• You can use a RJ45 coupler or switch (not included) to connect male

ends of Ethernet cable together.

• To extend the cable run beyond 300ft (92m), a switch will be required

(sold separately).

Audio Settings

NOTE: These instructions are based on current NVR interface. For the most

up-to-date instructions, see your NVR’s instruction manual on lorex.com.

To enable audio recording and listen-in audio:

1. From Live View, right-click and click Main Menu. Enter the system user name

(default: admin) and password.

2. Click Camera and select Recording.

3. Under Channel, select the channel where the audio-capable camera is connected.

4. Under Main Stream, click the More Setting button.

ATTENTION:

Audio recording and listen-in audio are disabled by default. Audio recording and/or use of listen-in

audio without consent is illegal in certain jurisdictions. Lorex Corporation assumes no liability for use of

its products that does not conform with local laws.

5. In the More Setting window:

A. Enable Audio Encode for audio

recording and listen-in audio.

NOTE:Listen-in audio requires a

monitor with speakers or speakers

connected to the NVR.

B. Select the format that will be

used to record audio.

ACC is recommended.

6. Click OK to save changes.

A

B

Important Installation Guidelines

Additional Installation Tips:

• Point the camera where there is the least amount of obstructions (e.g., tree branches).

• Install the camera where vandals cannot easily reach.

• Secure cabling so that it is not exposed or easily cut.

• This camera is rated for outdoor use. Installation in a sheltered location is

recommended.

• Smart motion detection is enabled by default. When enabled, the camera’s recording

frame rate is 20 frames per second.

• To obtain the maximum 30 frames per second, smart motion detection must be

disabled.

Optimizing Person and Vehicle Detection Accuracy:

• Angle the camera so that objects of interest appear in the bottom ⅔ of the camera

image.

• Choose a location where objects of interest will be no further than 50ft (~15m) from

the camera.

Optimal accuracy for objects within 50ft (~15m)

and in the bottom ⅔ of the image.

Lower accuracy for objects further away than

50ft (~15m) and/or in the top ⅓ of the image.

• Angle the camera between 30~60° down from the

level position.

• Install the camera between 8-16ft (2.5-5m) off of

the ground.

Level position (i.e., ceiling)

Optimal

angle

range

NOTE:Accuracy of person and vehicle detection will

be inuenced by multiple factors, such as the object’s

distance from the camera, the size of the object, and

the height and angle of the camera. Night vision will

also impact the accuracy of detection.

LNE9282B_QSG_EN_R3

4K Motorized Varifocal HD IP Dome

Security Camera with Smart Motion

Detection and Listen-in Audio

• 4K Motorized Varifocal HD IP Dome Security Camera with Smart

Motion Detection and Listen-in Audio

• Mounting Kit*

• Mounting Template*

• CAT5e Ethernet Extension Cable with Pre-attached RJ45 Cable

Gland*

• Allen Key*

• Read this guide carefully and keep it for future reference.

• Follow all instructions for safe use of the product and handle with care.

• Use the camera within given temperature, humidity and voltage levels

noted in the camera’s specications.

• Do not disassemble the camera.

• Do not point the camera directly towards the sun or a source of

intense light.

• Use only the supplied regulated power supply provided with the product.

Use of a non-regulated, non-conforming power supply can damage the

product and void the warranty.

• Periodic cleaning may be required. Use a damp cloth only. Do not use any

harsh, chemical-based cleaners.

• The supplied cable is rated for surface mounting only. Cables for in-wall

and oor-to-oor installations are sold separately (CMR type). These and

other cables are available at lorex.com.

* Per camera in multi-camera packs.

Copyright © 2023 Lorex Corporation

As our products are subject to continuous improvement, Lorex reserves the right to

modify product design, specications and prices, without notice and without incurring

any obligation. E&OE. All rights reserved.

Package Contents

ATTENTION:

It is recommended to connect the camera to the NVR or an external PoE switch. If

using a DC power adapter (not included) with the camera, a REGULATED power supply

is REQUIRED for use with this camera. Use of a non-regulated, non-conforming power

supply can damage this product and voids the warranty.

Safety Precautions

Dimensions

lorex.com

Extend the cable run for your camera. Additional extension cables sold

separately. See table below:

Cable Extension Options

Cable Type

Max Cable Run

Distance

Max # of

Extensions

CAT5e (or higher) Ethernet cable300ft (92m)3

• For a full list of compatible recorders, visit lorex.com/compatibility.

• Not intended for submersion in water. Installation in a sheltered location

recommended.

• This camera includes an Auto Mechanical IR Cut Filter. When the camera changes

between Day/Night viewing modes, an audible clicking noise may be heard from the

camera. This clicking is normal, and indicates that the camera lter is working.

Disclaimers

4.8” /

122mm

4.8” / 122mm

4.2” /

108mm

• Point the camera where there is the least amount of obstructions (i.e., tree branches).

• Install the camera where vandals cannot easily reach.

• Secure cabling so that it is not exposed or easily cut.

• This camera is rated for outdoor use. Installation in a sheltered location is

recommended.

Installation Tips

Nocturnal Series

Lorex N10

LNE9282B

Quick Start Guide
