middleatlantic.com | middleatlantic.ca

what great systems are built on.

™

96-940 / rev e / 5-12-20

PDS Series

rackmount power sequencer

rackmount power sequencer provides

sequenced 15 amp (single or dual circuit)

and 20 amp (single circuit) power

features:

• Provides 6-step sequencing to six rear outlets

• Single or dual circuit models available

• Adjustable start delay times

• Adjustable sequence intervals

• System may be activated locally via front panel,

or remotely via rear terminal block

• Up to three units may be chained together via simple

parallel wiring, providing 18 sequence steps

• UL Listed in the US and Canada

EIA compliant 19” rackmount power sequencer shall be Middle Atlantic Products model # PDS-__(refer to chart)R and shall be

constructed of 16-gauge steel finished in durable black powder coat. Power sequencer shall operate on 120 volt AC/60Hz power

and shall terminate with (1,2) 9’ 3 wire SignalSafe™power cord(s) with NEMA 5-__(15,20)P plug(s)(refer to chart). Rear, dry

contact closure shall provide status indicat

ion to compatible customer supplied monitoring device. Contacts shall be closed when all

channels are on; contacts shall be open when all channels are closed. Power sequencer shall feature __ circuits (refer to chart). Power

sequencer shall feature (15,20) amp circuitry for six rear-mounted NEMA 5-__(15,20)R receptacles and a (15,20) amp front-mounted

circuit breaker(s) and master switch. Additional rear outlet sha

ll be unswitched and uncontrolled. Power Sequencer shall be ETL listed

to UL standard 1419, UL 60950-1 and UL 60065 in the US; CSA standard 60950-1, and CSA C22.2 No. 60065 in Canada. Power

sequencer shall be manufactured by an ISO 9001 and 14001 registered company. Power sequencer shall be warrantied to be free from

defects in material or workmanship under normal use and conditions for a period of 3 years.

Customizable specification clips available at middleatlantic.com

specifications:

PDS-620R

EIA/TIA COMPLIANT
