Instruction Sheet:

IS- 468RIBES

#18148

Page of 11

Printed on 1-7-19

Lowell Manufacturing Company

100 Integram Drive

Pacific, Missouri 63069 U.S.A.

Mounting Note: The rough-in bridges must be mounted in

accordance with local state and federal codes and , ,

regulations and industry standard practices.,

The picture to the left shows the ES-8-RIB ,

being installed but is also typical for the ,

installation of the ES-4-RIB and the

ES-6-RIB. These Rough-In Bridges“ ”

include rows of 3/ diameter mounting 16"

holes on sixteen ( inch centers and 16)

twenty-four ( inch centers for mounting 24)

to floor joists rafters, , trusses metal rails, ,

or other ceiling support structure before the

drywall ceiling is installed. Screw types

required to mount these rough-in bridges

vary widely depending on the construction

of the ceiling structure so , mounting

screws are not included and will be

supplied by the installer. Mount the

bridge to the ceiling structure with the lip

downward toward the floor. Install speaker

cable and leave a loop above the rough-in

bridge where it will be accessible after the

ceiling has been installed. When the

ceiling contractor installs the drywall the lip ,

on the rough-in bridge will be used as a

router guide to cut the hole in the ceiling at

the location you have predetermined.

Phone: 800-325-9660

Fax: 636-257-6606 (www.lowellmfg.com)

ES-4-RIB, ES-6-RIB, and ES-8-RIB,

Ceiling Speaker Rough-In Bridges.

Installation Sheet For:

ES-4-RIB

ES-6-RIB

ES-8-RIB

SIGNALING SPEAKER

ACCESSORY

ES-4T

Speaker System

Use Rough-In Bridge

ES- T52

ES- T62

ES- T82

ES- CDT82

ES-8TSUB

ES-4-RIB

ES-6-RIB

ES-8-RIB
