Stereo Hi-Fi Wall Balun

500028-WP-US

__________________________________________________________________________________

© MuxLab Inc. 2011 Stereo Hi-Fi Wall Balun

MuxLab Inc.

8495 Dalton Road, Mount Royal, Quebec, H4T 1V5

Tel: (+1) 514 905 0588 Fax: (+1) 514 905 0589

Toll Free: 877 689-5228

E-mail: [email protected]

URL: www.muxlab.com

Overview

The Stereo Hi-Fi Wall Balun (500028-WP-US)

allows unbalanced line level stereo analogue

audio to be transmitted via Category 5e/6

unshielded copper twisted pair (UTP) in a point-

to-point connection. The product is designed for

audio applications where full-range, hi-fidelity

audio frequency response is required.

Used in pairs, the Stereo Hi-Fi Wall Balun

eliminates costly and bulky coaxial cable,

allowing audio equipment to be connected or

moved within a structured cabling environment.

Applications

Boardroom systems, classroom training,

auditoriums, custom home installations and

intercom systems.

Features & Benefits

20 Hz to 20 KHz bandwidth

Cost-efficient cabling

Up to 3,250 ft (1km) via Cat5e/6 UTP

Quicker moves, adds and changes

Compatible with Decora™ face plates

Specifications

Environment

Line level unbalanced analogue audio

Devices

DVD players, satellite receivers, MPEG players, laptops, hi-fidelity stereo audio

amplifiers, audio switchers, AV monitors, powered subwoofer and other line level

audio equipment

Transmission

Transparent to the user.

3dB Bandwidth

20 Hz to 20 KHz over the distance range

Maximum Input

1.1Vp-p (unbalanced)

Insertion Loss per balun pair

Less than 2 dB over the frequency range.

Common Mode Rejection

Greater than 60 dB @ 1 KHz

Greater than 40 dB over the frequency and distance range

THD

Maximum 0.007% @ 1 KHz over distance range.

Audio Source Impedance

100 ohms maximum

Audio Receiver Impedance

10 k ohms minimum

Max. Distance – Cat5e/6 UTP

3,250 ft (1km)

Pin Configuration (RJ45)

EIA 568 A or B

Audio 1 (White): pins 1[R] & 2 [T]

Audio 2 (Red): pins 3 [R] & 6 [T]

Cable – UTP

24AWG or lower solid copper twisted pair wire

Impedance: 100 ohms at 1 MHz; Maximum capacitance: 20 pf/foot.

Attenuation: 6.6 dB/1000 ft at 1 MHz

Cable – Coax

Shielded audio cable

Connectors

Two (2) RCA-F

One (1) RJ45

Temperature

Operating: 0º to 55º C. Storage:-20º to 85º C. Humidity: up to 95%

Enclosure

ABS. Fire retardant plastic

Dimensions

4.1” (104 mm) x 1.8” (45.7 mm) x 1.44” (36.6 mm). Choose 1.6” (40 mm) deep

back box to allow for Cat 5E/6 wiring connection.

Weight

4.1 oz (115 g)

Warranty

Lifetime

Order Information

500028-WP-US Stereo Hi-Fi Wall Balun, US

Decora ™ is a registered trademark of Leviton Manufacturing Co, Inc.
