Mimo Monitors
Sales: 1-855-YES-MIMO (937-6466)
Manual and Specications
Please keep this manual for future reference.
Mimo Vue with BrightSign HS124 Built-in
MBS-1080C-OF / MBS-1080C-OF-POE
MBS-1080-OF / MBS-1080-OF-POE
MBS-1080C / MBS-1080C-POE
MBS-1080 / MBS-1080-POE
- Touch -
- Non-Touch -
BRIGHTSIGN BUILT-IN
BRIGHTSIGN BUILT-IN SoC SERIES4
BrightSign oers two System on a Chip (SoC) solutions based on the HD Series
4 class BrightSign player. The BrightSign Built-In portfolio consists of the
HS124 and HS144, both of which feature a new, low-prole form factor and
are intended for integration into OEM commercial products. The BrightSign
HS124 oers Full HD video, while the BrightSign HS144 oers 4K video support.
BrightSign’s SoC solutions are compatible with all BrightSign software, services
and a wide range of supported CMS solutions.
As with all BrightSign hardware, our SoC solution is purpose-built for digital
signage, with a dedicated OS for unrivaled performance & security, and broad
industry support from leading CMS providers. BrightSign SoC is the clear choice
for display-integrated digital signage.
BrightSign, LLC. 983 University Ave, Suite A, Los Gatos, CA 95032 | USA 408-852-9263 | International +44 1223 298500 | www.brightsign.biz
Panel Control
Board
Panel
70mm
100mm
Model Features
• Powerful video engine (HS124 supports Full HD 1080p60 single decode; HS144 supports 4Kp60 single decode)
• Low-power, fan-less design (optional heatsink ns can be installed to improve thermal dissipation)
• HDMI output (HS124 supports 1.4; HS144 supports 2.0a) with CEC
• Mainstream HTML5 Engine
• Highly reliable media handling platform
• 100baseT Ethernet
• S/PDIF digital audio
• Engaging interactive controls: GPIO, UDP, 1x USB 2.0, Serial and IR controls
• Wi-Fi/Bluetooth module (optional)
• Single edge connector for all host I/O (mates with industry-standard M.2 sockets)
HS144
H.265
HEVC
High Efficiency Video Decoding
H.265
Tagging
Interactive
IP Streaming
Remote Snapshot
Sign Preview
Zones
Live Feeds
Geo-Fencing
BrightSign App
BrightWall
TM
Preview
Preview
Preview
Preview
B-Deploy
BrightBeacon
TM
Mainstream
HTML5
Mosaic Mode
HTML
AutoWall™
Digital Audio
FULL HD
1080p60 single
decode
4K60p single
decode
HS124
Produktspezifikationen
| Marke: | Mimo Monitors |
| Kategorie: | Monitor |
| Modell: | MBS-1080C |
| Touchscreen: | Ja |
| Bildschirmdiagonale: | 10.1 " |
| Bildschirmtechnologie: | LCD |
| Eingebaute Lautsprecher: | Ja |
| Integrierte Kamera: | Nein |
| Produktfarbe: | Schwarz |
| RMS-Leistung: | 3 W |
| Betriebstemperatur: | -10 - 50 °C |
| Zertifizierung: | CE, FCC, RoHS |
| Stromverbrauch (Standardbetrieb): | 24 W |
| HD-Typ: | Full HD |
| Bildschirmform: | Flach |
| Natives Seitenverhältnis: | 16:10 |
| Helligkeit: | 350 cd/m² |
| Reaktionszeit: | 14 ms |
| Kontrastverhältnis: | 800:1 |
| Bildwinkel, horizontal: | 85 ° |
| Bildwinkel, vertikal: | 85 ° |
| Anzahl der Lautsprecher: | 2 |
| VESA-Halterung: | Ja |
| Touch-Technologie: | Multitouch |
| Seitenverhältnis: | 16:10 |
| Wandmontage: | Ja |
| HDMI: | Ja |
| NVIDIA G-SYNC: | Nein |
| AMD FreeSync: | Nein |
| Anzahl der nachgeschalteten Steckplätze vom Typ USB-A: | 1 |
| Touchscreen Technologie: | Kapazitiv |
| Display-Auflösung: | 1280 x 800 Pixel |
