© MuxLab Inc. 2016 94-000823-A SE-000823-A

8495 Dalton Road, Mount Royal, Quebec, Canada. H4T 1V5

Tel: (514) 905-0588 Fax: (514) 905-0589

Toll Free (North America): (877) 689-5228

E-mail: videoease@muxlab.comURL: www.muxlab.com

Specifications

Environment

HDMI 2.0a

Devices

Ultra HD Blu-Ray, projectors, monitors, TV, PC, laptops.

Transmission

Transparent to the user.

Video Bandwidth

18 Gbps

Frequency Range

25 to 600 MHz

Signals

HDMI 2.0a protocol.

HDCP

Revision 1.4 & 2.2 compliant.

Connectors

HDMI receptacle.

LEDs

Power: Blue

Input & Output Link: Green

Resolution

480i to 1080p @ 50/60 FPS

1080p @ 24/50/60 FPS

3840 X 2160 @ 24/25/30/60 FPS

Color

8, 10 & 12 bit

Audio

LPCM 7.1CH, Dolby TrueHD, Dolby Atmos, DTS-HD Master

Audio and DTS:X

Cable

HDMI cable of appropriate length for video resolution selected.

Power Supply

One (1) 110-240V/5VDC , 2A power supply

Temperature

Operating: 0° to 40°C Storage: -20° to 60°C

Humidity: up to 90% non-condensing

Enclosure

Metal enclosure

Bracket

Included

Dimensions

4.33” x 2.44” x 1.00” (110 mm x 62 mm x 25 mm)

Weight

0.8 lbs (0.36 Kg)

Compliance

Regulatory: FCC, CE, RoHS

Warranty

2 years

Order Information

500425HDMI 1X2 Splitter, 4K/60 (UPC: 627699004258)

HDMI 1X2 Splitter, 4K/60 (500425)

Quick Installation Guide

Overview

The HDMI 1x2 Splitter (500425) allows one (1) HDMI source to be distributed to

up to two (2) HDMI displays. The splitter supports up to 4K (3840 X 2160) video

and HD audio. The splitter is HDCP 1.4 & 2.2 compliant and features LED

diagnostics. Additionally, all connectors are on the rear panel for neater cabling.

Applications include; commercial and residential AV systems, classroom projector

systems, digital signage, boardroom systems, collaborative PC systems, medical

information systems.

Pre-Installation Check

Identify the connectors as indicated on the product diagram above. LEDs are

located on the front and the connectors and mode switch on the rear.
