Seite 1/2
Second./core:
Primary/core:
5/3.75 W
2.5/1.25 W
0.625 W
10/7.5 W
5/2.5 W
1.25 W
20/15 W
10/5 W
2.5 W
30/22.5 W
15/7.5 W
3.75 W
50/37.5 W
25/12.5 W
6.25 W
100/75 W
50/25 W
12.5 W
75/56.25 W
37.5/18.75 W
9.375 W
red/blue
yellow/white
green
USER MANUAL
www.omnitronic.com
00057161.DOC, Version 1.0
Audio Transformers
The audio transformers of the T series were specially designed for converting low-impedance signals into 100 V
signals for PA systems. Thus, also low-impedance speakers or amplifiers without built-in 100 V audio
transformer can be connected to the 100 V line of the PAsystem. The power is matched via selection of cables.
Before your initial start-up, please make sure that there are no transport damages. Should there be any, do
not take the product into operation and immediately consult your dealer.
This product was designed for indoor use only. Protect it against humidity and heat. The ambient temperature
must always be between 0° C and 40° C. Keep away from heaters and other heating sources.
Speaker cables are sensitive to electrical interference. Hence, it is recommended to lay them at a
distance of several meters to sources of interference (e.g. dimmers, light switches).
Maintenance and service operations are only to be carried out by authorized dealers. Damage, caused by
manual modifications on the product are not subject to warranty. If the product is used for other purposes than
originally intended or if it is not correctly connected, it may suffer damage and the guarantee
becomes void.
For cleaning, please use a soft lint-free and moistened cloth. Never use alcohol or solvents!
H
.
If the PAsystem is turned on, turn it off before making any connection.
The transmformer's secondary cores serve as connectors for low-impedance signals. Connect the
black core COM to the negative pole and, according to the impendace (4, 8 or 16 ), one of the other colored
cores to the positive pole.
The transmformer's primary cores serve as connectors for the 100 V line of the PA system. Connect the
black core COM to the negative pole and, according to the desired power rating (see Technical
Specifications), one of the other colored cores to the positive pole.
Safety Instructions
E
Technical Specifications
!
!
!
!
!
!
!
!
W
lectrical Connection
DANGER TO LIFE!
igh voltage at connection cables. Installation by skilled personnel only!
Cabling a PA system is an electric installation which must only be carried out by a qualified electrician! Always
insulate the connection cables which are not used. Pay attention to the correct power matching. Overload will
result in damage of the PAamplifier
Turn off PAsystem before connecting.
Model T100T5 T10 T20 T30 T50 T75
Frequency
range:
50-15000 Hz 30-15000 Hz 40-17000 Hz 40-17000 Hz 30-15000 Hz 30-15000 Hz 30-15000 Hz
Power:
5 W RMS 10 W RMS 20 W RMS 30 W RMS 50 W RMS 75 W RMS 100 W RMS
Dim. (mm):
60 x 35 x 35 76 x 43 x 41 71 x 44 x 44 85 x 54 x 50 93 x 57 x 56 93 x 60 x 60 93 x 66 x 60
Weight:
180 g 300 g 400 g 675 g 900 g 950 g 1030 g
AUDIO TRANSFORMERS
Please note: Every information is subject to change without prior notice. 12.01.2011 ©
4 (red)/8 (yellow)/16 (green)W W W
