PHOTOELECTRIC DETECTOR
PHOTOELECTRIC DETECTOR
CONTENTS
1 INTRODUCTION
1-1 BEFORE YOUR OPERATION ............................... 2
1-2 PRECAUTIONS...................................................... 3
2 PARTS IDENTIFICATION............................................ 3
3 INSTALLATION
3-1 NOTE...................................................................... 4
3-2 INSTALLATION METHOD .................................... 4
4 WIRE CONNECTION................................................... 6
5 ALIGNMENT
5-1 OPTICAL ALIGNMENT .......................................... 7
5-2 BEAM INTERRUPTION TIME................................ 8
5-3 SELECTABLE BEAM FREQUENCIES
< AX-100/200TF ONLY > ....................................... 8
6 WALK TEST................................................................. 9
7 SPECIAL FUNCTION < AX-100/200TF ONLY >
7-1 ENVIRONMENTAL DISQUALIFICATION .............. 9
7-2 ALARM MEMORY .................................................. 9
8 OPTIONAL ACCESSORIES
8-1 HEATING UNIT : HU-3......................................... 10
8-2 BACK COVER : BC-3........................................... 11
8-3 POLE SIDE COVER : PSC-3 ............................... 11
9 TROUBLESHOOTING............................................... 12
10
SPECIFICATIONS
10-1 SPECIFICATIONS.............................................. 13
10-2 DIMENSIONS & OPTION................................... 14
INSTALLATION INSTRUCTIONS
FEATURES
No.59-2419-2 2111-29
No.59-1282-7 0904-30
AX-70TN, AX-130TN, AX-200TN
AX-100TF, AX-200TF
< AX-70/130/200TN, AX-100/200TF >
•High-performance waterproof structure
•Horizontal alignment dial for user-friendliness
•Adjustable beam interruption period
•Tamper function
•
Optional Accessories : Heating unit (HU-3), Back cover (BC-3),
Pole side cover (PSC-3)
•UL Listed
< AX-100/200TF ONLY >
•4 selectable beam frequencies
•LED indicator for fine beam alignment level
•D.Q. circuit (Environmental disqualification)
•Alarm memory
AX-200TN 60 m / 200 ft.
30 m / 100 ft.
4 selectable beam
frequencies
60 m / 200 ft.
AX-100TF
AX-200TF
Model Detection range Feature
20 m / 70 ft.
40 m / 130 ft.
Standard model with
detection range
60 m / 200 ft.
AX-70TN
AX-130TN
UL
AX-70TN, AX-130TN, AX-200TN
AX-100TF, AX-200TF
EN
Multilingual instructions
Visit to the Web site to find
valious language versions.
https://navi.optex.net/manual/08401/
- 1 -
Warning
Caution
This symbol indicates prohibition. The specific prohibited action is provided in and/or around the figure.
This symbol requires an action or gives an instruction.
Do not use the product for purposes other than the detection of moving objects such as people and vehicles.
Do not use the product to activate a shutter, etc., which may cause an accident.
Do not exceed the voltage or current rating specifi ed for any of the terminals during installation, doing so
may cause fire or damage to the devices.
Never attempt to disassemble or repair the product. It may cause fire or damage to the devices.
Do not pour water over the product with a bucket, hose, etc. The water may enter, which may cause damage
to the devices.
Clean and check the product periodically for safe use. If any problem is found, do not attempt to use the
product as it is and have the product repaired by a professional engineer or electrician.
Do not touch the unit base or power terminals of the product with a wet hand (do not touch when the
product is wet with rain, etc.). It may cause electric shock.
Warning
Caution
Failure to follow the instructions provided with this indication and improper handling may cause
death or serious injury.
Failure to follow the instructions provided with this indication and improper handling may cause
injury and/or property damage.
1
INTRODUCTION
1-1
BEFORE YOUR OPERATION
• Read this instruction carefully prior to installation.
• After reading, store this instruction carefully in an easily accessible place for reference.
• This instruction uses the following warning indications for correct use of the product, harm to you or other people
and damage to your assets, which are described below. Be sure to understand the description before reading the
rest of this instruction.
- 2 -
1-2
PRECAUTIONS
Mount unit only on a solid
surface.
Do not install the unit on
unsteady surfaces.
Do not install the unit
where objects moved by
the wind such as plants
and laundry, which may
block the beam.
Prevent direct sunlight
from entering into internal
receiver.
A different type of beam
should not reach the
receiver.
Mount the units more than
1 m away from the wall or
fence.
This symbol indicates
prohibition.
This symbol indicates
recommendation.
Avoid aerial wiring.
Receiver
Transmitter
(other model)
Transmitter
1m(3.3ft.)
2
PARTS IDENTIFICATION
View Finder
Terminals
Transmitting Condition LED
(Transmitter)
Alarm Indicator LED
(Receiver)
Waterproof Plug
Selection Dip Switch
(See "4 WIRE CONNECTION", "5-2 BEAM
INTERRUPTION TIME", and "7-2 ALARM
MEMORY < AX-100/200TF ONLY >")
Alarm Memory (Receiver)
(See "7-2 ALARM MEMORY < AX-100/200TF ONLY >")
Optical Unit
Cover
Unit Base
Mounting Plate
Pole-mounting Bracket
Wiring
Hole
Vertical Alignment
Screw
Horizontal
Alignment Dial
Monitor Jack
(Receiver)
Selection Switch
(See "5-3 4 SELECTABLE BEAM
FREQUENCIES < AX-100/200TF ONLY >")
- 3 -
