Seite 1/156

P/N: 2900-300928 Rev 7 www.KramerAV.com

USER MANUAL

MODEL:

VS-1616DN-EM

2x2 to 16x16 Modular Multi-Format

Managed Digital Matrix Switcher

Kramer Electronics Ltd.

VS-1616DN-EM – Contents
i

Contents
Introduction  1
Getting Started  2
Overview  4
Defining the VS-1616DN-EM 2x2 to 16x16 Modular Multi-Format Managed Digital Matrix Switcher  6
Mounting VS-1616DN-EM  10
Connecting the VS-1616DN-EM  11
Port Numbering  12
Connecting to the VS-1616DN-EM via RS-232  13
Connecting to the VS-1616DN-EM via USB (VCOM)  13
Connecting to the VS-1616DN-EM via Ethernet  13
Operating – Front Panel Buttons  17
Startup Display  17
Viewing the Display  18
Using the Selector Buttons  18
Confirming Actions  18
Switching Actions  19
Locking the Front Panel Buttons  22
Using the Configuration Menus  23
Using the Setup Menu  23
Using the Config Menu  27
Configuring the Number of Installed Input and Output Ports  33
Operating and Configuring – Embedded Web Pages  34
Browsing Web Pages  35
Switching – Web Pages  36
Copying EDID – Web Pages  37
Configuring Ports – Web Pages  37
Using the Test Video Plus Analog Audio Card  38
Defining the Test Video Plus Analog Audio Card  38
Setting the Resolution of the Generated Video  40
Setting the Pattern of the Generated Video  40
Installing the Test Module  41
Using the Input / Output Cards  42
Defining the UHD-IN2-F16 / UHD-OUT2-F16  42
Defining the UHDA-IN2-F16 / UHDA-OUT2-F16  44
Defining the HDBT7-IN2-F16 / HDBT7-OUT2-F16  48
Defining the DTAxr-IN2-F16 / DTAxr-OUT2-F16  51
Defining the HDBT-IN2-F16 / HDBT-OUT2-F16  55
Defining the HH-IN2-F16 / HH-OUT2-F16  59
Defining the HS-OUT2-F16  60
Defining the HAD-IN2-F16 / HAD-OUT2-F16  63
Defining the HAA-IN2-F16 / HAA-OUT2-F16  65
Defining the HDCP-IN2-F16 / HDCP-OUT2-F16  68
Defining the DGKat-IN2-F16 / DGKat-OUT2-F16  70
Defining the F670-IN2-F16 / F670-OUT2-F16  73
Defining the F610-IN2-F16 / F610-OUT2-F16  74
Defining the DVI-IN2-F16 / DVI-OUT2-F16  75
Defining the DL-IN1-F16 / DL-OUT1-F16  76
Defining the SDIA-IN2-F16  77
Defining the VGA-IN2-F16 / VGA-OUT2-F16  79
Defining the VGAA-OUT2-F16 / VGAA-IN2-F16  81
Defining the AAD-IN2-F16 / AAD-OUT2-F16  85
Defining the UHDS-OUT2-F16  87
Using the Test Module to Troubleshoot Video and Audio Problems  89
Troubleshooting Video Problems  89
Troubleshooting Audio Problems  91
Input / Output Card Hardware Installation Instructions  93
Replacing a FAN-16DN Fan Array  95
