WARNING: Risk of Fire or Electric Shock

• To reduce the risk of re, electrical shock or injury to persons;

read and follow all warnings and installation instructions before

installing.

• All installation should be performed by a qualied electrician.

• To avoid electric shock, ensure power is turned off before

installation or inspection. All wiring must be installed in

accordance with Electrical Code and local electrical code.

• To prevent re, this xture is rated for use in 120-277V, 50-60Hz

protected circuit and 75°C rated supply wire.

• External 1-10V only passive dimmers are supported.

Visit Satco.com for list of compatible controls.

• To prevent product malfunction and/or electrical shock, this

product must be properly grounded.

• To avoid damage and/or product malfunction, do not modify

the xture or replace accessories without conrming with the

supplier rst.

• To prevent wiring damage or abrasion, do not expose wiring to

edges of sheet metal or other sharp objects.

• Suitable for wet locations.

IMPORTANT:This product must be installed in accordance

with the applicable installation code by a person familiar with the

construction and operation of the product and the hazards involved.

There are two optional brackets for this xture. The following are street light xtures with the different brackets.

1

CCT SELECTABLE LED DUSK TO

DAWN AREA LIGHT W/PHOTOCELL

Models: 65-681, 65-682, 65-683, 65-684, 65-685, 65-686

Satco Products, Inc.

Brentwood, NY 11717

Optional Brackets:(See page 2 for Installation Intructions)

INSTALLATION AND SAFETY INSTRUCTIONS

IMPORTANT: Read before installing xture. Retain for future reference.

© Copyright 2020 Satco Products, Inc. 8/20

WIRING DIAGRAM

Item No. CCT Lumens

65-681 3000K/4000K/5000K 4060~4640

65-682 3000K/4000K/5000K 5600~6400

65-683 3000K/4000K/5000K 8400~9600

65-684 3000K/4000K/5000K 4060~4640

65-685 3000K/4000K/5000K 5600~6400

65-686 3000K/4000K/5000K 8400~9600

Pipe Arm

Installation

Wall

Installation

NOTE: Refer to

lamp label for

Dim+ and Dim–

wire color.

Dim+

Dim–

ACL: Black/Brown

Green/Yellow

ACN: White/Blue
