Installation Instructions for 70-1787

1-800-221-0932 metraonline.com

REV. 10/14/2014

Installation Instructions for 70-1787

1-800-221-0932 metraonline.com

REV. 10/14/2014

Installation Instructions for 70-1787

1-800-221-0932 metraonline.com

REV. 10/14/2014

Installation Instructions for 70-1787

1-800-221-0932 metraonline.com

REV. 10/14/2014

70-1787

Audi/Porsche/VW Bose integration

harness 1993-2007

AUDI

A3 2006-2007

A4 1996-2006

A6 1998-2004

A6 Quattro 1998-1999

A8 1997-2003

allroad 2001-2005

TT 2000-2006

PORSCHE

Boxster 1997-2004

VOLKSWAGEN

Beetle 1998

Golf 1993-1997

Jetta 1993-1997

APPLICATIONS

Connections to be made

From the aftermarket radio:

• ConnecttheBlackwiretothegroundwire.

• ConnecttheYellow wirethebatterywire.

• ConnecttheRedwiretheaccessorywire.

Note: If a wire is not populated on the factory side, an accessory wire will need to be run

to the fuse box.

• Connectthe Orange/Whitewiretotheilluminationwire.Iftheaftermarketradiohasno

illuminationwire,tapeoffanddisregardtheOrange/Whitewire.

Note: If a wire is not populated on the factory side, an illumination wire will need to be run

to the lighting circuit of the vehicle.

Caution: Metra recommends disconnecting the negative battery terminal before beginning

any installation. All accessories, switches, and especially air bag indicator lights must be

plugged in before reconnecting the battery or cycling the ignition.

*Note: Refer also to the instructions included with the aftermarket radio.

70-1787

Audi/Porsche/VW Bose integration

harness 1993-2007

AUDI

A3 2006-2007

A4 1996-2006

A6 1998-2004

A6 Quattro 1998-1999

A8 1997-2003

allroad 2001-2005

TT 2000-2006

PORSCHE

Boxster 1997-2004

VOLKSWAGEN

Beetle 1998

Golf 1993-1997

Jetta 1993-1997

APPLICATIONS

Connections to be made

From the aftermarket radio:

• ConnecttheBlackwiretothegroundwire.

• ConnecttheYellow wirethebatterywire.

• ConnecttheRedwiretheaccessorywire.

Note: If a wire is not populated on the factory side, an accessory wire will need to be run

to the fuse box.

• Connectthe Orange/Whitewiretotheilluminationwire.Iftheaftermarketradiohasno

illuminationwire,tapeoffanddisregardtheOrange/Whitewire.

Note: If a wire is not populated on the factory side, an illumination wire will need to be run

to the lighting circuit of the vehicle.

Caution: Metra recommends disconnecting the negative battery terminal before beginning

any installation. All accessories, switches, and especially air bag indicator lights must be

plugged in before reconnecting the battery or cycling the ignition.

*Note: Refer also to the instructions included with the aftermarket radio.

70-1787

Audi/Porsche/VW Bose integration

harness 1993-2007

AUDI

A3 2006-2007

A4 1996-2006

A6 1998-2004

A6 Quattro 1998-1999

A8 1997-2003

allroad 2001-2005

TT 2000-2006

PORSCHE

Boxster 1997-2004

VOLKSWAGEN

Beetle 1998

Golf 1993-1997

Jetta 1993-1997

APPLICATIONS

Connections to be made

From the aftermarket radio:

• ConnecttheBlackwiretothegroundwire.

• ConnecttheYellow wirethebatterywire.

• ConnecttheRedwiretheaccessorywire.

Note: If a wire is not populated on the factory side, an accessory wire will need to be run

to the fuse box.

• Connectthe Orange/Whitewiretotheilluminationwire.Iftheaftermarketradiohasno

illuminationwire,tapeoffanddisregardtheOrange/Whitewire.

Note: If a wire is not populated on the factory side, an illumination wire will need to be run

to the lighting circuit of the vehicle.

Caution: Metra recommends disconnecting the negative battery terminal before beginning

any installation. All accessories, switches, and especially air bag indicator lights must be

plugged in before reconnecting the battery or cycling the ignition.

*Note: Refer also to the instructions included with the aftermarket radio.

70-1787

Audi/Porsche/VW Bose integration

harness 1993-2007

AUDI

A3 2006-2007

A4 1996-2006

A6 1998-2004

A6 Quattro 1998-1999

A8 1997-2003

allroad 2001-2005

TT 2000-2006

PORSCHE

Boxster 1997-2004

VOLKSWAGEN

Beetle 1998

Golf 1993-1997

Jetta 1993-1997

APPLICATIONS

Connections to be made

From the aftermarket radio:

• ConnecttheBlackwiretothegroundwire.

• ConnecttheYellow wirethebatterywire.

• ConnecttheRedwiretheaccessorywire.

Note: If a wire is not populated on the factory side, an accessory wire will need to be run

to the fuse box.

• Connectthe Orange/Whitewiretotheilluminationwire.Iftheaftermarketradiohasno

illuminationwire,tapeoffanddisregardtheOrange/Whitewire.

Note: If a wire is not populated on the factory side, an illumination wire will need to be run

to the lighting circuit of the vehicle.

Caution: Metra recommends disconnecting the negative battery terminal before beginning

any installation. All accessories, switches, and especially air bag indicator lights must be

plugged in before reconnecting the battery or cycling the ignition.

*Note: Refer also to the instructions included with the aftermarket radio.

Installation Instructions for 70-1787

1-800-221-0932 metraonline.com

REV. 10/14/2014

Installation Instructions for 70-1787

1-800-221-0932 metraonline.com

REV. 10/14/2014

Installation Instructions for 70-1787

1-800-221-0932 metraonline.com

REV. 10/14/2014

Installation Instructions for 70-1787

1-800-221-0932 metraonline.com

REV. 10/14/2014

KNOWLEDGE IS POWER

Enhance your installation and fabrication skills by

enrolling in the most recognized and respected

mobile electronics school in our industry.

Log onto www.installerinstitute.com or call

800-354-6782 for more information and take steps

toward a better tomorrow.

Metra recommends MECP

certiﬁed technicians

KNOWLEDGE IS POWER

Enhance your installation and fabrication skills by

enrolling in the most recognized and respected

mobile electronics school in our industry.

Log onto www.installerinstitute.com or call

800-354-6782 for more information and take steps

toward a better tomorrow.

Metra recommends MECP

certiﬁed technicians

• Connectthe Blue/White wiretotheampturnonwire.Thiswiremustbe

connectedtohearsoundfromthefactoryamplifier.

• Formodelswithapowerantenna,inserttheBlue wireintothecavityabovetheYellowwire,

andthenconnectthiswiretotheantennaturnonwire.

Note: 1998 and up vehicles will not require this to be done as the antenna turn wire will be in

the antenna itself. Use Metra part number 40-VW54 for these applications.

For models without Bose:

 • ConnecttheWhitewiretotheleftfrontpositivespeakeroutput.

 • ConnecttheWhite/Black wiretotheleftfrontnegativespeakeroutput.

 • ConnecttheGray wiretotherightfrontpositivespeakeroutput.

 • ConnecttheGray/Black wiretotherightfrontnegativespeakeroutput.

 • CapoffanddisregardthePurple,Purple/Black,Green,andGreen/Blackwires.

 • Connectthe GreenRCAjacktotheleftrearRCAjackoutput.

 • ConnectthePurpleRCAjacktotherightrearRCAjackoutput.

 • DisregardtheWhiteandGrayRCAjacks.

For models with Bose:

 • CapoffanddisregardtheWhite,White/Black,Gray,Gray/Black,Purple, 

Purple/Black,Green,andGreen/Blackwires.

 • ConnecttheWhite RCAjacktotheleftfrontRCAjackoutput.

 • ConnecttheGrayRCAjacktotherightfrontRCAjackoutput.

 • ConnecttheGreenRCAjacktotheleftrearRCAjackoutput.

 • ConnectthePurple RCAjacktotherightrearRCAjackoutput.

KNOWLEDGE IS POWER

Enhance your installation and fabrication skills by

enrolling in the most recognized and respected

mobile electronics school in our industry.

Log onto www.installerinstitute.com or call

800-354-6782 for more information and take steps

toward a better tomorrow.

Metra recommends MECP

certiﬁed technicians

• Connectthe Blue/White wiretotheampturnonwire.Thiswiremustbe

connectedtohearsoundfromthefactoryamplifier.

• Formodelswithapowerantenna,inserttheBlue wireintothecavityabovetheYellowwire,

andthenconnectthiswiretotheantennaturnonwire.

Note: 1998 and up vehicles will not require this to be done as the antenna turn wire will be in

the antenna itself. Use Metra part number 40-VW54 for these applications.

For models without Bose:

 • ConnecttheWhitewiretotheleftfrontpositivespeakeroutput.

 • ConnecttheWhite/Black wiretotheleftfrontnegativespeakeroutput.

 • ConnecttheGray wiretotherightfrontpositivespeakeroutput.

 • ConnecttheGray/Black wiretotherightfrontnegativespeakeroutput.

 • CapoffanddisregardthePurple,Purple/Black,Green,andGreen/Blackwires.

 • Connectthe GreenRCAjacktotheleftrearRCAjackoutput.

 • ConnectthePurpleRCAjacktotherightrearRCAjackoutput.

 • DisregardtheWhiteandGrayRCAjacks.

For models with Bose:

 • CapoffanddisregardtheWhite,White/Black,Gray,Gray/Black,Purple, 

Purple/Black,Green,andGreen/Blackwires.

 • ConnecttheWhite RCAjacktotheleftfrontRCAjackoutput.

 • ConnecttheGrayRCAjacktotherightfrontRCAjackoutput.

 • ConnecttheGreenRCAjacktotheleftrearRCAjackoutput.

 • ConnectthePurple RCAjacktotherightrearRCAjackoutput.

• Connectthe Blue/White wiretotheampturnonwire.Thiswiremustbe

connectedtohearsoundfromthefactoryamplifier.

• Formodelswithapowerantenna,inserttheBlue wireintothecavityabovetheYellowwire,

andthenconnectthiswiretotheantennaturnonwire.

Note: 1998 and up vehicles will not require this to be done as the antenna turn wire will be in

the antenna itself. Use Metra part number 40-VW54 for these applications.

For models without Bose:

 • ConnecttheWhitewiretotheleftfrontpositivespeakeroutput.

 • ConnecttheWhite/Black wiretotheleftfrontnegativespeakeroutput.

 • ConnecttheGray wiretotherightfrontpositivespeakeroutput.

 • ConnecttheGray/Black wiretotherightfrontnegativespeakeroutput.

 • CapoffanddisregardthePurple,Purple/Black,Green,andGreen/Blackwires.

 • Connectthe GreenRCAjacktotheleftrearRCAjackoutput.

 • ConnectthePurpleRCAjacktotherightrearRCAjackoutput.

 • DisregardtheWhiteandGrayRCAjacks.

For models with Bose:

 • CapoffanddisregardtheWhite,White/Black,Gray,Gray/Black,Purple, 

Purple/Black,Green,andGreen/Blackwires.

 • ConnecttheWhite RCAjacktotheleftfrontRCAjackoutput.

 • ConnecttheGrayRCAjacktotherightfrontRCAjackoutput.

 • ConnecttheGreenRCAjacktotheleftrearRCAjackoutput.

 • ConnectthePurple RCAjacktotherightrearRCAjackoutput.

KNOWLEDGE IS POWER

Enhance your installation and fabrication skills by

enrolling in the most recognized and respected

mobile electronics school in our industry.

Log onto www.installerinstitute.com or call

800-354-6782 for more information and take steps

toward a better tomorrow.

Metra recommends MECP

certiﬁed technicians

• Connectthe Blue/White wiretotheampturnonwire.Thiswiremustbe

connectedtohearsoundfromthefactoryamplifier.

• Formodelswithapowerantenna,inserttheBlue wireintothecavityabovetheYellowwire,

andthenconnectthiswiretotheantennaturnonwire.

Note: 1998 and up vehicles will not require this to be done as the antenna turn wire will be in

the antenna itself. Use Metra part number 40-VW54 for these applications.

For models without Bose:

 • ConnecttheWhitewiretotheleftfrontpositivespeakeroutput.

 • ConnecttheWhite/Black wiretotheleftfrontnegativespeakeroutput.

 • ConnecttheGray wiretotherightfrontpositivespeakeroutput.

 • ConnecttheGray/Black wiretotherightfrontnegativespeakeroutput.

 • CapoffanddisregardthePurple,Purple/Black,Green,andGreen/Blackwires.

 • Connectthe GreenRCAjacktotheleftrearRCAjackoutput.

 • ConnectthePurpleRCAjacktotherightrearRCAjackoutput.

 • DisregardtheWhiteandGrayRCAjacks.

For models with Bose:

 • CapoffanddisregardtheWhite,White/Black,Gray,Gray/Black,Purple, 

Purple/Black,Green,andGreen/Blackwires.

 • ConnecttheWhite RCAjacktotheleftfrontRCAjackoutput.

 • ConnecttheGrayRCAjacktotherightfrontRCAjackoutput.

 • ConnecttheGreenRCAjacktotheleftrearRCAjackoutput.

 • ConnectthePurple RCAjacktotherightrearRCAjackoutput.

Produktspezifikationen

Marke:	Metra
Kategorie:	Nicht kategorisiert
Modell:	70-1787

Brauchst du Hilfe?

Wenn Sie Hilfe mit Metra 70-1787 benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten

Ihren Namen*

Deine E-Mail*

Schreiben Sie hier Ihre Frage

Bedienungsanleitung Nicht kategorisiert Metra

Metra 70-7864DZ Bedienungsanleitung

1 September 2025

Metra 99-7318 Bedienungsanleitung

1 September 2025

Metra 70-1787 Bedienungsanleitung

1 September 2025

Metra 71-6522 Bedienungsanleitung

1 September 2025

Metra 99-9700 Bedienungsanleitung

1 September 2025

Metra 99-7605 Bedienungsanleitung

31 August 2025

Metra XSVI-9004-NAV Bedienungsanleitung

31 August 2025

Metra 70-6507 Bedienungsanleitung

31 August 2025

Metra 82-8603 Bedienungsanleitung

8 August 2025

Metra AXHN-2 Bedienungsanleitung

8 August 2025

Bedienungsanleitung Nicht kategorisiert

Neueste Bedienungsanleitung für -Kategorien-

Samsung AM028FNMDEH Bedienungsanleitung

1 September 2025

Tripp Lite N286-10G-SR-C Bedienungsanleitung

1 September 2025

LG 55LS570Y Bedienungsanleitung

1 September 2025

Samsung WT16B5240BA Bedienungsanleitung

1 September 2025

Samsung AM045JNVDEH Bedienungsanleitung

1 September 2025

Chief PACSBM Bedienungsanleitung

1 September 2025

LG 47LW450Y Bedienungsanleitung

1 September 2025

LG 47LS460Y Bedienungsanleitung

1 September 2025

Tripp Lite U338-000 Bedienungsanleitung

1 September 2025

JobSite S-6 Bedienungsanleitung

1 September 2025
