Seite 1/4
KNX Brightness sensor
Ref.-no.: 2095 EB
Operating instructions
Brightness Sensor
1. System information
This device is a product of the instabus EIB-system and complies with
EIBA directives. Detailed technical knowledge obtained in instabus-
training courses is a prerequisite for proper understanding.
Functionality of this device is depending on the software. Detailed
information on loadable software and attainable functionality may be
taken from the manufacturer’s product database.
Planning, installation and commissioning of the unit is done by means of
EIBA certified software.
2. Indications of danger
Caution ! The installation and assembly of electrical equipment may
be carried out only by a skilled person.
3. Function
The brightness sensor detects the value of brightness via the receiver c
(see fig. B) and analyzes and transmits a telegram to the instabus.
Stand: Jun-08 825 238 13
KNX Brightness sensor
Ref.-no.: 2095 EB
4. Connection
The decoder 2 was build as an installation device and is being recessed
into a false ceiling or another hollow body.
It may be installed with 2 screws 4 mm Ø.
For opening the terminal connection box move the locking towards
direction of arrow
3 (fig. A) and open cover f.
For closing terminal connection box shut cover until locking snaps in.
Connect the wires of the receiver line to the decoder as follows:
Terminal S : white wire
Terminal – : blue wire
Terminal + : red wire
The receiver is being recessed by means of a terminal spring
g and an
aperture
h i into the false ceiling (fig. B). Plug the aperture to the front
of the receiver and slide the terminal spring onto the receiver from the
back.
To attach the receiver plug the fastening element
j into one of the tracks
k provided.
Figure A
Figure B
2
KNX Brightness sensor
Ref.-no.: 2095 EB
5. Important
Preferably via the area to be detected, if possible avoid installation to
direct light irradiation.
Do not expose rear of receiver directly to irradiation of light as
malfunction may occur caused by light entrying at the cable inlet.
Subject to change without notice.
6. Technical Data
Supply
instabus EIB : 21 – 32 V DC
Power input capacity : approx. 120 mW
Connection
instabus : Connecting terminal
and branch joint
Receiver line : Screw terminals
Terminal S : white wire
Terminal – : blue wire
Terminal + : red wire
Length of
receiver line : approx. 2 m, may not
be lengthened !
Aperture
h : Ø 47 mm
Installation of receiver
bore :
Ø 37 mm
or
rectangular opening : 30 x 30 mm
thickness of
false ceiling : max. 45 mm
Ambient temperature : -5 °C until +45 °C
Storing temperature : -40 °C until +55 °C
Type of protection : IP 20
3
