P/N: 2900-301204 Rev 3 www.kramerAV.com

USER MANUAL

MODELS:

AFM-20DSP, AFM-20DSP-LE,

AFM-20DSP-AEC

20-Port Audio Matrix

Kramer Electronics Ltd.

AFM-20DSP – Contents
i

Contents
Introduction  1
Getting Started  1
Overview  2
Typical Applications  4
Defining AFM-20DSP  5
AFM-20DSP, AFM-20DSP-AEC Front Panels  5
AFM-20DSP-LE Front Panel  5
AFM-20DSP/LE/AEC Rear Panels  6
Installing AFM-20DSP  8
Connecting the 20-Port Audio Matrix  9
Connecting AFM-20DSP  9
Connecting AFM-20DSP-LE  11
Connecting AFM-20DSP-AEC  12
Connecting to AFM-20DSP via RS-232  14
Operating and Controlling AFM-20DSP  15
Operating via Ethernet  15
Using Embedded Webpages  18
Accessing the AFM-20DSP Webpages  19
Using the Top Status Bar  19
Viewing the Matrix Area  21
Processing Audio Signals  22
Selecting Output Signals to Route to Amplifier Outputs  22
Linking Analog Inputs and Outputs  23
Processing a Signal  24
Routing Inputs to Outputs  37
Mixing Audio Signals  41
Defining Audio Settings  44
Defining Video Settings  45
Defining AEC Settings  46
Auto Mixer  50
Restarting and Resetting the Device  53
Restarting the Device  53
Resetting the Device  53
Defining Settings  54
Importing/Exporting Global Settings  54
Setting Access Security  54
Defining Communication Settings  55
Performing Firmware Upgrade  56
Setting Date and Time  57
Configuring Device Automation  57
Viewing Device Information  58
Upgrading Firmware  59
Technical Specifications  60
AFM-20DSP Technical Specifications  60
AFM-20DSP-LE Technical Specs  61
AFM-20DSP-AEC Technical Specifications  62
Default Communication Parameters  64
Default AFM-20DSP EDID  64
Default AFM-20DSP-AEC EDID  66
Protocol 3000  68
Understanding Protocol 3000  68
Protocol 3000 Commands  68
Result and Error Codes  86
