GB/IE GB/IEGB/IEGB/IE
liability is accepted for
damage
to property or persons caused
by improper handling or non-
observance of the safety
advice!
J This appliance can be used
by children aged from 8
years and above and
persons with reduced
physical, sensory or mental
capabilities or lack of
experience and knowledge
if they have been given
supervision or instruction
concerning use of the
appliance in a safe way
and understand the hazards
involved. Children shall not
play with the appliance.
Cleaning and user
maintenance shall not be
made by children without
supervision.
J Do not allow the lamp or
the packaging materials to
lie around unattended.
Plastic film or bags,
Styrofoam etc. can turn into
dangerous toys for children.
J
CAUTION!
DANGER OF
EXPLOSION!
Do not operate the lamp in
potentially explosive
environments in which there
are inflammable vapours,
gases or dusts.
J Do not expose the lamp to
direct sunlight, rain, snow or
ice. Failure to observe this
advice may result in
damage to the product.
J Do not attach the light to
damp or conductive
substrates.
LED cannot be replaced.
To avoid danger
to life from
electric shock
J Never use your lamp if you
discover that it is damaged
in any way.
J In the event of damage,
repairs or other problems
with the lamp, please
contact the Service Centre
or an electrician.
J Before installation, switch
off the electrical circuit at
the circuit breaker box or
remove the fuse from the
fuse box.
J Never let the lamp come
into contact with water or
other liquids.
J Never open or insert
anything into electrical
fittings or equipment. Doing
this sort of thing can lead to
a serious danger to life from
electric shock.
J Before assembly, ensure
that the mains voltage
available corresponds to
the operating voltage
necessary of the light
(HG00198A-BS: 100 - 240 V ∼;
HG00198B-BS: 220 - 240 V ∼).
HG00198A-BS
J The product is only suited
for use with the included
mains adapter (Model No.
YNQST120025BL).
J Please note that the power
adapter continues to draw
a small amount of power
even if the lamp is turned off
as long as the power
adapter is plugged into a
power outlet. To switch the
device off completely,
Q
Technical data
HG00198A-BS
LED Light strip +
Main adapter:
Total power
consumption: approx. 3.2 W
LED Light Strip:
Operating voltage:
12 V
Lamps:
6 x power LED
LED:
6 x
0.5 W
Nominal power:
approx. 2.4 W
Protection
category:
Main adapter:
Rated voltage,
primary: 100–240V
~
50–60 Hz
Rated voltage,
secondary: 12V
250 mA
Protection class:
Main adapter (model no.:
YNQST120025BL) CE
standard tested.
HG00198B-BS
Operating voltage:
220–240 V
~
50-60 Hz
Lamps:
4 x power LED
LED:
4 x
0.5 W
Nominal power: approx. 3 W
Protection
category:
Q
Safety
Safety
advice
The right to claim under the
guarantee shall be rendered
invalid in respect of damage
caused by the non-observance
of these operating instructions!
No liability is
accepted for
consequent damage!
No
LED LIGHT STRIP
Q
Proper use
The under-unit lights
HG00198A-BS and
HG00198B-BS are intended for
providing illumination and for
mounting on furniture. Under-unit
light HG00198B-BS can also be
mounted on walls. The product
may only be used indoors in dry
rooms. The LEDs cannot be
r
eplaced. The light can be
mounted
on all normally
flammable surfaces. This device
is intended for use only in a
domestic, private household
environment.
Q
Description of
parts and features
HG00198A-BS
1
Drill hole
2
LED
3
ON/OFF switch (“Touch
switch”)
4
Socket for connecting lead
5
Plug-in mains adapter with
connection lead (length
approx. 2 m)
6
Screw
HG00198B-BS
1
ON/OFF switch
2
Socket for connecting lead
3
LED
4
Protective cap
5
Drill hole for wall mounting
6
Slot for mounting rail
7
Connecting lead with mains
plug
8
Extension lead
9
Mounting rail
10
Dowel
11
Screw for wall mounting
12
Screw for under-cabinet
installation
LED LIGHT STRIP
Operation and Safety Notes
LED LIGHT STRIP
IAN 271061
HG00198A-BS
HG00198B-BS
HG00198A-BS
HG00198B-BS
HG00198B-BS
HG00198B-BS
HG00198B-BSHG00198B-BS
unplug the power adapter
from the socket.
HG00198B-BS
J The product may only be
used with the built-in LED
control gear.
J The product continues to
draw a small amount of
power even if the lamp is off
as long as product is
connected to supply mains.
To switch the device off
completely, the mains switch
should be switched off.
To avoid danger
of fire and injury
J RISK OF INJURY! Check
every bulb and lampshade
for damage immediately
upon unpacking. Do not fit
the light if the bulbs and / or
lampshades are faulty. If
they are, contact the service
point for a replacement.
DANGER
OF ELECTRIC SHOCK!
DANGER OF DAMAGE
TO PROPERTY!
DANGER OF INJURY!
Ensure that you do not strike
electrical cables, gas or
water pipes when you are
drilling into the wall. If
necessary, check the wall
using a suitable detector
before you drill.
J
RISK OF
INJURY FROM
BURNS! Ensure
the lamp has been switched
off and allowed to cool
before
you touch it. In this
way you
will avoid the
danger of burns.
Bulbs give
GB/IEGB/IEGB/IEGB/IEGB/IEGB/IEGB/IE
for electrical and electronic
appliances. Recycling
helps to reduce the consumption
of raw materials and to ease the
burden on the environment.
Q
Warranty
The device has been
manufactured to strict quality
guidelines and meticulously
examined before delivery. In the
event of product defects you
have legal rights against the
retailer of this product. Your
legal rights are not limited in
any way by our warranty
detailed below.
The warranty for this device is
3 years from the date of
purchase. Should this device
show any fault in materials or
manufacture within three years
from the date of purchase, we
will repair or replace it - at our
choice - free of charge to you.
The warranty period begins on
the date of purchase. Please
keep the original sales receipt in
a safe location. This document is
required as your proof of
purchase. This warranty
becomes void if the device has
been damaged or improperly
used or maintained.
The warranty applies to faults in
material or manufacture. This
warranty does not cover
product parts subject to normal
wear, thus possibly considered
consumables (e.g. batteries) or
for damage to fragile parts, e.g.
switches, rechargeable batteries
or glass parts.
Q
Maintenance and
Cleaning
Allow the lamp to cool down
completely.
DANGER
TO LIFE FROM
ELECTRIC
SHOCK! Before carrying
out any tasks on the lamp,
switch off the electrical
circuit at the circuit breaker
box or remove the fuse from
the fuse box.
j CAUTION! Do not use
solvents, petrol etc.
DANGER
TO LIFE FROM
ELECTRIC
SHOCK! For reasons of
electrical safety, the light
must never be cleaned with
water or other fluids or be
immersed in water. When
cleaning, only use a dry,
lint-free cloth.
Q
Disposal
The packaging and
ancillary packing
consist entirely of
environmentally-friendly
materials. They can be disposed
of at your local recycling facility.
The symbol of the
wheelie bin with the
line through it means
that, in the European Union, the
product has to be disposed of in
a separate refuse collection.
This applies to the product and
to all components bearing this
symbol. Products marked in this
way may not be disposed of
along with normal domestic
waste but have to be handed in
at a recycling collection point
j Insert the supplied dowels
10
into the drilled holes.
Insert the supplied screws
11
into the dowels and
tighten them. Let them
project a distance of about
1.3 mm from the wall or
mounting surface.
j Attach the light to the
screws
11
using the
appropriate wall mounting
holes
5
.
j Plug the connection cable
with mains plug
7
into the
socket for the connection
cable
2
.
j Plug the connection cable
with mains plug
7
into the
mains socket. Your light is
now ready for operation.
Extensions
j Note: Ensure that no more
than 3 under-unit lights of the
same type (HG00198B-BS)
are connected together in
series. Install each
additional light at a
distance of approx. 15 cm
as described.
j Remove the protective cap
4
. Connect the two under-
unit lights to the socket
2
using the extension lead
8
. Then you only need
one connection lead
7
for
the power supply.
j CAUTION! First ensure
that all the under-unit lights
are connected by an
extension lead
8
before
you insert the mains lead
into the mains socket.
j First screw only one of the
mounting rails
9
in the pre-
drilled positions with the
supplied screws
12
.
j Place the under-cabinet light
flat on the mounting surface
and push it onto the
mounting rail
9
up to the
stop in the slot
6
(see Fig. C).
j Push the second mounting
rail
9
into the slot
6
on
the under-cabinet light so
that the drilled hole is
visible. Tighten the screw in
this position (see Fig. D).
j Now push the under-
cabinet light a little to the
right. Both mounting rails
9
should now be firmly
positioned (see Fig. E).
Check that the under-
cabinet light is fitted
securely.
j Plug the connecting lead
7
into the socket
2
.
j Plug the mains plug of the
connecting lead
7
into a
socket. Your under-cabinet
light is now ready for
operation.
Q
Mounting model
HG00198B-BS on
a wall
j Measure up the wall or
mounting surface for drilling
the holes. Use a spirit level
to improve accuracy.
j Mark the two mounting
holes a distance of approx.
403 mm apart.
j Now drill the mounting
holes (ø approx. 6 mm,
depth approx. 30 mm).
CAUTION! Make sure that
you do not damage any
electrical cables during this
operation.
j Position the under-cabinet
light according to the drilled
holes and tighten the
screws
6
.
j Plug the connecting lead
5
into the socket
4
.
j Plug the mains plug of the
connecting lead
5
into a
socket. Your under-cabinet
light is now ready for
operation.
Note: Only use the lamp
with the mains adapter it
was delivered with
(YNQST120025BL).
Damage due to use of a
different adapter is not
covered by the guarantee.
Q
Installing light
HG00198B-BS
j Use the mounting rails
9
(see also Fig. B) and the
screws
12
for under-cabinet
installation.
j Measure the space for
installation of the light. Use
a spirit level to position it
correctly.
Mark where you wish to
drill and pre-drill the holes.
j Mark the distance of
533 mm for the two fixing
holes. Drill the holes: ø
approx. 2 mm, approx.
10 mm deep.
Note: The supplied screws
are for standard installation
under wall cabinets and are
not suitable for every type
of wall. If installing on
concrete walls, for example,
you will need to use special
dowels and screws.
Information on suitable
installation material can be
obtained from specialist
stores.
off a lot of heat around the
top of the lamp.
J Do not use this light for
dimmers or electronic
switches. It is not suitable
for these purposes.
Working safely
J Install the lamp so that it is
protected from moisture,
wind and dirt.
J Make careful preparations
for the assembly and take
sufficient time. Clearly lay
out all components and any
additional tools or materials
that might be required so
that they are readily to
hand.
J Remain alert at all times
and always watch what you
are doing. Always proceed
with caution and do not
assemble the lamp if you
cannot concentrate or feel
unwell.
Q
Installation and
operation
Q
Installing light
HG00198A-BS
j Measure the space for
installation of the light. Use
a spirit level to position it
correctly.
j Mark the position of the drill
holes
1
in the under-
cabinet light.
j Mark the two mounting
holes at a distance of
362 mm apart.
j Drill the holes, ø approx.
2 mm, depth approx.
10 mm.
IAN 271061
OWIM GmbH & Co. KG
Stiftsbergstraße 1
D-74167 Neckarsulm
Model no.: HG00198A-BS /
HG00198B-BS
Version: 10/2015
Produktspezifikationen
| Marke: | Livarno Lux |
| Kategorie: | Beleuchtung |
| Modell: | IAN 271061 |
Brauchst du Hilfe?
Wenn Sie Hilfe mit Livarno Lux IAN 271061 benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten
Bedienungsanleitung Beleuchtung Livarno Lux
31 August 2025
30 August 2025
30 August 2025
30 August 2025
8 August 2025
8 August 2025
8 August 2025
8 August 2025
8 August 2025
8 August 2025
Bedienungsanleitung Beleuchtung
- Theben
- Berger & Schröter
- Aveo Engineering
- Aquatlantis
- Yongnuo
- Dyson
- Elinchrom
- Forte Lighting
- Life On Products
- Neewer
- Goobay
- Hikoki
- CAME-TV
- Canarm
- SWIT
Neueste Bedienungsanleitung für -Kategorien-
31 August 2025
31 August 2025
31 August 2025
31 August 2025
30 August 2025
30 August 2025
30 August 2025
30 August 2025
30 August 2025
30 August 2025
