RackLink™ Series
Quick Start Guide
I-00469 Rev E
NOTE: Access software downloads, firmware updates, and the RackLink Premium Owner's Manual at
www.middleatlantic.com or contact support at 1-800-266-7225.
SETTING UP THE RACKLINK HARDWARE
1. Install the device in the location it will reside.
2. Plug the device into a properly grounded AC power source.
3. Connect the device to your network using a standard Cat5e cable (or better, not provided).
4. If connecting to a control system using the RS-232 port, you will need a female to female null modem cable
(not provided).
NOTE: The default IP address is 192.168.1.200.
USING WEB INTERFACE OPERATIONS
NOTE:
• Refer to the RackLink Premium Owner's Manual (I-00468) at www.middleatlantic.com for comprehensive
web interface operations.
• Middle Atlantic Products recommends updating your device to the latest firmware version. Download the
latest firmware updates at www.middleatlantic.com or contact support at 1-800-266-7225 and follow the
“Updating Your Firmware” topic at the end of this guide.
USING THE FREE MIDDLE ATLANTIC PRODUCTS DDNS SERVICE
Take advantage of the free DDNS service provided by Middle Atlantic Products by contacting support at
1-800-266-7225.
TROUBLESHOOTING
Forgotten Password:
Press the Restore Defaults button on your device. This will default the login to admin and the system forces you to
change the default password for security purposes.
NOTE: Pressing this button also defaults your device to using DHCP.
Cannot Access Web Interface:
Verify if you are able to access a standard web page, such as www.google.com.
Verify the green LED on the Ethernet port is lit (not flashing) and the yellow LED is flashing.
Unit Will Not Operate After Firmware Upgrade:
Contact Middle Atlantic Products technical support at 1-800-266-7225.
RackLink Not Receiving Power:
Check that your power cable is securely fastened and confirm the circuit breaker on the unit is in
the ON position.
Plug another device into the same receptacle and see if the other unit receives power.
INSTALLING THE DEVICE DISCOVERY SOFTWARE
1. Dowload the installation file at www.middleatlantic.com or contact support at 1-800-266-7225.setup.exe
2. Run the file on a computer connected to the same network on which your RackLink device setup.exe
resides.
NOTE: The default installation path is C:\Program Files\Middle Atlantic Products\RackLink Discovery, however, this
location may be changed to a different installation location, if desired.
3. Follow the installation steps until the Device Discovery Tool opens on your computer.
4. When launched, the Device Discovery Tool discovers and lists all RackLink devices on the same subnet.
5. Locate the specific device you wish to access from the list and click the corresponding Device Control
button on the same row.
The device’s web interface appears.
6. Log into the system using the default login and password: (admin/admin).
NOTE: After logging in for the first time, the system forces you to change default passwords for security purposes.
7. After logging in, access the Setup tab to configure your device’s attributes.
UPDATING YOUR FIRMWARE
NOTE:
• Middle Atlantic Products recommends updating your device to the latest firmware version. The following procedure
quickly explains how to update your firmware. For a more detailed version of this procedure, refer to the RackLink
Premium Owner's Manual (I-00468) at www.middleatlantic.com.
• The version of the currently installed firmware is displayed at the bottom of every page of the user interface.
1. Log into your RackLink using the Administrator account.
2. Click the tab (on the left navigation bar).Setup
The Device Settings page appears.
3. Click the link.Upload a new version
The Update Firmware page appears.
4. Click the link next to "Get the Latest Firmware".Firmware
Confirm the latest firmware version and revision number as being newer than the version you already have
installed on your device.
5. If the firmware version currently installed on your device is older than the latest version, click and then Download
store the file in the desired location on your computer by clicking .Save
NOTE: If you have any issues downloading the correct firmware for your RackLink device, please contact support at
1-800-266-7225.
6. Click the button on your browser and return to the Update Firmware page.Back
7. Click the button next to "Upload New Firmware".Browse...
Locate and select the firmware file you just downloaded and stored on your computer.
8. Click .Upload
9. After your firmware uploads successfully to your device, click .Install
Once the installation is complete, your device reboots the My Device page appears.
WARRANTY
For warranty information, refer to http://www.middleatlantic.com/company/about-us.aspx#warranty
Corporate Headquarters
Voice: 973-839-1011 - Fax: 973-839-1976 - International Voice: +1 973-839-8821 -
Fax: +1 973-839-4982 - www.middleatlantic.com - info@middleatlantic.com
Middle Atlantic Canada
Voice: 613-836-2501 - Fax: 613-836-2690 - ca.middleatlantic.com -
customerservicecanada@middleatlantic.ca
Middle Atlantic EMEA Technical Support
Voice: +31 (0) 495 726002 - av.emea.middleatlantic.support@legrand.com
Factory Distribution
United States: New Jersey, California, Illinois - Canada: Ontario - The Netherlands: Weert
At Middle Atlantic Products we are always listening. Your comments are welcome.
Middle Atlantic Products is an ISO 9001 and ISO 14001 Registered Company.
