MCTRL6 00

LED Display Controller

Specications

MCTRL600 LED Display Controller Specications

www.novastar.tech

Change History

Document Version

Release Date

Description

V2.3.3

2024 22- -08

Updated the packing box dimensions.

V2.3.2

2023 16- -11

Updated the video source specications

V2.3.1

2021 02- -08



Changed the number of receiving cards loaded by the Ethernet port

from 256 to 512.



Updated the packing information.

V2.3.0

2020 12- -10



Added the hot backup verication function.



Added the 10bit Gamma adjustment function.



Optimized the device cascading solution. Up to 20 devices can be

cascaded.



The default screen conguration information becomes 128×128 after

factory reset.



Updated the product appearance diagram.

Introduction

The MCTRL600 is an LED display controller tar Tech Co., Ltd. (hereinafter referred to as developed by Xi’an NovaS

NovaStar). It supports 1x DVI input, 1x HDMI input, 1x audio input, and 4x Ethernet outputs. A single MCTRL600

supports input resolutions up to 1920×1200@60Hz.

The MCTRL600 communicates with PC via type-B USB port. Multiple MCTRL600 units can be cascaded via UART

port.

As a highly cost-eective controller, the MCTRL600 can be mainly used in the rental and xed installation

applications, such as concerts, live events, security monitoring centers, Olympic Games and various sports centers.

Certications

FCC, CE, EAC, IC, PFOS

If the product does not have the relevant certications required by the countries or regions where it is to be

sold, please contact NovaStar to conrm or address the problem. Otherwise, the customer shall be

responsible for the legal risks caused or NovaStar has the right to claim compensation.

Features



3 types of input connectors

− 1x SL-DVI

− 1x HDMI 1.3

− 1x AUDIO



4x Gigabit Ethernet outputs



1x light sensor connector



1x type-B USB control po rt



2x UART control ports

They are used for device cascading. Up to 20

devices can be cascaded.



Pixel level brightness and chroma calibration

Working with NovaLCT and calibration platform,

the controller supports brightness and chroma

calibration on each LED, which can eectively

remove color discrepancies and greatly improve

LED display brightness and chroma consistency,

allowing for better image quality.Appearance

MCTRL600 LED Display Controller Specications

www.novastar.tech

Front Panel

Indicator

Status

Description

RUN

(Green)

Slow ashing (ashing once in 2s)

No video input is available.

Normal ashing (ashing 4 times in 1s)

The video input is available.

Fast ashing (ashing 30 times in 1s)

The screen is displaying the startup image.

Breathing

The Ethernet port redundancy has taken eect.

STA

(Red)

Always on

The power supply is normal.

O

The power is not supplied, or the power supply is abnormal.

Rear Panel

Connector Type

Connector Name

Description

Input

DVI IN

1x SL-DVI input connector



Resolutions up to 1920×1200@60Hz



Custom resolutions supported

Maximum width: 3840 (3840×600@60Hz)

Maximum height: 3840 (548×3840@60Hz)



Does NOT support interlaced signal input.

HDMI IN

1x HDMI 1.3 input connector



Resolutions up to 1920×1200@60Hz



Custom resolutions supported

Maximum width: 3840 (3840×600@60Hz)

Maximum height: 3840 (548×3840@60Hz)



HDCP 1.4 compliant



Does NOT support interlaced signal input.

AUDIO

Audio input connector

Output

4x RJ45

4x RJ45 Gigabit Ethernet ports



Capacity per port up to 650,000 pixels



Redundancy between Ethernet ports supported

Functionality

LIGHT SENSOR

Connect to a light sensor to monitor ambient brightness to

allow for automatic screen brightness adjustment.
