552

IN CL U DE D HAR DWA R E

1 2 3

Continued on Next Page

Page 2 • JL Audio, Inc., 2020

SBA-J-JK-FHB INSTR_SKU# 011552

BOM ID DescriptionQty SKU

1 1 153975 Fuse Holder Bracket

2 2 150074 6mm Stainless Steel Serrated Flange Nut

3 4 154006 #6 - 32 x 1/2” Flat Head Phillips Screw

- 2 154100 8” Cable Tie *

* Not Shown

F U S E B L O C K M O U N T I N G T E M P L A T E

The SBA-J-JK-FHB Fuse Holder Bracket is designed to accommodate two JL Audio XB-MFBU-ANL Master ANL Fuse Blocks (sold separately). Use the illustration and table below to determine the

mounting hole use:

XB-MFBU-ANL 1

XB-MFBU-ANL 2

Continued on Next Page

Page 3 • JL Audio, Inc., 2020
